1. Overview of Upgrade to WSS 3.0 and SharePoint Server 2007 Joel Oleson
Sr. Technical Product Manager
Microsoft Corporation
2. Agenda Upgrade Preparation
Prescan and * Disk considerations
Upgrade Methods and Options
In-Place, Gradual and Content DB Migration
Post Upgrade Considerations
Customizations, Content
Partner Upgrade Tools
Summary
Q & A
3. Upgrade/Migration Path
4. Preparing for Upgrade Scope and Plan your upgrade
Review Hardware End of Life, plan for upgrade capacity; disk space, memory, processor
Test your upgrade & estimate your upgrade duration
Review customizations
Keep or Decommission customizations
Cleanup
Remove Orphans, increase close quotas, remove locks,
Service Offering
Redesign, Training, Communication plan
5. What will Prescan find? Sites based on customized site templates - site template upgrade kit
Sites based on custom site definitions
Unghosted pages
Orphaned objects
Custom Web Parts
Sites than need language packs
6. Prescan Example of good PreScan results:
07/19/2006 17:17:01 Scan finished without failure.
07/19/2006 17:17:01 Number of sites skipped (already scanned): 0
07/19/2006 17:17:01 Number of sites scanned: 1
07/19/2006 17:17:01 Number of broken sites: 0
07/19/2006 17:17:01 Number of webs scanned: 13
07/19/2006 17:17:01 Number of broken webs: 0
07/19/2006 17:17:01 Number of webs using custom template: 0
07/19/2006 17:17:01 Number of pages scanned: 0
07/19/2006 17:17:01 Number of unghosted pages: 63
7. Upgrade Options In-Place Upgrade
For small non production environments, offline while it runs (Not recommended for most environments)
Gradual Upgrade: Side by Side Upgrade
Granular control, one to many site collections at a time
Side-by-side; rollback to 2003 supported
More complex & resource intensive
Content DB Migration: Upgrade Into Separate Farm
Attach 2003 content db to 2007 farm & upgrade runs
2003 farm stays available and untouched
Content only, requires new farm, has many manual steps
8. In Place Upgrade Pros:
Simple and fast upgrade
Best for smaller or non production environments
Cons:
Environment offline during upgrade
Riskier in large environments
Upgrade Fails if it encounters errors -fix then rerun.
Not Recommended for Most Deployments
9. Database Mapping
10. In-Place Upgrade Steps On existing hardware, install prerequisites
Run setup and choose In-Place Upgrade
Install language packs if needed
Deploy Upgrade Definition, Site Definition and Feature Files
Run Configuration Wizard and Upgrade one web server
Review log files and resolve any issues
Review upgraded content
Reset pages (or site) to Site Definitions
11. Gradual Upgrade Pros:
Old and new SharePoint versions run in parallel
Allows upgrade with minimal downtime
Can roll-back upgrades per site collection
Cons:
Redirector will cause user confusion
Additional impact from two SharePoint versions
12. Gradual Upgrade Process
13. On existing hardware, install prerequisites
Prepare URL Redirect Domain
Install Binaries and Choose Gradual Upgrade Option
Run Configuration Wizard to setup a new farm
Install Language Packs
Deploy Upgrade Definition, Site Definition and Feature Files
Deploy Custom Web Part Packages and any other custom code (only if in Bin directory)
14. Gradual UpgradeUpgrade Steps Review log files & resolve any issues
Repeat setup & upgrade on each server in the farm
Start content upgrade thru UI or stsadm
Review your upgraded content
If customized sites, reset pages to 2007 site definition versions
Fix issues and reapply customizations using SharePoint Designer
If upgrade result is undesirable, revert to 2003 site
15. Gradual UpgradeContent Upgrade
16. Gradual Upgrade Revert to 2003 When upgrade result is undesirable, revert deletes 2007& resets redirect to 2003
Confirm 2003 site still exists before reverting to it
Revert to 2003 via UI or command line
UI: Select Sites for Upgrade > Revert Site
Command line: stsadm o upgrade revert
Once complete, re-upgrade original
Use SharePoint designer to merge changes from fixed& re-upgraded versions
17. Gradual Upgrade Scenarios Works best for Staging Environment
Environments with Heavy Customizations
Recommended for Large Databases and Site Collections
Upgrade a subset of Site Collections only
Environments requiring minimal migration window
18. Content DB Attach Upgrade Pros:
Fast upgrade method
Cons:
More complex than in-place upgrade
Note: This does still require Prescan. Dont forget assemblies
19. Content DB Migration
20. Create new 2007 farm on clean hardware
Install prerequisites
Configure farm-level settings
Create a new web application for each 2007 virtual server
Manually re-apply configuration settings
Ensure all inclusions re-created in 2007 (required)
Deploy Upgrade Definition, Site Definition and Feature Files
Deploy custom web parts to GAC or BIN Content DB Migration Steps
21. Back up 2003 content database using SQL
Restore backup to copy in 2007 farm
Add content db to web application via command line
Ensure root site included in first database
stsadm o addcontentdb
Upgrade triggers automatically, runs until it completes
For large databases, command line preferable
Review log files for any issues
Repeat for all additional content and search/user profile databases
stsadm o restoressp
Content DB Migration Stepscontinued
22. Set 2003 content DBs to read-only
Avoids manual merging of updates post-upgrade
Note: Users will see warnings when DB is read-only
Re-mapping URLs
Use ISA Server to remap URLs to 2007 farm
Use IIS Redirect
Use DNS
Re-applying inclusions, custom web parts & custom site definitions are critical
Entirely manual process for moving them Content DB MigrationAdditional Considerations
23. Moving to new hardware or a new architecture
Customers who need to maximize upgrade throughput.
Required for Scalable Hosting Mode or Active Directory Account Creation Mode.
Recommended for Large Farms
24. Database Attach on Steroids
25. 2003 Customizations Templates
Custom Site Definitions
Custom Site Templates
Page Templates
Custom Code
Web Parts
Event Handlers
Client-side Scripts
ASP.NET apps in _layout
Branding and Layout Customizations
Style sheets and Themes
FrontPage Customizations
Non-SharePoint Elements
NT Services
Web services
Custom DLLs
26. Customization Considerations
27. Resetting to Site Definition
28. Page ReGhosting (Reverting) Unghosting of pages occurs easily
Upgrade may not affect unghosted status
Page re-ghosting in Site Settings or Designer
Re-ghosting pages during upgrade:
Your choice
Can be performed by Server Administrator or Site Collection Admin
29. Upgrade Effects on Ghosting
30. Upgrading Site Definitions Three things required to upgrade site definitions:
Prescan configuration file
Upgrade configuration file
Upgraded site definition
Upgrade file changes site structure:
<List FromTemplateId="104 ToFeatureId="00BFEA71-D1CE-42de-9C63-A44004CE0104" />
<File FromPath="{LocaleId}\STS\default.aspx ToPath= "SiteTemplates\STS\default.aspx" />
31. Upgrade Considerations Best Practices
Reduce Dependency on Site Definitions (Use Soln Deployments)
Consolidate Web Applications and farms
Information Architecture Restructure
Content/structure change Workflow & Forced Checkout
URL/path change - Global Nav & Breadcrumbs
WSS upgrade to MOSS
32. Finalize Upgrade Business/Customer approval
Removes gradual upgrade redirector
Can remove SharePoint 2003 afterwards
Can still upgrade using database attach method
33. Lessons Learned Communicate upgrade schedule
Determine plan or policies:
Ghosting during upgrade
Upgrade priorities exceptions process
Upgrade roll-backs exceptions process
Determine whether to offer site previews
Choose gradual upgrade redirection URL wisely
Review and Retain upgrade logs after each upgrade
34. Troubleshooting Tips Prescan logs
%temp%
Prescan.log
Prescan Report and Summary
Log files
Upgrade and Server logs
Logs are in: \Program Files\Common Files\Microsoft Shared\Web Server Extensions\12\Logs
Event Viewer
Psconfig command-line utility
35. Partner: CorasWorks Migrator Reghost multiple sites at once
Migrate Customizations and web parts to sites post upgrade
Helps you add layouts, master pages, web parts, en masse
36. Partner: Echo Helps you quickly roll out customizations and settings and permissions across your farm with no site collection boundaries
37. Partner: AvePoint DocAve Used to connect to 2003 and move content to 2007 without dependencies on customizations. Quickly and Easily move your lists and libraries into a clean slate (out of box site definitions).
38. Summary Use In-Place for Development Environments
Use Gradual for Staging your Customizations
Use Content DB Migration to move to a new architecture and hardware
Prepare, plan and test your customizations!!
Learn how to troubleshoot prescan and upgrade logs
39. References Upgrade Documentation
http://technet2.microsoft.com/Office/en-us/library/396c85d9-4b86-484e-9cc5-f6c4d725c5781033.mspx?mfr=true
Migration and Upgrade Information for SharePoint Developers
http://msdn2.microsoft.com/en-us/office/aa905505.aspx
Upgrade Toolkit for Windows SharePoint Services Sites and Templates Guide
http://www.microsoft.com/technet/solutionaccelerators/collaboration/default.mspx
Upgrade on WSS SDK
http://msdn2.microsoft.com/en-us/library/ms460185.aspx
IT Pro Content
http://www.microsoft.com/technet/prodtechnol/office/sharepoint/default.mspx
SharePoint Technical Library on TechNet
http://technet2.microsoft.com/Office/en-us/library/3e3b8737-c6a3-4e2c-a35f-f0095d952b781033.mspx
Conferences (SharePoint Conference 2006, TechEd 2006)
Models, Scenarios and Flowchart
http://officebeta.iponet.net/en-us/help/HA101639821033.aspx?pid=CL100605171033
HotFixes
Description of a new command-line operation that you can use to repair content databases in Windows SharePoint Services http://support.microsoft.com/kb/918744
Description of a new command-line operation that is available for the Spsadm.exe command line tool that you can use to clean up orphaned items in the configuration database in SharePoint Portal Server 2003 http://support.microsoft.com/kb/918742/
40. References Supportability
2003 Best Practices to ensure upgradeability http://msdn2.microsoft.com/en-us/library/ms916859.aspx
KB Article on Site Defn supportability in 2003 http://support.microsoft.com/Default.aspx?id=898631
Supported and unsupported scenarios for working with custom site definitions and custom area definitions in Windows SharePoint Services and in SharePoint Portal Server 2003 http://support.microsoft.com/kb/898631/en-us
Community Tools
SharePoint Configuration Analyzer http://www.microsoft.com/downloads/details.aspx?FamilyID=918f8c18-89dc-4b47-82ca-34b393ea70e1&DisplayLang=en
SharePoint Utility http://www.microsoft.com/sharepoint/downloads/components/detail.asp?a1=724
SPReport http://workspaces.gotdotnet.com/spreports
Managing SharePoint Products and Technologies Performance at Microsoft http://www.microsoft.com/technet/itshowcase/content/spsperfnote.mspx#ETKAE
Microsoft SQL Server Report Pack for Microsoft Office SharePoint Portal Server 2003 http://www.microsoft.com/downloads/details.aspx?FamilyID=49159368-544b-4b09-8eed-4844b4e33d3d&DisplayLang=en
Blogs
Resources and Recommendations for Upgrading Site Definitions and Site Templates http://blogs.msdn.com/joelo/archive/2007/01/03/resources-and-recommendations-for-upgrading-site-definitions-and-site-templates.aspx
Upgrade Content IT Pros may not have seen http://blogs.msdn.com/joelo/archive/2006/12/06/upgrade-content-it-pros-may-not-have-seen.aspx
Other Upgrade Topics from Joels Blog http://blogs.msdn.com/joelo/archive/tags/Upgrade/default.aspx
41. Custom Site Definitions 2007 custom site definition is required or sites in Compatibility mode
Upgrade your custom site definitions and page templates
Create and test new site definition and features
Create upgrade definition to map 2003 to 2007
Deploy mapping file & 2007 site definition
Can be done post-upgrade using command line
43. Upgrade Definitions Upgrade files deployed to \12\config\upgrade
WSSUpgrade.xml
SPSUpgradePremium.xml
Upgrade Definition File Schema
Config
WebTemplate
Lists
List
Source
Files
File
AppliedSiteFeatures
Feature
AppliedWebFeatures
Feature
44. Upgrading Site Definitions Not heavily customized site definition
Example: Add custom list, modified Default.aspx
Create new v3 site definition and re-apply customizations
Recommended approach
Heavily customized site definition
Modify v2 site definitions to work in v3
ASPX Pages must contain Web Part Manager or use Master Pages
<WebPartPages:SPWebPartManager id="m" runat="Server" />
Onet.xml contains $Resources
Remove base types, standard lists, deprecated list templates
Map document templates to v3 document templates
Replace List Templates with Feature references
Replace Form and View Pages with \pages\form.aspx and "pages\viewpage.aspx
SPTool from SharePoint Toolkit, http://spplatform/toolkit
45. Custom Site Templates Locate .stp file
Determine which site definition it is based on
Determine whether it is customize/unghosted
Upgrade Toolkit for Windows SharePoint Services Sites and Templates Guide
Steps
In 2003, create a site using the site template (.stp)
Install 2007 and upgrade site
In 2007, revert to site definition and reapply changes
Package the site into site template
Test by creating new sites using 2007 site template
46. Custom Web Parts Most will work post-upgrade
Test in WSS 2003 SP2 with ASP.NET 2.0
Must re-build custom parts if you used ASP.Net 1.1 obfuscation tools
Must re-deploy web parts if
Moving to a new server farm (Content DB Migration)
Web part in the \bin (Gradual Upgrade)
Deploying web parts
stsadm o addwppack
47. FrontPage Customizations Important consideration: keep customizations or move to 2007
Custom pages kept by default during upgrade
Be aware: customized pages do not match rest of site
Reset to Site Definition
Returns page to layout in site definition
Option exists to reset all pages during Gradual upgrade
Available in site settings or within SharePoint Designer
48. Preparing for Upgrade Investigate and Prepare your content
Large site collection and database sizes
Tools for analyzing your environment
SharePoint Utility, SharePoint Configuration Analyzer, SPReport
Backup, backup, backup
Run Pre-Scan tool is required
Comes with the product in \bin , available as download
Reports common issues that needs to be addressed
Updates WSS lists so they can be upgraded
Lists all custom site definitions used
49. Running Prescan.exe prescan.exe /c preupgradescanconfig.xml /all
PreScan Log and Summary created in \%temp%\
52. Pre-Scan Common Issues Site/List not scanned error at the end of the log
Solution: Post SP2 Hotfix
UpdateListSchemaInAllWebs() Method not found
Solution: Install SP2
Various WSS OM method failure from SPRequest object with File not found error
Solution: Install custom site definitions
Virtual server is not in a ready state
Solution: Run it against v2 Virtual server
53. Orphaned Objects WSS Content DB Orphans
Post SP2 Hotfix, KB 918743 and KB 918744
stsadm -o databaserepair -url http://WSSSite -databasename DatabaseName
stsadm -o databaserepair -url http://WSSSite -databasename DatabaseName deletecorruption
SPS Config DB orphans
Post SP2 Hotfix, KB 918742
spsadm o repairorphans http://PortalSite
WSS Config DB orphans
Remove and then reattach the content databases on the virtual server
54. For ITPros: (RTM Exam)
70-631 - Windows SharePoint Services 3.0 - Configuring
70-630 - Office SharePoint Server 2007 - Configuring
For Developers: (Beta Exam)
70-541 - Microsoft Windows SharePoint Services 3.0 - Application Development
70-542 - Microsoft Office SharePoint Server 2007 - Application Development
All 4 exams are available TODAY in the Learning Testing Center on the First Floor of the WSCC DON'T DELAY TAKE 'EM TODAY!!!Be one of the first to pass the NEW MCTS Exams!!!
55. Appendix
57. Post-Upgrade Delete un-needed 2003 sites
Needed for Gradual Upgrade & DB Attach
Finalize Upgrade
Required for Gradual & In-Place Upgrade
Removes temporary data maintained about 2003 environment
Post-upgrade data migration
Un-install 2003 environment
58. Effect of Upgrades:Low Customization Site (Original)
59. Effect of Upgrades:Low Customization Site (Upgraded)
60. Effect of Upgrades:Low Customization Site (Re-Ghosted)
61. Effect of Upgrades:High Customization Site (Original)
62. Effect of Upgrades:High Customization Site (Upgraded)
63. Effect of Upgrades:High Customization Site (Re-Ghosted)
64. Effect of Upgrades:Themed Site (Original)
65. Effect of Upgrades:Themed Site (Upgraded)
66. Reasons for Upgrade Consolidation of Services and Infrastructure
Less number of Databases and Servers
Shared Services
Operational Needs
Full fidelity Data Protection and Recovery
Site ownership management
Built-in ability to remove site customizations
Platform Upgrade
64 bit
SQL Server 2005
ASP.NET 2.0/3.0
67. Reasons for Upgrade New Business Scenarios/Requirements
Content Management
Business Intelligence
Business Data Integration
Improved Experience
Security-trimmed UI
Search
Workflow
Improved Extensibility
68. Planning for Upgrade Review your environment and business scenarios
Profile your usage scenarios
Review customizations; requirements and design documentations
Determine how to handle them
Determine upgrade approach
Understand upgrade process
Prototype different options with subset of your data
69. Choose if resetting files to template version
Can change selection with each group of sites upgraded
Select first group of sites to upgrade
Must include the root site of the domain in first group
Note storage (number of MB) to be upgraded
During upgrade, redirect to 2003 URL is removed
2007 site is now live
Automatic - no admin action needed
Review log files after each upgrade group
Tip: Upgrade duration is in logs. Number of MB / duration is good approximation for subsequent upgrade durations
Repeat steps 1-3 for all sites
Command line available to automate Gradual UpgradeContent Upgrade
70. Shared Services configuration
For each master portal
Configure search in 2007/O12
Configure profile/audience sync in 2007/O12
Review Managed Properties of user profiles in 2007/O12
For each child portal
Modify start addresses in 2003/O11 master portal to prevent double-crawling Gradual Upgrade Shared Services Considerations
71. Gradual UpgradeShared Services Considerations Search Services
Two crawls running at the same time
Keywords, site-level scopes only available for upgraded 2007 sites
User Profiles/Audiences
Changes in 2007 pushed down to 2003 does not include new properties and audience rules
Review Managed Properties list for people search scope
Review upgraded audiences consider deleting those built on DLs/SGs as those groups can be used directly
72. Content Database Migration
73. Content DB Migration Shared Services
V2/O11 not affected
Parent continues to provide services to v2 sites
Child sites retain user experience
User profile/audience data not synced between v2, v3
Two profiles, two MySites, etc may confuse Applications
Most search data not upgraded
Re-create search settings other than custom search properties
74. Search Services
Configure on the 2007 Parent farm
Avoid double-crawl as configuring your content sources
User Profiles/Audiences
Data not synchronized between 2003 and 2007
Review Managed Properties list for people search scope
Review upgraded audiences consider deleting those built on DLs/SGs as those groups can be used directly
My Sites Two of them
75. Additional Considerations Search Upgrade
In-Place and Gradual: some settings are not upgraded
Index files, Scopes, Search alerts, Any filters, word breakers and thesaurus files
DBAttach: none of the search settings are upgraded since search settings are on the registry
Configure search settings on the new farm
Site Directory (area, list, sites)
2003: Area with Directory List, Site collections
2007: Subsite with Directory List, Site collections, Subsites under /SiteDirectory
76. Summary and Tradeoffs
