  1. An Ultra-Wideband CMOS Low Noise Amplifier for 3–5-GHz UWB System IEEE JOURNAL OF SOLID-STATE CIRCUITS, VOL. 40, NO. 2, FEBRUARY 2005 指導教授 : 林志明 教授 學生 : 黃世一

  2. Outline • Abstract • Introduction • Design of wideband amplifier • Amplifier design and measurement results • Conclusion • References

  3. Abstract • An UWB CMOS LNA combines a narrowband LNA with a resistive shunt-feedback • Wideband input matching and small NF degradation by Q-factor • 0.18μm CMOS technology for 3.1-5GHz UWB system • BW 2-4.6 GHz, NFmin 2.3dB, gain 9.8dB • IP3 -7dBm, Pd 12.6mW

  4. Introduction • UWB system : 3.1–10.6 GHz low-frequency band : 3.1–5 GHz high-frequency band: 6–10.6 GHz • CMOS in wideband amplifiers with two different topologies • Distributed amplifiers • Resistive shunt-feedback-based amplifiers

  5. Recently, a bandpass LC filter at the input of the cascode low noise amplifier (LNA) for wideband input matching • A new low power, low noise, and wideband amplifier in 3.1-5 GHz UWB system

  6. Design of wideband amplifiernarrowband LNA Input match

  7. RLC series resonant circuit ωT : cutoff frequency ω0:resonant frequency

  8. UWB LNA topology Shunt packing inductor Shunt-feedback Cf , C1, C2 : ac coupling

  9. Amplifier design and measurement results

  10. Conclusion

  11. References • Chang-Wan Kim; Min-Suk Kang; Phan Tuan Anh; Hoon-Tae Kim; Sang-Gug Lee;Solid-State Circuits, IEEE Journal of Volume 40, Issue 2, Feb. 2005 Page(s):544 - 547 Digital Object Identifier 10.1109/JSSC.2004.840951

  12. Thank You For Your Attention !
