  1. General, Organic, and Biochemistry, 7e Bettelheim, Brown, and March

  2. Chapter 12 Alkenes and Cycloalkenes

  3. Alkenes and Alkynes • Alkene: a hydrocarbon that contains one or more carbon-carbon double bonds • ethylene is the simplest alkene • Alkyne: a hydrocarbon that contains one or more carbon-carbon triple bonds • acetylene is the simplest alkyne

  4. Alkenes • Structure: • the VSEPR model predicts bond angles of 120° about each carbon of a double bond • in ethylene, the actual angles are close to 120° • in substituted alkenes, angles about each carbon of the double bond may be greater than 120° because of repulsion of alkyl groups bonded to the double bond

  5. Alkenes • Cis-trans isomerism • because of restricted rotation about a carbon-carbon double bond, an alkene with two different groups on each carbon of the double bond shows cis-trans isomerism

  6. Alkenes - IUPAC Names • To name an alkene • the parent name is that of the longest chain that contains the C=C • number the chain from the end that gives the lower numbers to the carbons of the C=C • locate the C=C by the number of its first carbon • use the ending -ene to show the presence of the C=C • branched-chain alkenes are named in a manner similar to alkanes; substituted groups are located and named

  7. Alkenes - IUPAC Names • Examples

  8. Alkynes - IUPAC Names • follow the same rules as for alkenes, but use the ending -yne to show the presence of the triple bond

  9. Common Names • Common names are still used for some alkenes and alkynes, particularly those of low molecular weight

  10. Cycloalkenes • To name a cycloalkene • number the carbon atoms of the ring double bond 1 and 2 in the direction that gives the lower number to the substituent encountered first • number and list substituents in alphabetical order

  11. Dienes, Trienes, Polyenes • alkenes that contain more than one double bond are named as alkadienes, alkatrienes, and so on • those that contain several double bonds are referred to more generally as polyenes (Greek: poly, many)

  12. Physical Properties • alkenes and alkynes are nonpolar compounds • the only attractive forces between their molecules are London dispersion forces • their physical properties are similar to those of alkanes with the same carbon skeletons • alkenes and alkynes are insoluble in water but soluble in one another and in nonpolar organic liquids • alkenes and alkynes that are liquid or solid at room temperature have densities less than 1 g/mL; they float on water

  13. Terpenes • Terpene: a compound whose carbon skeleton can be divided into five-carbon units identical with the carbon skeleton of isoprene • Terpenes illustrate an important principle of the molecular logic of living systems • in building large molecules, small subunits are bonded together by a series of enzyme-catalyzed reactions and then chemically modified by additional enzyme-catalyzed reactions

  14. Terpenes

  15. Reactions of Alkenes • The most common reaction is addition

  16. Reactions of Alkenes • Most alkene addition reactions are exothermic • the products are more stable (lower in energy) than the reactants • just because they are exothermic doesn’t mean that they occur rapidly • reaction rate depends on activation energy • many alkene addition reactions require a catalyst

  17. Addition of HX • Addition of HX (HCl, HBr, or HI) to an alkene gives a haloalkane • H adds to one carbon of the C=C and X to the other • reaction is regioselective • Markovnikov’s rule: H adds to the less substituted carbon and X to the more substituted carbon

  18. Addition of HX • Chemists account for the addition of HX to an alkene by a two-step reaction mechanism • we use curved arrows to show the repositioning of electron pairs during a chemical reaction • the tail of an arrow shows the origin of the electron pair (either on an atom of in a bond) • the head of the arrow shows its new position • curved arrows show us which bonds break and which new ones form

  19. Addition of HCl to 2 Butene • Step 1: • reaction of the carbon-carbon double bond with H+ gives a secondary carbocation intermediate • Step 2: • reaction of the carbocation intermediate with chloride ion completes the addition

  20. Addition of H2O • Addition of water is called hydration • hydration is acid catalyzed, most commonly by H2SO4 • hydration follows Markovnikov’s rule; H adds to the less substituted carbon and OH adds to the more substituted carbon

  21. Addition of H2O • Step 1: • Step 2: • Step 3:

  22. Addition of Cl2 and Br2 • Addition takes place readily at room temperature • reaction is generally carried out using pure reagents, or mixing them in a nonreactive organic solvent • addition of Br2 is a useful qualitative test for the presence of a carbon-carbon double bond • Br2 has a deep red color; dibromoalkanes are colorless

  23. Addition of H2 - Reduction • Virtually all alkenes add H2 in the presence of a transition metal catalyst, commonly Pd, Pt, or Ni

  24. Polymerization • From the perspective of the organic chemical industry, the single most important reaction of alkenes is polymerization • polymer: Greek: poly, many and meros, part • monomer: Greek: mono, single and meros, part

  25. Polymerization • show the structure of a polymer by placing parentheses around the repeating monomer unit • place a subscript, n, outside the parentheses to indicate that this unit repeats n times • the structure of a polymer chain can be reproduced by repeating the enclosed structure in both directions • following a section of polypropene (polypropylene)

  26. Polyethylene • Low-density polyethylene (LDPE) • a highly branched polymer; polymer chains do not pack well and London dispersion forces between them are weak • softens and melts above 115°C • approximately 65% used for the production of films for packaging and for trash bags • High-density polyethylene (HDPE) • only minimal chain branching; chains pack well and London dispersion forces between then are strong • has higher melting point than LDPE and is stronger • can be blow molded to squeezable jugs and bottles

  27. Codes for Plastics

  28. Chapter 12 End Chapter 12
