cisco unified access cisco mobility vision strategy and portfolio

Cisco Unified AccessCisco Mobility Vision, Strategy, and Portfolio

JeevanPatil

Senior Product Line Manager

Wireless Networking Group

agenda
Agenda

1

Cisco’s Mobility Vision

2

Mobility Differentiators

3

Mobility Roadmap

4

Controller and Access Point Portfolio

5

Mobility Services Portfolio

cisco mobility innovation leadership led every major change in mobility wlan for 15 years
Cisco Mobility Innovation LeadershipLed Every Major Change in Mobility/WLAN for 15 Years

802.11ac Wave 2

802.11ad

Hotspot 2.0

Local Services Discovery

IPv6

802.11ac

Virtualization

App visibility

Unified Policy and Network Management

802.11n and Spectrum Intelligence

Controller and Coordinated Access Points

Autonomous Access Points

RF resiliency, WLAN Scale, High Client Density

Standards Leadership (IEEE, WFA, WBA)

AP Mechanical Design

2015

1997

Wi-Fi Requirements

cisco mobility differentiators
Cisco Mobility Differentiators

Policy and Network Management

Mobility/RF Innovation

Predictability and Reliability

  • Award Wining Design

Purpose-Built Wi-Fi Chipset with 4x4 MIMO, with robust platform No Open Vents

Who? What? When? Where? How?

  • ClientLink

Best-in-class performance to a/g/n clients

Chip level proactive and automatic interference mitigation

  • CleanAir

ISE

Control

First to introduce 802.11r, 802.11wand 802.11ac

  • Standards
  • VideoStream

Optimized multicast to unicast

Stateful fail-over

Sub second failover to hot standby controller

  • AVC

Classification andpolicies on 1000+ Apps

Prime Infrastructure

Visibility

MSE and Thinksmart

Analytics that aid business decisions

Meaningful Interaction with your customers

cisco cleanair technology industry s first chip level proactive interference mitigation
Cisco CleanAir TechnologyIndustry’s First Chip Level Proactive interference mitigation
  • CleanAir Radio ASIC
  • Detect Wi-Fi and non-Wi-Fi interference sources
  • Assess impact to Wi-Fi performance
  • Proactively change channels when interference occurs
  • Monitor air quality

100

20

63

97

35

90

Detect | Classify | Locate | Mitigate

  • Unique alert per interference, not per AP
  • Fully integrated into Radio Resource Monitoring(RRM) and with location analytics
  • Detects Off-channel interference, radar jammer
  • 3rd security monitoring module offers a cost-effective management of full spectrum
cisco clientlink 2 0 technology advanced beamforming improves w ireless c lient p erformance
Cisco ClientLink 2.0 TechnologyAdvanced BeamForming improves wireless client performance

AFTER

Beam Directed Towards Client Resulting in a Consistent Experience and Better Performance

BEFORE

Manual RF Management

Beacon Rate

6 Mbps

6 Mbps

65 Mbps

65 Mbps

150 Mbps

150 Mbps

300 Mbps

300 Mbps

Connection Rate

450 Mbps

450 Mbps

  • Highest data-rates for 802.11a/g/11n clients over the coverage area leads to:
    • Lower coverage holes
    • Transferring data at higher throughput conserves client battery life of smartphone
  • 100+ clients supported per radio in hardware
cisco videostream technology wired like video delivery over wireless
Cisco VideoStream TechnologyWired-Like Video Delivery over Wireless

BEFORE

Manual RF Management

AFTER

Dynamic RF Management

GlobalEnterprise

CEOMeeting

CEOMeeting

SportsEvent

SportsEvent

M&ANegotiation

M&ANegotiation

  • Cisco supports 40+ Videostream sessions per Access Point 2600, 3600 (2x competition)
  • Tested for 30x Less Bandwidth Consumed
ap3600 investment protection 802 11ac wave 1 module

Availability in1HCY13

AP3600: Investment Protection802.11ac Wave 1 Module
  • Field upgradable 802.11ac module
    • 5 GHz radio module, 802.11ac Wave 1
    • 1.3 Gbps PHY/~900 Mbps MAC (throughput)
    • Three spatial streams, 80 MHz, 256 QAM
  • AP3600 maintains dual-band support 2.4 and 5 GHz
    • Supporting b/g/n on 2.4 GHz base radio, a/n on 5 GHz base radio, and AC on 5 GHz module radio
    • CleanAir and ClientLink 2.0 maintained
  • 15.4W < Power requirement with the 802.11ac module installed < 20W
slide9

802.11ac Dx.0

ratified

802.11ac D3.0

balloted

Q2

Q3

Q4

Q1

Q2

Q3

Q4

Q1

Q2

Q3

Q4

Q1

Q2

Q3

Q4

2011

2012

2013

2014

80 MHz

256QAM

1-3 SS

Estimates only

Wave 1certified

160 MHz

1-4 SS

MU-MIMO?

Wave 2certified

9

cisco aironet 802 11n 802 11ac access point portfolio
Cisco Aironet 802.11n + 802.11ac Access Point Portfolio

Bestin Class

Mission

Critical

3600

Enterprise

Ready

2600

  • High Client Density
  • HD Video/VDI
  • Investment Protection
  • 11ac Migration
  • ComprehensiveSecurity

TELEWORKERReady

  • Any Device / BYOD Optimized
  • Client Scalability
  • RF Interference Mitigation

1600

600

  • Enterprise-class Performance
  • Voice/Video/Multimedia
  • Basic Connectivity
  • Deployment Flexibility
  • SP WiFi, Emerging, Teleworker
wireless controller redundancy no ssid outage with stateful switch over
Wireless Controller RedundancyNo SSID outage with stateful switch over

New in 7.3

5500, WiSM2, 7500, 8500 Series

Backup Controller

(Requires L2 Adj.)

5508

$20,000

redundancy ports connected via standard ethernet

WiSM2

$25,000

Flex7500

$40,000

Active WLC

Hot-Standby WLC

8500

$60,000

2500

(7.4 Release) $2,000

  • 1:1 wireless stateful failover capability in appliance and integrated controllers
  • SSID is always beaconing (even after primary controller is down)
  • Subsecond WLAN network convergence
cisco s application visibility control
Cisco’s Application Visibility & Control

New in 7.4

Identify standard ports, L7 Deep Packet Inspection and Heuristics

AFTER

Network Based Application Recognition - NBAR2Deep Packet Inspection and App ID

BEFORE

Application View & Control based on Firewall sessions

Wireless LAN Controller

Visibility to the port level interaction but not the applications running within the port

Netflix = 50%

YouTube = 15%

WebEx = 10%

Citrix = 9%

exchange= 8%

HTTP = 75%

SMTP = 15%

FTP = 2%

Telnet = 1%

SNMP = 3%

Traffic

NBAR2 LIBRARY

Deep Packet inspection

First

Generation

Firewall

POLICY

Packet Mark and Drop

Netflow v9 export

  • Classify 1000+ applications with sub-classification within applications: e.g. Lync– desktop share, video/voice, file transfer
  • Apply Granular policies - Per SSID, Device, Campus, Building, Floor
  • Real-time troubleshooting on the Wireless LAN Controller
  • Wired-wireless consistent export to standard netflow collectors
controller product portfolio
Controller Product Portfolio

New

Multi-Architecture

Capable

8500

(SP Wi-Fi)

WiSM-2 (Campus)

5500

(Campus)

Features/Performance

2500

(Branch)

SRE–WLCM2

FlexConnect

New

Flex 7500

VirtualController

Scale (Number of Clients, APs)

Roadmap is highly confidential and reflects current plan. Subject to change without notice

mobility services engine mse overview
Mobility Services Engine (MSE) Overview

Advanced Spectrum Capability

Indoor Location / Context-Aware

  • Real time location tracking
  • Tracking probing & associated clients, RF tags & wired endpoints
  • Geo fencing / Zone based alerts
  • Location Analytics
  • System wide Interferer details
  • Event correlation
  • Visualization of interferer zone of impact
  • Interferer notification
  • Track & Trace interferers & Layer 1 threats

Mobile Concierge*

Wireless Intrusion Prevention

Physical &

Virtual Appliance

MSE tracks up to

50,000 endpoints &

supports 10,000

Monitor Mode

or ELM AP

  • Detection & Mitigation of security penetration attacks
  • Detection & Mitigation of denial of service attacks
  • Capability supported in Monitor Mode & data serving AP (Enhanced Local Mode -ELM)
  • Detecting Presence
  • Delivering location based services

* Roadmap

slide15

Analytics that aid business decisions

New in 7.3

Which area did people spend time at?

Peak times in the store? New or repeat customers?

Most frequently used paths in the venue

% of shoppers who walk by without entering

fy13 roadmap wng wlan infrastructure

Cisco Confidential—NDA Only

In Planning

Committed

FY13 Roadmap - WNGWLAN Infrastructure

September 2012

May 2012

Q1 CY13

Q2 CY13

Release

7.3

7.2MR1

7.4

8.0

AP1600

802.11n G2

AP 2600

802.11n G2

AP3600

11ac module

Outdoor AP Internal Antenna

AP3600

Security Module

Outdoor AP

Uni Band Antenna

Mid-Market

1 Box Solution

WLC 8500

Target customer - SP

Application visibility and control (AVC)

Outdoor AP Honeywell integration

IPv6 infrastructure

Profiling and Policy on WLC

Virtual Controller

Bonjour Gateway

802.11r

L2 Fast Roaming

Scale Flex7500

6K APs

HA – Client SSO

Unified Access

WLAN Infrastructure

Voice Enterprise Certification**

HA SSO over any L2 connection

HA - AP SSO

HA Licensing

Scale WLC 2500

ISE -Flex integration

Flex / Local Mode parity with ISE

FlexConnect Split Tunneling

AP-based firewall

HA Licensing, N:1

802.11r – Flex Modes

802.11w

Mgmt Frame Protection

LAG on Flex7500, WLC 8500, WLC 2500

Bi-directional rate-limiting

Local andFlexConnect support on RAP

PMIPv6 – AP-Based

Guest Anchor on WLC2500

Voice/Video:

11n CAC

FIPS, CC, UCAPL

PMIPv6 on WLC

**Voice Enterprise Certification targeted on a special release – FCS beyond 7.4

fy13 roadmap wng mobility services

Cisco Confidential—NDA Only

In Planning

Committed

FY13 Roadmap - WNGMobility Services

September 2012

May 2012

Q1 CY13

Q2 CY13

S/WRelease

7.3

7.2MR1

7.4

8.0

Improved location accuracy for CleanAir

High Availability

aWIPS Prevention

Mobile Concierge

Unified Access – WLAN Infrastructure

Location Analytics II

Virtual Appliance

MSE 3355 Scaling

Location Analytics I

Scalability Improvements

FIPS, CC, UCaPL

Automated Switched port tracing

MSE

ELM Signature Parity

Global Forensics

Location Support for FLEX

Better Rogue Classification, Containment, Detection

AP 3600 Security Module

Rogue Contain Enhancements II

Rogue Detection Enhancements

aWIPS Rogue Contain Enhancements

Better Attack Mitigation for aWIPS (Location)

Channel Scanning Optimization

WiFi Direct detection & Classification

New Signatures

PI 2.1 (7.4 Support)

PI 1.2 (7.3 Support)

NCS 1.1 (7.2, 7.2 MR1)

PI 2.2 (8.0 Support)

PI releases

AVC, Day 1 Device Support

Northbound REST API

Branch Router Mgmt (ISR / ASR)

Prime

3rd Party Support

IPv6 Support

Mobile Concierge Support

IPv6 Support

Prime 360 Experience

Guest Services

Wired Config & Image Management

Rougue Rules Customization

FIPS, CC, DoD Certification

ISR / ASR Mgmt Integration

Reporting Enhancements

Next Gen GUI

FIPS Certification Support

One Box Solution
