Presentation Transcript

  1. RAY TRACING & WAVEFRONT ANALYSIS USING THE TRACEY SYSTEM Donald R. Sanders, M.D., Ph.D. Center For Clinical Research

  2. 20/10 UNCORRECTED PATIENT

  3. 20/10 UNCORRECTED PATIENT P S F Retinal Spot

  4. 20/10 UNCORRECTED PATIENT

  5. 20/10 UNCORRECTED PATIENTRef +0.04 + 0.16 X 110 Total RMS = 0.068m Lower Higher

  6. Astigmatism Defocus (Refraction) 2nd Order Higher 3rd Order 4th Order 5th Order

  7. Breakdown of Zernike Terms Coefficient value (microns) -0.5 0 0.5 1 1.5 2 1 2 astig. 3 2nd order defocus 4 astig. 5 trefoil 6 3rd order coma 7 coma 8 Zernike term trefoil 9 10 11 4th order spherical aberration 12 13 14 15 16 5th order 17 18 19 20

  8. Root Mean Square …… trefoil term defocus term astigmatism term astigmatism term

  9. GROSS APPROXIMATIONTotal RMS Vs. Visual Acuity 1.0m = 20/20 - 20/25 0.5m = 20/15 0.25m = 20/10

  10. COMPONENTS OF TOTAL RMS Lower Order Aberrations Defocus (Sphere) Astigmatism (Cylinder) Plus Higher Order Aberrations

  11. 20/10 VISIONRef -0.14 + 0.39 X 168 Total RMS = 0.204mP S F

  12. LARGELY LOWER ORDER ABERRATIONS P S F Retinal Spot

  13. 99% OF RMS VALUE IS LOWER ORDER ABERRATIONS(Refractive Error) Lower Higher

  14. AFTER SUBTRACTING LOWER ORDER ABERRATIONS P S F Retinal Spot

  15. REFRACTIVE ERROR P S F “UCVA” “BCVA” All Aberrations Higher Order Only

  16. REFRACTIVE ERROR “UCVA” “BCVA” All Aberrations Higher Order Only

  17. REFRACTIVE ERROR Retinal Spot “UCVA” “BCVA” All Aberrations Higher Order Only

  18. CORNEAL BIRTH TRAUMA P S F “UCVA” “BCVA” All Aberrations Higher Order Only

  19. CORNEAL BIRTH TRAUMA Retinal Spot “UCVA” “BCVA” All Aberrations Higher Order Only

  20. CORNEAL BIRTH TRAUMA “UCVA” “BCVA” All Aberrations Higher Order Only

  21. COMMON SIGNIFICANT HIGHER ORDER ABERRATIONS Trefoil Coma Spherical Aberration

  22. (T.M.) POST LASIK Complains Of Night Glare6mm Scan (Undilated)

  23. PATIENT T.M. (OD)6 mm Scan – P S F “UCVA” “BCVA” All Aberrations Higher Order Only

  24. PATIENT T.M. (OD)6 mm Scan – Retinal Spot “UCVA” “BCVA” All Aberrations Higher Order Only

  25. PATIENT T.M. (OD)6 mm Scan “UCVA” “BCVA” All Aberrations Higher Order Only

  26. PATIENT T. M. (OD)Decentered Excimer COMA

  27. PATIENT T. M. (OD) Vertical Coma

  28. PATIENT T.M. (OD)EFFECT OF SCAN DIAMETER (PUPIL SIZE) ON PSFHigher Order Aberrations Only 6 mm 4 mm

  29. PATIENT T. M. (OS)6.5mm Scan – P S F UCVA (All Aberrations) BCVA (Higher Order Only)

  30. COMA SPHERICAL

  31. HORIZONTAL COMA SPHERICAL ABERRATION

  32. PATIENT T.M.NIGHT MYOPIA DUE TO SPHERICAL ABERRATION 2.49 OS Amount Of Myopia (D) 1.99 1.66 0.85 Pupil Size (Undilated)

  33. PATIENT T. M. (OS)Night Myopia Due To Spherical Aberration 4 mm 5 mm 6 mm 6.5 mm

  34. PATIENT T. M. (OS) – P S FNight Myopia Due To Spherical Aberration 4 mm 5 mm 6 mm 6.5 mm

  35. SUMMARY PATIENT T.M.Large Pupils In Dim Light OD Vertical Coma (Decentration) With Mild Spherical Aberration OS Horizontal Coma(Decentration) + Spherical Aberration

  36. PATIENT S. P. Complains Of Severe Night Glare6.5mm Scan Pupil is 7.0 –7.5mm Undilated

  37. PATIENT S. P. (OD)Severe Night Glare PUPIL SIZE 4 mm 4.5 mm RMS = 0.261 RMS = 0.407 6.0 mm 6.5 mm RMS = 1.1 RMS = 1.83

  38. PATIENT S. P. (OD)Severe Night Glare Pupil Size Higher Order Aberration Only 4mm 4.5mm RMS = 0.166 RMS = 0.346 6.0mm 6.5mm RMS = 0.656 RMS = 1.83

  39. PATIENT S. P. (OD)Severe Night Glare 4 mm 6.0 mm Lower Higher

  40. PATIENT S. P. (OS)Complains Of Severe Night Glare 4.5 mm 5.5 mm 6.5 mm 6.0 mm

  41. PATIENT S. P. (OS)Complains Of Severe Night Glare 4.5 mm 6.5 mm NOTE: Scale Doubles

  42. PATIENT J. C.Most Higher Order Aberrations – Trefoil, Tetrafoil

  43. S/P RK SURGERY J. C. D. D.
