  1. Introducción a las Interfaces de entrada / salida

  2. Puerto de Salida Básico Registro (Latch) #CE CLK #WR #OE D0 D7 Q0 Q7 Bus de Datos del Sistema Salidas

  3. Sintesis en vhdl de un puerto de salida Entity Salida is port ( HCLK : in std_logic; RESET : in std_logic; CS : in std_logic; WR : in std_logic; D : in std_logic_vector (7 downto 0); --Bus datos es siempre entrada O : out std_logic_vector (7 downto 0) --Salidas al exterior ); end Salida;

  4. architecture B2 of Salida is begin process (HCLK, RESET) begin if RESET = '1' then O ( 7 downto 0 )<= "00000000"; else if HCLK = '1' and HCLK'event then -- Flanco de ascendente if CS = '0' then if WR = '0' then O (7 downto 0) <= D ( 7 downto 0 ); end if; end if; end if; end if; end process; end B2;

  5. Estimulo para test del puerto de salida

  6. Simulación – Puerto de salida

  7. Puerto de Entrada Básico Puerta de 3 estados (Transceiver) #CE #RD #OE O0 O7 I0 I7 Bus de Datos del Sistema Entradas

  8. Sintesis en vhdl de un puerto de entrada entity Entrada is port ( HCLK : in std_logic; RESET : in std_logic; CS : in std_logic; RD : in std_logic; D : out std_logic_vector (7 downto 0); -- Bus Datos es siempre salida I : in std_logic_vector (7 downto 0) -- Entradas externas ); end Entrada;

  9. architecture B2 of Entrada is Begin process (HCLK, RESET) Begin if RESET = '1' then D ( 7 downto 0 )<= "ZZZZZZZZ"; else if HCLK = '1' and HCLK'event then -- Flanco de ascendente if CS = '0' then -- Acceso al registro solo si CS es 0 if RD = '0' then D ( 7 downto 0 ) <= I (7 downto 0); else D ( 7 downto 0 ) <="ZZZZZZZZ"; -- Si RD esta en 1 el bus esta en "Z" end if; else D ( 7 downto 0 ) <="ZZZZZZZZ"; -- Si CS esta en 1 el bus esta en "Z" end if; end if; end if; end process; end B2;

  10. Estimulo – Puerto de entrada

  11. Simulación – Puerto de entrada

  12. 8. 8. 8. 8. Aplicación Puerto “A” Q7 CE1 WL CLK Excitación (Ánodos) D7 … D0 OE Q0 Puerto “B” CE1 WH CLK K3 K2 K1 K0 D15 … D8 Q3 Q0 OE Habilitaciones (Cátodos)

  13. a f b g e c p d

  14. ÁNODOS CÁTODO COMÚN ÁNODOS

  15. Vcc a b c d e f g p CÁTODO COMÚN ÁNODOS

  16. ÁNODOS 5. 8. 8. 8. KHH KMH KML KLL ULN2003 1 0 0 0

  17. ÁNODOS 8. 8. 3. 8. KMH KML KLL ULN2003 0 1 0 0

  18. ÁNODOS 8. 9. 8. 8. KMH KML KLL ULN2003 0 0 1 0

  19. ÁNODOS 8. 8. 8. 6. KMH KML KLL ULN2003 0 0 0 1

  20. ;Subrutina DISP ;Variables utilizadas: ;STATUS : Próximo dígito de Buffer que es necesario refrescar ;BUFFER : Tabla de 8 bytes que contiene los datos para el display y los códigos de habilitación correspondientes STATUS dw 0 BUFFER db 1, 1 ;LSD , 00000001 db 3, 2 ; , 00000010 db 5, 4 ; , 00000100 db 7, 8 ;MSD; 00001000 ;PORT_A : Etiqueta que especifica la dirección del puerto del display PORT_A equ XXXX

  21. ;Subrutina DISP ;Variables utilizadas: ;STATUS : Próximo dígito de Buffer que es necesario refrescar ;BUFFER : Tabla de 8 bytes que contiene los datos para el display y los códigos de habilitación correspondientes STATUS dw 0 BUFFER db 1, 1 ;LSD , 00000001 db 3, 2 ; , 00000010 db 5, 4 ; , 00000100 db 7, 8 ;MSD; 00001000 ;PORT_A : Etiqueta que especifica la dirección del puerto del display PORT_A equ XXXX 0 STATUS 0 OFFSET incrementa 1 BUFFER 1 = 00000001 3 2 = 00000010 5 4 = 00000100 7 8 =00001000

  22. ;SUB. DE REFRESCO------------ DISP PROC NEAR XOR AX,AX MOV DX, PORT_A OUT DX,AX ;APAGA DISPLAY MOV BX, STATUS ;BUSCA DATOS EN BUFFER MOV SI, OFFSET BUFFER MOV AX,(BX+SI) OUT DX,AX ;ENCIENDE DIGITO ADD BX, 2 ;APUNTA AL PROXIMO DIGITO EN MEMORIA AND BX, 7 MOV STATUS,BX RET

  23. ;SUB. DE REFRESCO------------ DISP PROC NEAR XOR AX,AX MOV DX, PORT_A OUT DX,AX ;APAGA DISPLAY MOV BX, STATUS ;BUSCA DATOS EN BUFFER MOV SI, OFFSET BUFFER MOV AX,(BX+SI) OUT DX,AX ;ENCIENDE DIGITO ADD BX, 2 ;APUNTA AL PROXIMO DIGITO EN MEMORIA AND BX, 7 MOV STATUS,BX RET

  24. ;SUB. DE REFRESCO------------ DISP PROC NEAR XOR AX,AX MOV DX, PORT_A OUT DX,AX ;APAGA DISPLAY MOV BX, STATUS ;BUSCA DATOS EN BUFFER MOV SI, OFFSET BUFFER MOV AX,(BX+SI) OUT DX,AX ;ENCIENDE DIGITO ADD BX, 2 ;APUNTA AL PROXIMO DIGITO EN MEMORIA AND BX, 7 MOV STATUS,BX RET OFFSET BUFFER 1 1 = 00000001 3 STATUS 2 = 00000010 5 4 = 00000100 7 8 =00001000

  25. ;SUB. DE REFRESCO------------ DISP PROC NEAR XOR AX,AX MOV DX, PORT_A OUT DX,AX ;APAGA DISPLAY MOV BX, STATUS ;BUSCA DATOS EN TRABLA MOV SI, OFFSET BUFFER MOV AX,(BX+SI) OUT DX,AX ;ENCIENDE DIGITO ADD BX, 2 ;APUNTA AL PROXIMO DIGITO EN MEMORIA AND BX, 7 MOV STATUS,BX RET

  26. ;SUB. DE REFRESCO------------ DISP PROC NEAR XOR AX,AX MOV DX, PORT_A OUT DX,AX ;APAGA DISPLAY MOV BX, STATUS ;BUSCA DATOS EN TRABLA MOV SI, OFFSET BUFFER MOV AX,(BX+SI) OUT DX,AX ;ENCIENDE DIGITO ADD BX, 2 ;APUNTA AL PROXIMO DIGITO EN MEMORIA AND BX, 7 MOV STATUS,BX RET

  27. ;SUB. DE REFRESCO------------ DISP PROC NEAR XOR AX,AX MOV DX, PORT_A OUT DX,AX ;APAGA DISPLAY MOV BX, STATUS ;BUSCA DATOS EN TRABLA MOV SI, OFFSET BUFFER MOV AX,(BX+SI) OUT DX,AX ;ENCIENDE DIGITO ADD BX, 2 ;APUNTA AL PROXIMO DIGITO EN MEMORIA AND BX, 7 MOV STATUS,BX RET

  28. Teclado C0 C1 Entradas C2 C3 F0 F1 Teclas Salidas F2 F3

  29. TECLADO 0 0 Entradas 0 0 0 1 Salidas 0 0

  30. TECLADO 0 1 Entradas 0 0 0 1 Salidas 0 0

  31. TECLADO 0 0 Entradas 0 0 0 1 Salidas 0 0

  32. TECLADO 0 0 Entradas 0 0 0 1 Salidas 0 0

  33. Teclado C0 C1 Entradas C2 C3 F0 F1 Teclas Salidas F2 F3

  34. 8. 8. 8. 8. Aplicación Q7 CE1 WL CLK Excitación (Ánodos) D7 … D0 OE Q0 CE1 WH CLK K3 K2 K1 K0 D15 … D8 Q3 Q0 OE Habilitaciones (Cátodos)

  35. Teclado C0 C1 Entradas C2 C3 Q0 Q1 Teclas Q2 Q3

  36. Teclado I0 I1 Entradas I2 I3 P U E R T O B Q0 Q1 Teclas Q2 Q3

  37. PUERTO_C Puerta de 3 estados CE OE1 RDL OE2 Entradas D0 D7 O0 O7 I0 I7

  38. Teclado I3 I2 I1 I0 I4 I5 I6 I7 Entradas PUERTO_C P U E R T O B Q0 Q1 Teclas Q2 Q3

  39. Subrutina SCAN : Variables utilizadas : TECLA : Código ultima tecla presionada TECLA db 0 ;SUB. DE EXPLORACION DE TECLADO SCAN PROC NEAR MOV DX, PORT_B IN AL, DX TEST AL, 0F0h JZ notec MOV TECLA, AL notec: RET

  40. Registros internos Síntesis en vhdl de un registro interno (sin líneas de entrada ni salida) entity Registro is port ( HCLK : in std_logic; RESET : in std_logic; CS : in std_logic; RD : in std_logic; WR : in std_logic; D : inout std_logic_vector (7 downto 0) -- Bus de datos es Entrada/Salida ); end Registro;

  41. architecture B2 of Registro is Begin process (HCLK, RESET) variable REGISTRO : std_logic_vector (7 downto 0) := "00000000"; Begin if RESET = '1' then D ( 7 downto 0 )<= "ZZZZZZZZ"; else if HCLK = '1' and HCLK'event then -- Flanco de ascendente if CS = '0' then -- Acceso al registro solo si CS es 0 if RD = '0' then D ( 7 downto 0 ) <= REGISTRO (7 downto 0); else D ( 7 downto 0 ) <="ZZZZZZZZ"; -- Si RD = 1, bus en "Z" if WR = '0' then REGISTRO (7 downto 0) := D ( 7 downto 0 ); end if; end if; else D ( 7 downto 0 ) <="ZZZZZZZZ"; -- Si CS = 1, bus en "Z" end if; end if; end if; end process; end B2;

  42. Estímulo para test de registro interno

  43. Salida del test de registro interno

  44. Generador PWM Contador Comparador HCLK CLK Q0 Q7 Salida PWM =1 si Registro > Contador Registro #CE #WR #OE CLK D0 D7 Q0 Q7 Bus de Datos del Sistema

  45. Síntesis VHDL de Generador PWM entity PWM is port ( HCLK : in std_logic; RESET : in std_logic; CS : in std_logic; RD : in std_logic; WR : in std_logic; D : inout std_logic_vector (7 downto 0); PWM : out std_logic ); end PWM;

  46. architecture B2 of PWM is Begin process (HCLK, RESET) variable REGISTRO : std_logic_vector (7 downto 0) := "00000000"; variable CICLO : std_logic_vector (7 downto 0) := "00000000"; variable CONTADOR : std_logic_vector (7 downto 0) := "00000000"; Begin if RESET = '1' then D ( 7 downto 0 )<= "ZZZZZZZZ"; PWM <= '0'; else if HCLK = '1' and HCLK'event then -- Flanco de ascendente if CS = '0' then -- Acceso al registro solo si CS es 0 if RD = '0' then D ( 7 downto 0 ) <= REGISTRO (7 downto 0); else D ( 7 downto 0 ) <="ZZZZZZZZ"; -- Si RD es 1 el bus es "Z" if WR = '0' then REGISTRO (7 downto 0) := D ( 7 downto 0 ); end if; end if; else D ( 7 downto 0 ) <="ZZZZZZZZ"; -- Si CS es 1 el bus es "Z" end if;

  47. CONTADOR := CONTADOR +1; if CONTADOR > CICLO then PWM <= '0'; else PWM <= '1'; end if; if CONTADOR = "00000000" then CICLO := REGISTRO; end if; end if; end process; end B2;

  48. Test de puerto PWM

  49. Puertos programables, líneas de control Puerto de Entrada + Salida Básico #CE Registro (Latch) #WR #OE Salida Bus de Datos Entrada Puerta de 3 estados (Transceiver) #RD #OE

  50. Puertos programables, lineas de control Puerto de Entrada + Salida Básico #CE #WR Registro (Latch) #OE Salida Bus de Datos Entrada Puerta de 3 estados (Transceiver) #RD #OE
