diverter a new approach to networking within virtualized infrastructures

Diverter: A New Approach to Networking Within VirtualizedInfrastructures

Aled Edwards, Anna Fischer, Antonio LainHP Labs

outline
Outline
  • Data Center Networks for Cloud Computing
  • Our Approach: Diverter
  • Evaluation
  • Future Work
data center networks for cloud computing1
Data Center Networks for Cloud Computing

Goals (and Challenges!)

  • Multi-tenancy and Security
    • Host multiple customers on a single shared infrastructure
    • Allow each customer to configure their own network topology to suit application needs
    • Data and performance isolation between customers, and the utility
    • Allow controlled and efficient inter-communication between customers if required and permitted
      • “provide rich ecosystem of interacting services”
  • Large scale
  • Automation
  • Flexibility / Programmability
  • Performance
data center networks for cloud computing2
Data Center Networks for Cloud Computing

Problems with Traditional Approaches

  • Traditional L2
    • Flat network: isolation, scalability
    • VLANs: configuration, management
    • Encapsulation, Tunneling
    • Explicit routing entities required, e.g. routing VMs
  • Traditional L3
    • Mobility
    • Routing bottlenecks
our approach diverter1
Our Approach: Diverter

High-level Overview

  • Isolate customer resources into Cells
    • Cell is a collection of virtual resources
    • Cell has a single owner
  • Each Cell can have its own virtual network topology
    • Cells consist of several Subnets
    • Cell owner can define network policies
      • Security: define who can communicate with VMs
      • QoS: define bandwidth limits for VMs
our approach diverter2
Our Approach: Diverter

Virtual Network Topology

Globally managed virtual IP address space representing virtual network topologies

IP address format: 10.<CELL>.<SUBNET>.<HOST> (for example)

Subnet

C3

Subnet A1

Subnet C2

Subnet B2

Subnet A2

Subnet B1

Subnet C1

Cell A

Cell C

Cell B

Virtual Router

Virtual Router

Virtual Router

our approach diverter3
Our Approach: Diverter

Realisation as a Distributed Virtual Router

  • Virtual routers are realised as Distributed Virtual Router implementation (“VNET”)
    • VNET component running on each server
    • VNET intercepts packets to/from VMs, processes them, eventually forwards them, or discards them
  • VNET takes care of
    • Simulating routing across subnets, or Cells
    • Multicast/broadcast distribution
    • Address discovery

As virtual routing functionality is distributed across all servers rather than implemented by particular, traditional routing entities,

communication between any endpoints in the infrastructure always involves just a single network “hop”.

our approach diverter4
Our Approach: Diverter

How Does It Work? MAC Rewriting!

  • VNET rewrites packets to simulate routing hop
    • Packets are sent to / received from virtual router interface when crossing subnets
    • Important to emulate behaviour of traditional network topology
  • VNET uses (modified) ARP to discover physical machines hosting a particular VM
  • VNET rewrites packets to send directly to physical machines hosting destination VM
  • VNET rewrites packets to limit VM broadcast/multicast traffic to particular Cell/subnet
mac rewriting simplified
MAC Rewriting Simplified

1. Packet TX

Virtualmachines

7. Packet RX

Virtual machines

  • Direct network hop between any endpoint
  • No virtual MACs leaking onto the physical wire

2. Packet

intercept

6. Packet RW

Physical host B

Physical host A

3. Packet RW

4. Packet TX

5. Packet RX

sVMAC dVMAC

sVMAC dVMAC

sPMAC dPMAC

sPMAC dPMAC

Physical network

virtual router simulation
Virtual Router Simulation

3. Packet TX

Virtualmachines

9. Packet RX

Virtual machines

DHCP Response with Virtual Router IP

2. ARP Request / Reply for Router IP

4. Packet

intercept

Virtual MACs do not

leak across subnets!

8. Packet RW

Physical host B

Physical host A

5. Packet RW

6. Packet TX

7. Packet RX

sVMAC RVMAC

sPMACdPMAC

sPMAC dPMAC

RVMAC dVMAC

Physical network

our approach diverter5
Our Approach: Diverter

Further Benefits

  • Efficiency
    • Use of multicast/unicast ARP instead of broadcast
    • Local DHCP response generation
    • No packet encapsulation
    • Fast tracking of moving VMs/addresses
  • Security
    • Integrated network policy framework
      • Enforcement of fine-grained packet filtering
      • Allow frequent changes of network policies
  • Manageability
    • No programming of physical infrastructure required
      • No synchronization between physical switches and servers
      • Only rely on underlying flat L2 network
      • Separation of concerns: network administrators vs. server administrators
    • Communication possible with non-VNET servers
    • No programming of explicit routing entities required
    • No specific hardware (or hardware modifications) required
traditional l2 vs diverter
Traditional L2 vs. Diverter

Intra-subnet vs. Inter-subnet Communication

Subnet B

SubnetA

Routing VM

Subnet A

Traditional L2

Diverter

Physical network

performance evaluation
Performance Evaluation

VM Network Throughput

future work1
Future Work
  • Direct Network I/O
    • Integrate with virtualization-aware HW on server-side, e.g. SR-IOV NICs, blade server networking
    • Integration with new I/O virtualization approaches developed around KVM/Xen
  • QoS
  • Virtual Network Cloning
  • Data Center Network Federation
  • L2 Scalable Data Center Ethernet
