  1. Robust Requirements Tracing Via Internet Tech:Improving an IV&V TechniqueSAS 2004 July 20, 2004 Alex Dekhtyar Jane Hayes Senthil Sundaram Ganapathy Chidambaram Sarah Howard Department of Computer Science University of Kentucky

  2. Outline • Requirements Tracing and Information Retrieval • Methods • Metrics • RETRO • Experimental Results • NASA Research information • Technology Readiness Level • Potential applications • Ease of finding, or availability of, data or case studies • Barriers to research or application • Future work

  3. Who Is Who • Sponsor • NASA IV&V Center, Fairmont, WV • Principal Investigators: Alexander Dekhtyar • Jane Hayes • Ph. D. Student: Senthil Karthekian Sundaram* • M.S. Student: Sarah Howard • Past Undergraduate Students: James Osborne* • Rijo Jose Thozhal • Subcontractor: SAIC • * Supported by the NASA grant

  4. The Problem How can we automate tracing requirments during IV&V? Relevance to NASA • Alleviate work of NASA IV&V analysts • Improve quality of IV&V for NASA software Importance/Benefits Improve analyst productivity on one of the most time-consuming IV&V tasks

  5. Approach • Use Information Retrieval Techniques for Requirements Tracing • Build RETRO (REquirements TRacing On-target) • Evaluate performance • TF-IDF, Thesaurus, Probabilistic IR, LSI • Analyst Feedback • Metrics • Special-purpose requirments tracing tool • Standalone version • Integrated with SAIC’s SuperTracePlus • MODIS, LOFAR, CM-1 datasets

  6. Matching algorithm Analyst representation Feedback 1. 2. 3. Approach: IR for Requirements Tracing 2 1 3 Design Document Yes Yes No Requirements Document

  7. Outline • Requirements Tracing and Information Retrieval • Methods • Metrics • RETRO • Experimental Results • NASA Research information • Technology Readiness Level • Potential applications • Ease of finding, or availability of, data or case studies • Barriers to research or application • Future work

  8. Methods • TF - IDF • TF = Term Frequency • IDF = Inverse Document Frequency (rare terms) • Latent Semantic Indexing (LSI) • term x document => “factor” x document • #”factors” << # terms • Enhancements: • Thesaurus • Feedback Processing • Filtering

  9. Outline • Requirements Tracing and Information Retrieval • Methods • Metrics • RETRO • Experimental Results • NASA Research information • Technology Readiness Level • Potential applications • Ease of finding, or availability of, data or case studies • Barriers to research or application • Future work

  10. N - number of low-level requirements; M - number of high-level requirments; Hits - number of correct candidate links Strikes - number of false positives Misses - number of missed links Metrics

  11. N - number of low-level requirements; M - number of high-level requirments; Hits - number of correct candidate links Strikes - number of false positives Misses - number of missed links Metrics Hits Hits Precision = Recall = Hits + Strikes Hits +Misses

  12. N - number of low-level requirements; M - number of high-level requirments; Hits - number of correct candidate links Strikes - number of false positives Misses - number of missed links Metrics Hits Hits Precision = Recall = Hits + Strikes Hits +Misses Hits + Strikes Selectivity = M * N

  13. N - number of low-level requirements; M - number of high-level requirements; Hits - number of correct candidate links Strikes - number of false positives Misses - number of missed links Metrics Hits Hits Precision = Recall = Hits + Strikes Hits +Misses Hits + Strikes Selectivity = M * N AvgH = average relevance of Hits AvgS = average relevance of Strikes DiffR = AvgH - AvgS

  14. N - number of low-level requirements; M - number of high-level requirments; Hits - number of correct candidate links Strikes - number of false positives Misses - number of missed links Metrics Hits Hits Precision = Recall = Hits + Strikes Hits +Misses Hits + Strikes Selectivity = M * N AvgH = average relevance of Hits AvgS = average relevance of Strikes DiffR = AvgH - AvgS Lag(Hit) = # Strikes for high-level requirement with Higher relevance Lag = average Lag(Hit) over all Hits

  15. N - number of low-level requirements; M - number of high-level requirments; Hits - number of correct candidate links Strikes - number of false positives Misses - number of missed links Metrics Hits Hits Precision = Recall = Hits + Strikes Hits +Misses Hits + Strikes Selectivity = M * N Breakpoint =(threshold, Precision, Recall), s.t. Precision = Recall

  16. Metrics • Precision: signal - to - noise • Recall: “coverage” • Selectivity: improvement in # of comparisons vs. exhaustive search • AvgH, AvgS, DiffR, Lag - separation between Hits and Strikes in candidate link lists • Breakpoints - effects of filtering

  17. Outline • Requirements Tracing and Information Retrieval • Methods • Metrics • RETRO • Experimental Results • NASA Research information • Technology Readiness Level • Potential applications • Ease of finding, or availability of, data or case studies • Barriers to research or application • Future work

  18. RETRO: REquirements TRacing On-target

  19. Filter RETRO Architecture documents Analyst Feedback processor Build Representation IR toolbox

  20. A SFEP RETRO Build STP Interactive Link Anlysis RETRO IR Toolbox RETRO Feedback STP Report Generation RETRO + SuperTracePlus requirements documents Analyst Review Representation Traceability Reports STP RETRO

  21. Outline • Requirements Tracing and Information Retrieval • Methods • Metrics • RETRO • Experimental Results • NASA Research information • Technology Readiness Level • Potential applications • Ease of finding, or availability of, data or case studies • Barriers to research or application • Future work

  22. The Universe of Tests method thesaurus feedback threshold Top 1 Top 2 Top 3 Top 4 Yes No TF-IDF LSI* [0.0…0.5] X X X • * LSI: number of dimensions + • low-level documents • high+low-level documents • high-level, low-level documents separately

  23. Datasets • MODIS • 20 high-level • 49 low-level • 41 true links • CM-1 • ~200 high-level • ~300 low-level • # true links - under construction

  24. MODIS, TF-IDF, Thesaurus Top2 Feedback

  25. Breakpoint MODIS, TF-IDF, Thesaurus Top2 FeedbackFiltering at Iteration 0

  26. MODIS, TF-IDF, Thesaurus Top2 Feedback

  27. Above 70% MODIS, TF-IDF, Thesaurus Top2 Feedback

  28. MODIS, TF-IDF, No Thesaurus Top3, Feedback

  29. MODIS, Comparing Feedback Traces

  30. MODIS, Comparing Feedback Traces Above 70%

  31. MODIS, Secondary Measures

  32. MODIS, Secondary Measures

  33. Outline • Requirements Tracing and Information Retrieval • Methods • Metrics • RETRO • Experimental Results • NASA Research information • Technology Readiness Level • Potential applications • Ease of finding, or availability of, data or case studies • Barriers to research or application • Future work

  34. NASA Research Information • Technology Readiness Level -- 6.5 for RETRO • Integrated with existing software system • Engineering feasibility demonstrated • Limited documentation available • Most functionality available for demonstration and test • Most software bugs removed • Potential applications • Tracing bug reports to code • Identifying related/duplicate bug reports • Ease of finding, or availability of, data or case studies • Data available • Issue is answerset • Barriers to research or application • Answerset availability • IV&V analysts for human factors studies • Publications • Paper accepted to RE 2004 • 1 journal paper submitted, one in progress

  35. Outline • Requirements Tracing and Information Retrieval • Methods • Metrics • RETRO • Experimental Results • NASA Research information • Technology Readiness Level • Potential applications • Ease of finding, or availability of, data or case studies • Barriers to research or application • Future work

  36. Next Steps, Conclusions, Plans, Ideas • IR methods work : need to implement more • Productize RETRO (Check!) • Data Integration with existing tools (Check!) • Other IV&V problems may be alleviated • Study “human factors”
