  1. Panoramasphoto Student:Chi-Wei Huang ID:601410132 2013/1/12

  2. Outline • Introduction • Method • Use • Demo • limitation • References

  3. Introduction • 動機 ─ 隨著時代的進步，大家越來越注重相片的運用，在課堂上聽到老師介紹全景照片合成，因此對此方向感興趣，作為期末的project。 • 設備平台 ─ CPU:Intel(R) Core(TM)i5-480M ─ Memory:4.00GB ─ OS:Windows 7 ─ Software:Visual C++ 2010 Professional Edition ─ Other:OpenCV、GLUI

  4. Method • 利用SIFT去找特徵點作matching • Blend image ─ LaplacianPyramid Blending 1.Build Laplacianpyramids for each image. 2.Build a Gaussian pyramid of region mask. 3.Blend each level of pyramid using region mask from the same level: 4.Collapse the pyramid to get the final blended image.

  5. Use • glui介面 ─ 在sorce1、 sorce2、 sorce3分別點選想要 的照片。 ─ 當選定好照片之後按下start，稍待片刻， 當處理完成後，會把結果儲存並且show到 銀幕上。

  6. Demo 連結 • 影片連結http://youtu.be/b4wYPllWsT8 • 測試相片 ─ 採用之前旅遊實際拍攝 ─ 解析度：3648*2736

  7. Demo

  8. limitation • 照片限制 ─ 在輸入的照片需要有相似的地方，否則比對結果不良。

  9. References • 上課投影片ch14 102~118 、ch27 5~30 • Recognising Panoramas [IEEE 2003] M. Brown and D. G. Lowe {mbrown|lowe}@cs.ubc.ca Department of Computer Science, University of British Columbia, Vancouver, Canada. • OpenCVdocument http://opencv.willowgarage.com/documentation/python/index.html

  10. Thank you!!
