Presentation Transcript
implementing the paint specification in the performance standard for protective coatings

Implementing The Paint Specification in the Performance Standard for Protective Coatings

NPCA

Virginia Beach

June 08

NPCA08

objective
Objective
  • To provide a review of the requirements as laid out in the IMO PSPC and highlight important aspects

NPCA08

the parties involved at present
The Parties Involved at present

Shipyard

Ship-owner

Productivity/

Environment

Performance

Coating supplier

NPCA08

the parties involved
The Parties Involved
  • A paint specification is in many ways a compromise:
    • It has to meet with the yards building procedures, environmental and productivity requirements
    • The shipyard is the customer of the coating manufacturers and they have to be competitive on standards as well as price
    • It has to match the paint suppliers product range.
  • The PSPC is in effect making the compromise redundant

NPCA08

coating performance standard review
Coating Performance Standard Review
  • The Performance Standard for Protective Coatings (PSPC) provides the technical requirements for protective coatings in dedicated sea water ballast tanks of all types of ships of 500 gt and greater and double sided skin spaces on bulk carriers of 150m and greater in length.
  • It will be mandatory and is intended to be included as amendments to SOLAS regs II-1/3-2 and XII/6
  • It is also recommended to be applied where possible to items, not integral to the structure e.g. ladders, platforms – Permanent means of access

NPCA08

tip of the iceberg
Tip of the iceberg
  • A family of regulations
    • PSPC
    • Permanent means of access
    • Cargo tanks
    • Maintenance
  • These will change the current compromise solutions

NPCA08

coating performance standard review1
Coating Performance Standard Review
  • Aims of the PSPC
    • to provide a 15 year life for ballast tank coatings over which it is defined as in being ‘good’ condition.
    • ‘Good’ condition is defined in resolution A.744(18) and is “ condition with only minor rust spotting”

( Note: this is different to IACS definition)

    • Better coating systems with reduced maintenance
    • Improved safety at sea

NPCA08

coating performance standard review4
Coating Performance Standard Review
  • Entry into force
  • The proposals will apply to the aforementioned types of vessels:
    • For which the building contract is placed on or after 1st July 2008, or
    • In the absence of a building contract, the keels of which are laid or which are at a similar stage of construction on or after 1st January 2009, or
    • The delivery of which is on or after 1st July 2012

NPCA08

coating performance standard review5
Coating Performance Standard Review
  • Entry into force
  • However IACS are applying the proposals on ratification to tankers ( L > 150m) and bulkers (L > 90m) under the Common Structural Rules (CSR) for contracts signed from December 8th 2006
  • It is expected that the first new building classed under the above rules will begin building in the second half of 2007

NPCA08

the parties involved1
The Parties Involved

Shipyard

Ship-owner

Classification Soc.

?

Productivity

Performance

Coating supplier

NPCA08

coating performance standard review6
Coating Performance Standard Review
  • Main Elements of the PSPC:
    • Design of a specification and coating system
    • Coating System approval
    • Definition of inspection procedures
    • Production of a Coating Technical File (CTF) which records all aspects of the process
    • Verification of compliance

NPCA08

the paint specification
The Paint Specification
  • The paint specification is at the heart of the PSPC and covers:
    • Primary and Secondary surface preparation standards
    • Steel profile range
    • Cleanliness of surfaces prior to coating
    • Soluble salt limits
    • Steel condition
    • Thickness and number of coats
    • Environmental conditions allowed

NPCA08

the paint specification1
The Paint Specification
  • The paint specification applies to the coating system that has been selected
  • Selection of the coating system takes into account the service conditions and planned maintenance
  • All coatings to be epoxy based or equivalent and consist of multi-coat systems of contrasting colour
  • The top coat to be a light colour

NPCA08

the paint specification2
The Paint Specification
  • All coatings to be pre-qualified by:
    • A method corresponding to a specified test procedure or equivalent ( now Annex 1), cross test with shop primer or…
    • Documented field exposure with a final condition of “GOOD” after 5 years
  • Non Annex 1 test must show equivalent testing procedures and needs.
  • A Statement of Compliance or Type Approval Certificate to be issued by a third party - independent of the coating manufacturer

NPCA08

the paint specification3
The Paint Specification
  • The paint specification covers all the processes and defines the standards from:

Shop Primer Application

Block Painting

Post Erection Repairs

NPCA08

the paint specification4
The Paint Specification
  • The painting process at each stage can be separated into the following simple processes:
    • Cleaning the surface
    • Preparing the surface
    • Coating the surface

NPCA08

the paint specification5
The Paint Specification
  • The main elements of the specification in the PSPC are already being carried out in many shipyards and have been for a number of years
  • The main items that are new are :
    • A Coating Technical File has to be produced by the shipyard
    • All inspectors are to be qualified to a recognised standard
    • Increased inspection and prescriptive inspection and data collection
    • Audit by class

NPCA08

suggested table of contents and responsibilities for new build
Suggested table of contents and responsibilities for New build

YARD

A statement of agreement between Owner/yard and paint company for this contract

Paint specification as issued by yard including key criteria and data sheets

A summary or full log of work carried out by yard/coating inspector - one for each tank and Non-conformity/repair summary log for each tank - including verified inspection reports

Statement of conformance

Copy of type approval certificate or statement of compliance

Yard procedures (for inspection and repair) audit certificate from class (includes application ).

Paint Company

Planned maintenance procedures for in service

Class Soc.

Sign off as approved

www.safinah.co.uk

NPCA08

54

suggested table of contents and responsibilities for in service
Suggested table of contents and responsibilities for in service

Ship owner

Maintenance log

Inspection log

Condition log

Class inspection log

www.safinah.co.uk

NPCA08

55

ambiguities
Ambiguities
  • There are many ambiguities in the standard:
    • Salt measurement
    • 90:10 rule
    • Area judgement and other subjective elements
    • CTF detail and content
    • Products approved through testing – will they last 15 years target life
    • What happens if they do not
  • There are some guidelines
    • PR34 from IACS
    • IACS guidance notes
  • Maintenance requirements
  • Costs of implementation
  • IACS members not acting in harmony – adding costs

NPCA08

conclusions
Conclusions
  • Needs a bedding in period
  • Needs a cool and calm interpretation
  • In the wrong hands can considerably add to costs.
  • Places a clear increased burden on yards
  • It is going to get worse before it gets better.

NPCA08
