Presentation Transcript
slide1
ContentProbeCompliance Recording for TV & RadioSignal Fault MonitoringCommercial Content Verification
compliance recording
Compliance Recording

ContentProbe CR range records a proxy of video and audio for regulatory, archive or technical purposes

  • Complete 1,2 or 4 Video channels in 1RU
  • Inputs: Composite, SDI, HD-SDI, IP or ASI
  • Windows Media 9 at 512Kb/s (256-2048k)
  • Up to 720 days per unit @ 512K
  • Audio model up to 32 Channels- AES or Analogues
  • Radio model up to 16 Channels- FM or AM
  • Fully automatic 24x7 recording
  • Accessed immediately from desktop PCs
slide3

Compliance Recording

Product features

  • Up to 16 Audio channels per video
  • RAID 5 hot swap storage
  • Dual Power Supply
  • Export clips for external users
  • Fast and Easy search by Time code
  • Playlist integration from Automation
  • Options
    • Video & Audio – Verification
    • Signal Fault Monitoring – FaultTracker
    • Ad Content Matching / Confirmation- AdCert
slide5

Monitoring Recorder

MRF Low-cost video monitoring solution for as little as ~ Euro 2500 per channel

  • MRF has full functionality of CR compliance products
  • Up to 300 days storage per unit (internal RAID 1)
  • Composite, SDI, HD-SDI, IP or ASI
  • 1,2 or 4 Video channels in 1RU
  • Compact & economical hardware platform
  • Around 30% lower cost compared to CRF model
option for real time monitoring of faults

Fau!tTracker

Option for Real-time monitoring of faults

Detects:

  • Frozen video
  • No video input
  • Audio silence
  • Audio tone
  • Specific content – logos, bars & Idents

New fail-over switching module:

  • Module compares a main and backup channel and provides automatic fail-over switching via the router using GPI or serial control.
reporting

Fau!tTracker

Reporting:
  • Engineering log of transmission faults
  • PDF file with mini-pictures, time code, channel ID for each error or daily report
  • PDF can be e-mailed automatically
  • Log annotation
  • SNMP trap monitoring
  • New free ProbeMonitor desktop software
slide8

Fau!tTracker

PDF reports are generated automatically to give a physical log of transmission faults

transmission verification option checks the correct content is being received

erification

Transmission Verification option checks the correct content is being received
  • Compares source and destination signals
  • Verifies Content for matching video & audio
  • Generates alarms if different
  • Allows for TX & network delays
  • Generates automatic reports for detected errors
slide10

erification

Signal is fingerprinted as it is transmitted

Signal is fingerprinted as it is remotely down-linked

WWW

Fingerprints compared and alarm raised if problem

Fingerprints return via WWW in real-time

slide11

Ad-Cert

Commercials Transmission Reporting

  • AdCert automatically logs transmission of TV Ads, pop promos or other short form material
  • Provides a true and accurate "as transmitted log“
  • Certification for TV Advertisers, Agencies and Broadcasters
  • Automatic logging of Ad hoc commercials during live sporting events
  • Data available as CSV, XML etc
slide13

New Items

New User Interface

  • Modular and easy to configure functionality
  • Lite Client for larger organisations

New Features

  • OmniBus iTX Integration
  • Bookmarking clips to share with other users
  • Archive / Backup module
  • Caption text search facility

New Audio and Radio Models

  • Audio up to 32 Channels– AES/EBU/Analogue
  • Radio with up to 16 internal FM/AM Tuners
protected investment new for old aladdin hardware replacement

Trade-In Deals

Protected Investment - ‘New for Old’ Aladdin Hardware Replacement
  • Aladdin program gives all customers future-proofing of their investment in ContentProbe
  • Upgrade to the latest generation hardware and software and rule out obsolescence
  • Trade-in anytime after 3 years
summary

ContentProbe

Summary
  • Competitively Priced Compliance Recorders
  • Flexible and well featured software
  • Unique options – FaultTracking / Verification / AdCert
  • 1 to 4 Video channels in 1RU
  • New products
      • MRF for monitoring
      • New Radio/Audio Models
  • New-for-old ‘Aladdin’, Archive for external storage,
  • - off-air failover switching of router and AdCert Marketing add-on
slide17

Customers

Some customers

  • OFCOM
  • ITV
  • Starz Entertainment Group
  • Comcast
  • Red Bee
  • SBS
  • QVC
  • ITN News
  • CNBC Europe
  • The History Channel
  • SIS
  • Nickelodeon
  • Globecast
  • Ascent
  • Viasat
slide18

Reliability

www.ideasunlimited.tv

The Oast House, 5 Mead Lane,

Farnham, Surrey GU9 7DY UK.

Telephone: 0870 1627200

83% of our Customers purchased ContentProbes on multiple occasions.

Easy To Do Business With.....

media fingerprinting technology

MediaFingerprinting

Media FingerPrintingTechnology
  • Generates a small digital signature of an audio and video signal
  • Totally non-invasive as FingerPrints do not travel with the TV signal
  • Low bandwidth connections. FingerPrint data including JPEG mini pics is typically 15 - 50kbits
  • Robust- typically over 99.9% accurate
commercial proof of transmission

Ad-Cert

Commercial proof of transmission
  • AdCert automatically records Air plays of TV Ads
  • Provides a true and accurate "as transmitted log“
  • Automatic reconciliation against “as run” logs
  • Certification for TV Advertisers, Agencies and Broadcasters
  • Minimises billing disputes
  • AdCert enables Advertisers, Agencies and Broadcasters to easily check each playout
how it works

Ad-Cert

How it works
  • AdCert monitors and registers any new Ads added to a Broadcast server
  • Alternative manual registration option
  • A secure digital signature gives exact time & channel ID of each airing
  • AdCert compares and flags errors inc. missing sections, audio silence/tone
  • Discrepancies can be visually checked by playing recording
adcert configuration

Ad-Cert

AdCert configuration
  • A single AdCert box can monitor for transmission of up to 1500 spots
  • Additional AdCert boxes can be added to increase the number of spots monitored
  • ContentProbe recorders can be used to monitor any number of channels
  • Playout data can be provided at low level via XML to external systems
  • Easily scalable
adcert more features

Ad-Cert

AdCert more features
  • Emailed PDF's showing mini pics for each play
  • Browse copy of video can be attached to email
  • Short form material such as promos & pop videos can also be verified
  • Ad hoc TX of commercials during live sporting events can be logged
  • Existing ContentProbe users can easily add an AdCert box to their systems
slide25

Fau!tTracker

Instantly know when you have a problem with on-air transmissions - real-time configurable status alarms
  • GPI triggers anywhere on the internet
  • Emailed PDF report with WM9 file
  • Text/SMS alerts using a serial modem
  • Feedback to Automation systems
  • SNMP Traps
