advancing integration competency and excellence with the wso2 integration platform

Advancing Integration Competency and Excellence with the WSO2 Integration Platform

KasunIndasiri

Software Architect, WSO2

MiyuruWanninayaka

Technical Lead, WSO2

agenda
Agenda
  • Fundamentals of WSO2 ESB
  • Cloud Connectors
  • RESTful Integration
  • Cloud Connector – Scenarios
  • RESTful Integration – PizzaShop Scenario
  • Discussion
software in enterprise
Software in Enterprise
  • Large enterprises have many software systems in their “line of business”
    • Enterprise Resource Planning systems (ERP)
    • Management Information Systems (MIS)
    • Decision Support Systems (DSS)
    • Data stores
    • Legacy systems
  • These systems are often independent and controls one or more related business activities
  • But they are all parts of a single business process
need for enterprise integration
Need for Enterprise Integration
  • Individual software applications cannot achieve much
  • Systems should be integrated to work together
    • Enables free data flow across the organization
    • Improves production and management efficiency
    • Application users can make better decisions
easier said than done
Easier Said Than Done!
  • Integrating a multitude of complex software applications is no child's play
  • Systems are diverse
    • Different platforms
    • Different programming languages
    • Different protocols and messaging standards
    • Different QoS requirements
    • Not everyone adhere to standards
what is an esb
What is an ESB?
  • A piece of software that resembles a data bus used in computers
  • Provides a uniform approach for connecting systems
  • Monitor and control routing of message exchange between services
  • Software applications communicate via the bus
  • The service bus acts as a carrier or a message broker
  • Replaces direct contact between applications – Reduces coupling

http://en.wikipedia.org/wiki/Enterprise_service_bus

wso2 enterprise service bus
WSO2 Enterprise Service Bus
  • A lightweight, high performance ESB
  • Configuration driven over coding
  • REST, SOAP and WS-* support
  • Domain specific protocol support (eg: SAP, FIX)
  • Extensible to support custom protocols / message formats
  • Cloud enabled
  • Supports all EIP patterns

http://www.eaipatterns.com

routing
Routing
  • Simple proxy
  • Header-based Routing
  • Content-based Routing
  • XPath/Property/Regular Expression
  • Rules
  • If/Then/Else
  • Router mediator for complex routing
traffic filtering
Traffic Filtering
  • Xpath and regex based filtering
  • Script based filtering
  • Schema based filtering and validation

<id>foo</id>

<id>bar</id>

<id>foo</id>

<id>bar</id>

service orchestration
Service Orchestration
  • Service chaining
  • Split/Aggregate/
  • Clone/Merge
  • Parallel/Serial execution
  • If/Then/Else
transformation
Transformation
  • XSLT
  • Payload Factory
  • Smooks
  • XQuery
protocol message format switching
Protocol & Message Format Switching
  • Message Formats
    • SOAP, REST, JSON, Binary
  • Protocols
    • HTTP(S), JMS, VFS(File), TCP, SAP, FIX, HL7, SMTP
qos security throttling caching
QoS : Security, Throttling, Caching
  • WS-Security / REST Security
  • Throttling
    • Concurrency
    • Rate
  • Caching
    • Local
    • Replicated
    • Suitable for idempotent operations
rest capabilities
REST Capabilities
  • Expose any service as RESTful APIs
  • URL Mapping
  • URL Templates

REST

http://www.infoq.com/articles/webber-rest-workflow

http://wso2.org/library/articles/2012/09/get-cup-coffee-wso2-way/

store and forward
Store and Forward
  • Store incoming request in message store
    • In memory, JMS queue, Database
  • Forward to backend using message processor
  • Guaranteed delivery

Message Store

mediator

Configuration Data

Mediator

Input Message

Output Message

sequences
Sequences
  • A sequential arrangement of mediators – A mediator chain
  • When a message is handed to a sequence it is given to the first mediator of the chain - The outcome of that will be handed to the second mediator of the chain and so on…
  • The messages are sent through the chain while mediators perform various actions on it along the way
  • Pipelining
more on sequences
More on Sequences…

Consider the example sequence shown above

Messages are first logged by the log mediator

The property mediator sets a property on the messages

Then they are sent to a specified endpoint by the send mediator

It is a simple log-and-forward message flow

endpoints
Endpoints
  • Defines an endpoint reference (EPR) to which messages can be sent/forwarded from the ESB
    • The send mediator takes an endpoint as an argument
  • Various operational constraints can be enforced on an endpoint
    • Timeout duration
    • Message format (POX, SOAP 1.1, SOAP 1.2)
  • QoS expectations can be set on an endpoint
    • WS-Security
proxy services api
Proxy Services / API

Acts like a virtual service that can receive requests from clients

Received client requests are processed and routed to a specified endpoint (usually to an actual service – backend service)

Responses coming back from the backend service are further processed and forwarded to the clients

Resembles traditional HTTP proxy servers

slide34

Templates

  • With complex business requirements, ESB config can grow bigger..
  • Need a way to reuse the configuration
  • WSO2 ESB 4.0 introduces – Templates
  • An analogy… classes vs instances
slide35

Templates

  • Sequence Templates

<template xmlns="http://ws.apache.org/ns/synapse" name="xslt_func">

<parameter name="xslt_key"/>

<sequence>

<log level="full">

<property name="BEFORE_TRANSFORM" value="true"/>

</log>

<xslt key="{$func:xslt_key}"/>

<log level="full">

<property name="AFTER_TRANSFORM" value="true"/>

</log>

</sequence>

</template>

templates
Templates
  • Call Template Mediator – Invoking a Template

<inSequence>

<call-template target="xslt_func">

<with-param name="xslt_key" value="xslt-key-req"/>

</call-template>

<send>

<endpoint>

<address uri="http://localhost:9000/Foo"/>

</endpoint>

</send>

</inSequence>

wso2 esb cloud connectors3
WSO2 ESB Cloud Connectors
  • Cloud to Enterprise
cloud connector architecture
Cloud Connector Architecture
  • Objectives
    • Connect with any cloud API
    • Supporting diverse APIs (REST, SOAP, SDKs)
    • Dynamic configuration (No predefined configuration language)
    • Development methodology (config, java code, javascript, pojo)
    • Reduce development time(100+ connectors)
    • Dynamic Tooling with DevStudio
    • Performance
dynamic synapse configuration based on templates
Dynamic Synapse Configuration based on Templates
  • WSO2 ESB config language is predefined
    • Mediator Factories and Serializers
      • Eg: Property Mediator Serializer/Factory
    • So, dynamic synapse config language is not possible?
  • Custom Mediators/Mediator per each connector?
    • Won’t scale and it will be tedious task to write a connector
  • A new approach…
    • Inspired from Templates and Mediation Library
structure of a cloud connector
Structure of a Cloud Connector
  • Connector Structure
    • A connector can have
      • Synapse config as templates
      • Custom Mediators
      • External Libararies (eg: twitter4j)
      • Java Script (or any other scripting lang.)
    • Connector Deployer
    • Loading required libraries
structure of a cloud connector1
Structure of a Cloud Connector

Templates

External Libs

Connector custom code

new secure vault
New Secure Vault
  • No hardcoded secrets or passwords in the ESB Config
  • wso2:vault-lookup

<twitter.config>

<consumerSecret>xx</consumerSecret>

<accessTokenSecret>{wso2:vault-lookup('my_secret')}</accessTokenSecret>

<accessToken>{wso2:vault-lookup('my_token')}</accessToken> <consumerKey>{wso2:vault-lookup('my_key')}</consumerKey>

</twitter.config>

cloud connectors use case i
Cloud Connectors – Use Case (I)
  • Salesforce + Twilio – Lead Generation
cloud connectors use case ii
Cloud Connectors – Use Case (II)
  • Salesforce + Google Spread Sheet – Opportunity Management
cloud connectors use case iii
Cloud Connectors – Use Case (III)
  • Salesforce + JIRA + Twilio – Account Management
cloud connectors use case iv
Cloud Connectors – Use Case (IV)
  • Twitter + Salesforce – Lead Monitor
advanced restful integration
Advanced RESTful Integration
  • HTTP Endpoint

<endpoint xmlns="http://ws.apache.org/ns/synapse" name=“PizzaShopJaxRS">

<http uri-template= "http://localhost:8080/{uri.var.servicepath}/restapi/{uri.var.servicename}/menu?category={uri.var.category}&amp;type={query.param.type}"

method="GET">

</http>

</endpoint>

advanced restful integration1
Advanced RESTful Integration
  • JSON Payload Factory

<payloadFactory media-type="json">

<format>{"purchaseInformation": {"amount": "$1","cc": "$2"}}

</format>

<args>

<arg evaluator="json" expression="$.payment.amount_lkr">

</arg>

<arg evaluator="json" expression="$.payment.card_no">

</arg>

</args>

</payloadFactory>
