Breathing air systems

Trident provides the best breathing air systems products.<br><br><br><br>Model Simplex- 10S<br>L (mm)- 625<br>B (mm)- 540<br>H (mm)- 1121<br>Flow cfm- 10<br>End conn. BSP- 1/2"<br><br>Model Duplex- 10D<br>L (mm)- 1150<br>B (mm)- 800 <br>H (mm)- 1168<br><br><br>Standard Features<br>* Single Medical breathing Air unit with CO and Dew Point Monitor (Simplex)<br># Dual Medical breathing Air unit with CO and Dew Point Monitor (Duplex) One Stand by unit with manual redundancy.<br><br>Operating Conditions<br><br>Voltage : 100 - 240 VAC, 50/60Hz, 1ph<br>Power Consumption : 40 Watt Max<br>Maximum working pressure : 16 bar (g)<br>Minimum working pressure : 4 bar (g)<br>Rated inlet Temperature : 38u00b0C<br>Rated inlet pressure : 7 bar(g)<br>CO Level : 10 PPM (Alarm set point)<br>as per NFPA 99<br>Air Quality : 2<br>0C PDP (Alarm set point)<br>as per NFPA 99<br>0.01 micron particle level.<br>Cycle Time : 4 min<br>Dewpoint dependent change over<br><br>Alarms<br>Compact digital carbon monoxide (CO) monitor, Dew point monitor. If the set value exceeds the standard value,<br>it will give the alarm in the front panel.<br><br>Purge saving<br>Manual Purge economiser.<br>Dewpoint sensor for automatic purge control.<br><br><br>Construction<br>Corrosion free aluminium towers and blocks. All pipeline are in SS/Copper.<br><br>Display<br>LED indication for tower operation and sequence of operations.<br><br>Easy Integration<br>Easy installation and integration with existing equipment: All system tie-in points are on one side.<br><br>Safe<br>Heavy-duty adsorption vessels, designed and certified for an unlimited number of cyclic loads.<br><br>Customization<br><br>An extended list of options allow you to define your specific Trident Twin-Tower PSA breathing air dryer<br>adjusted to your individual need.<br>

Download Presentation

Breathing air systems

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. Company Overview With a strong presence that has lasted three decades, we have been a leading manufacturer offering innovative product solutions in the field of Compressed Air Treatment. Our product range includes - Air Dryers, Drain Valves, Nitrogen Generators, Oxygen Generators, Filters etc, some of which are patented. Our infrastructure with modern equipments and facilities ensure quality products which meet stringent requirements of the industry. Products: • Compressed Air Dryer. • Compressed Air Filter & Drain valve • Rail road Products • Gas Generator Products

  2. Compressed Air dryer Product • Coldspell Refrigeration Compressed Air Dryers

  3. Dryspell Plus – Heatless Air Dryers

  4. Heatless Desiccant Dryers - DP Series

  5. MEDICAL AIR DRYERS

  6. Blower Reactivated Dryers

  7. CUSTOM SOLUTIONS

  8. COLD SPELL HIGH PRESSURE

  9. Compressed Air filter & drain products • Condensate Sensing Drain Valve – Series LDV

  10. Drain Valve-Timer Type - Series CTD

  11. Cleansweep Microfilters

  12. High Pressure Filters Cleansweep

  13. Medical Vacuum Filter

  14. Bacteria Filter Series

  15. Rail road Products • Air Dryers

  16. Valves

  17. Gas Generator Products • Nitrogen Generator

  18. Onsite Medical Oxygen Plant

  19. For more details INDIA Tel : +91 8220019925 E-mail : sales@tridentpneumatics.com Website: http://www.tridentpneumatics.com/

  20. INDONESIA Phone no : +6281210690960 E-mail : risma@august-compressor.com Website: http://www.tridentpneumatics.com/id
