  1. Role of Auxiliary in Pollution Incidents US Coast Guard Auxiliary, D11N Wilfred Sumner ADSO MS

  2. Objectives • To familiarize Auxiliary personnel with pollution response activities. • To discuss various scenarios that may arise. • To discuss Coast Guard Auxiliary response to reports of pollution.

  3. Auxiliary Duties When Observing An Incident • Identify the pollution incident. • Report the incident to National Response Center & your Station • Monitor the Incident and stay on station until relieved.

  4. Initial notifications Local Station or Authority National Response Center (NRC) 800-424-8802 Sector Command Center

  5. Questions Asked by NRC • Is there a source of the discharge? • Is the source secured? • What actions is the responsible party taking to mitigate the discharge? • Describe the size, color and coverage of the spill

  6. Sheens • Very thin layer of oil usually less than 0.0001 of an inch floating on the water surface. • Not recoverable • Minimal environmental impact • Can be gray to rainbow in color depending on age and product

  7. Mystery Sheens • How big is it? • Can a source be identified? • Is there significant media or public interest? • Is it near the Monterey Bay Aquarium? • IMD will most likely not dispatch personnel if a source can’t be identified and is unrecoverable

  8. Mystery Drums • Metal or plastic containers used to contain oil or other hazardous materials • No responsible party • May contain an unknown substance

  9. Response to Mystery Drums • Station will ask Auxiliary if they can remain on-scene until help arrive. • If not then we will ask you to get last known position • NRC will ask if it accessible by land or ask for a ride to it’s last known location • Once on scene Station/IMD will determine if a contractor needs to be hired for removal.

  10. Description of Spills Form Color Size

  11. What happens to oil when it is spilled? • Spreading • Oil Weathering • Transport

  12. Oil Thickness

  13. Spreading Does not spread uniformly. 50 barrels of Arabian crude

  14. EASY REORTING METHOD • --- BOX IT • --- SQUEEZE IT • --- DESCRIBE IT • --- REPORT IT

  15. SPILL ON WATER

  16. BOX IT 2 4

  17. BOX IT 2 x 4 = 8 SQ. NM

  18. SQUEEZE IT 2 4

  19. SQUEEZE IT 2 4

  20. SQUEEZE IT 30% COVERAGE 2 4

  21. Dispersion and Dissolution • Dispersion a major removal mechanism. • Droplets 50 to 70um in diameter are not likely to resurface due to turbulence. • Less than 1 to 2% of the spilled oil volume actually dissolves into the water column.

  22. Tarballs

  23. THE TEST…IS IT OIL? CRUDE OIL SLICK

  24. IS IT OIL? RED TIDE

  25. IS IT OIL? KELP BED

  26. IS IT OIL? POSSIBLY SUBMERGED ALGAE ?

  27. Records to collect during a spill. Photos/Videos Charts Statements/Interviews Samples-MSL Facility Com. logs Procedures & Documents required

  28. Helpful ways to assist IMD personnel • Try to determine a source of the discharge. • Mark the last known position of drums • Take pictures • Issue NOFI’s • Make witness statements

  29. Reports of Pollution incidents • Coxswain call in to NRC 800 424 8802 • Radio into local CG Station or Authority • Take notes of spill to be reported on Mission Report 7030 • Take Photos • Use mission 70b on 7030 • Supply 7030 and notes to Issuing Authority

  30. Sector San Francisco Pollution Cases MST1 ANDERSON WAS HERE

  31. Boat Fire, Turner Cut Resort • On October 8, 2007, Sector San Francisco was notified of a fire that occurred at the Turner Cut Resort near Stockton, CA. The Sector duty pollution team was dispatched to the location and discovered that at least six vessel were burned. The damaged to the vessels ranged from burned to the waterline to completely sunk. The owners of the vessels could not be found to initiate a response to the spill. The pollution team opened the Oil Spill Liability Trust Fund and hired Parker Diving Service to mitigate the spill and possibly salvage certain vessels if needed. • Suspected cause: Arson.

  32. Fire, Turner Cut Resort

  33. Fire, Turner Cut Resort An estimated 500 gallons of diesel and gasoline was discharged into the water The contractor used sorbent pads and boom to recover the spilled substances and nets to recover the sheening debris An estimated 300 gallons was recovered by the contractors • Six rec boats were burned when the marina caught on fire • Impacted region was marshy • Decision Memo was requested by NPFC to justify response • Local Fire Department response was significantly delayed due to remote location The cost of this project was $36,784.00

  34. CFV Lou Denny WayneNovember 29, 2007

  35. CFV Lou Denny Wayne • On November 29, 2007, Sector San Francisco received a call from a grounded vessel a half a mile south of Pigeon Point lighthouse. While recovering crab pots at 0300, the vessel sustained damaged to the starboard bow section and was taking on water. In an attempt to save his vessel, the owner grounded the vessel on the rocks approx. 20 yards from shore. The owner and his son were rescued by a CG helo, while the vessel remained grounded with a potential of 500 gallons of diesel on board. The pollution team was dispatched to the scene and discovered that the owner of the vessel did not have insurance. The OSLTF was opened and Parker Diving was hired to remove the fuel from the vessel.

  36. CFV Lou Denny Wayne

  37. CFV Lou Denny Wayne December 4th, 2007 December 6th, 2007 Parker Diving Service was contracted by NOAA to remove the debris, engine, generator, windlass, shaft, and other components of the wreck.

  38. Any Questions?
