bird strikes be alert and aware know the risks avoid survive

BIRD STRIKES!Be alert and aware!Know the risks!Avoid & Survive!

Click mouse button to advance screen

objectives of this training

BIRD STRIKES! Wing Fligh.Clinic0

Objectives of This Training:

  • Improve your awareness of the issue of bird strikes
  • Improve your understanding of risk factors
  • Reduce the likelihood of bird strikes in CAP

Click mouse button to advance screen

slide3

BIRD STRIKES!

This presentation is based on documents prepared by the FAA and in cooperation with the U.S. Department of Agriculture. The emergency forced landing of US Airways Flight 1549 in the Hudson River on 15 January 2009 after Canada geese were ingested in both engines of the Airbus 320 dramatically demonstrated to the public that bird strikes are a serious aviation safety issue. For more detailed data, see the above report on the: http://wildlife-mitigation.tc.faa.gov/wildlife/downloads/BASH90-09.pdf website.

slide4

BIRD STRIKE!

Click mouse button to advance screen

slide5

BIRD STRIKE!

Click mouse button to advance screen

slide6

BIRD STRIKE!

Click mouse button to advance screen

slide7

BIRD STRIKE!

Click mouse button to advance screen

slide8

BIRD STRIKE

Click mouse button to advance screen

slide9

lBIRD STRIKE!

Click mouse button to advance screen

slide10

BIRD STRIKES!

This was US Airways flight 1549 Airbus 320 that landed in the Hudson due to loss of engine power from bird ingestion in both engines.

Some persons in this photo actually stopped and grabbed their bags from the overhead bins during the evacuation.

Was there anything in the luggage that was worth your life?

Click mouse button to advance screen

slide11

BIRD STRIKE STATS

MN Wing Flight Clinic: Bird Strikes

Bird strike reports have increased alarmingly over the last 20 years.

Click mouse button to advance screen

slide12

BIRD STRIKE FACTS

Many populations of wildlife species commonly involved in strikes have increased markedly in the last few decades and adapted to living in urban environments, including airports.

Thirteen of the 14 bird species in North America with mean body masses greater than 8 lbs have shown significant population increases over the past three decades.

The number of strikes annually reported more than quintupled from 1,759 in 1990 to 9,474 in 2009.

Click mouse button to advance screen

slide13

MN Wing Flight Clinic: Bird Strikes

Canada Goose

Population Increase

Explosive growth of the Canada goose population in the U.S.

Click mouse button to advance screen

slide14

BIRD STRIKE STATS

51% of the annual total.

Bird strikes can occur anytime, but the prime months are July through October.

Click mouse button to advance screen

slide15

BIRD STRIKE STATS

Since most flights occur during the day, more bird strikes occur then. However, birds do also fly at night.

Click mouse button to advance screen

slide16

BIRD STRIKE STATS

The phases of flight during which the vast majority of bird strikes occur is during takeoff and climb out, and during approach and landing.

Click mouse button to advance screen

slide17

BIRD STRIKE STATS

The highest number of bird strikes occur below 100 AGL, and then another high grouping appears in the 900 to 4000 foot AGL range.

Click mouse button to advance screen

slide18

BIRD STRIKE!

It always pays to keep your eyes outside and looking for any kind of airborne traffic.

Click mouse button to advance screen

slide19

BIRD STRIKE!

Although it seems the more fancy panel equipment we get, the more we focus inside. This panel is much less fancy after a bird strike.

Click mouse button to advance screen

slide20

BIRD STRIKE AVOIDANCE!

  • The U.S. Air Force Bird Aircraft Strike Hazard (BASH) Team and the FAA offer this guidance for avoiding and/or dealing with bird strikes:
  • Avoid low altitude flight as much as feasible to reduce the risk of a strike.
  • Strikes are most likely in July, August, September, and October - particularly in migratory flyways. These tend to be the larger birds.
  • Keep a lookout, just as you would for other flying objects.
  • Turn on landing or recognition lights. This helps birds see oncoming aircraft.

Click mouse button to advance screen

slide21

BIRD STRIKE AVOIDANCE!

  • Plan to climb. Birds almost invariably dive away, but there are exceptions.
  • Slow down. This will allow birds more time to get out of your way and will lessen the impact force if you do hit one.
  • If a collision seems likely, duck below the glare shield to avoid being hit by the bird and flying Plexiglas. Advise passengers to do the same. Protect your eyes and head.

Click mouse button to advance screen

slide22

BIRD STRIKE,

NOW WHAT?

  • If a collision occurs, fly the aircraft first! Assess the damage and decide whether you can make it to an airport or you should make an off-airport landing.
  • Declare an emergency - it doesn't cost anything.
  • Even if no damage is visible, divert to the nearest airport and have a mechanic look at the airplane. There are likely to be some aerodynamic modifications that do not have FAA approval.

Click mouse button to advance screen

slide23

Please be sure to use the Avian Hazard Advisory System to get general information updates about Avian activity in areas near you. This is available on www.capmembers.com under the Safety Tab.

Click to the next page for a look at the webpage entry screen.

slide24

A product of the Air Force Safety center, this is a public use webpage accessible at www.capmembers.com.

slide25

BIRD STRIKE

SUMMARY:

Bird strikes occur more often in the late summer/ autumn season.

Birds are more likely to be struck during the landing (i.e., descent, approach or landing roll) phase of flight compared to take-off and climb.

72% of the time bird strikes occur below 500 feet AGL.

92% of the bird strikes occur at or below 3,000 feet AGL.

Less than 2 percent of bird strikes occur above 10,000 feet AGL.

Flying high and maintaining that altitude during cruise is good ORM.

Click mouse button to advance screen

slide26

BIRD STRIKE

Thank you for the contribution of this presentation from CAP’s members and for everyone’s continued support of a positive safety program.
