1. Homologous Series Members Alrick Moodie
February 2007
2. Hydrocarbons Hydrocarbons are compounds which contain carbon and hydrogen only .
The two families of hydrocarbons which we will explore are :
- the alkanes
- the alkenes
3. Alkanes The alkanes have general formula
CnH2n+2
4. Physical properties of alkanes
5. Chemical reactions of alkanes Alkanes are saturated hydrocarbons i.e. they have the maximum number of hydrogen atoms .
Alkanes undergo substitution reactions where one of the hydrogen is replaced by a next element .
6. This process is called halogenation
CH4 + Cl2 ? CH3Cl + HCl
This reaction is carried out :
In the presence of ultraviolet light
or
At temperatures of 200oC
The reaction also occurs with bromine although with less vigour
7. Chemical reactions of alkanes Alkanes also undergo combustion reactions.
They burn in oxygen to form carbon dioxide and water .
8. Alkenes Alkenes are hydrocarbons which contain one carbon to carbon double bond
C=C
The double bonds means that alkenes are unsaturated . They can hold more atoms therefore they undergo addition reactions .
11. Reactions
Hydrogenation
Halogenation
Hydration
Hydrohalogenation
Combustion
12. Like alkanes , alkenes will burn in air to form carbon dioxide and water .
C2H4 + 3O2 ? 2CO2 + 2H2O
13. Hydrogenation
Alkenes will add hydrogen gas to form the alkane .
C2H4 (g) + H2 (g) ? C2H6 (g)
This reaction is carried out at 200oC over a metal catalyst , usually nickel .
14. Margarine manufacture
Some margarine is made by hydrogenating carbon-carbon double bonds in animal or vegetable fats and oils. You can recognize the presence of this in foods because the ingredients list will include words showing that it contains "hydrogenated vegetable oils" or "hydrogenated fats".
15. Halogenation
Alkenes will add the halogen to form the alkyl halide .
C2H4 (g) + Br2 (l) ? C2H4Br2 (l)
This reaction is carried out at room temperature . This is the qualitative test for alkenes , the ease at which bromine in a solvent is decolourized .
16. The bromine is usually in a non-polar solvent such as carbon tetrachloride CCl4
Aqueous bromine , bromine water can be used .
The colour would go from red-brown to colourless .
17. Hydration
Alkenes will add water to form the alcohol .
C2H4 (g) + H2 O (l) ? C2H5OH (l)
18. The reaction is carried out :
The alkene is passed with steam over a catalyst .
or
Concentrated sulphuric acid is added to the alkene and the mixture boiled with water to 120oC .
20. Hydrohalogenation
Alkenes will add hydrogen halide to form the alkyl halide .
C2H4 (g) + HBr (g) ? C2H5Br (g)
21. Alkenes also undergo oxidation . The reactions are not necessary to be taught at this stage . The products could be :
- the diol
- the carboxylic acid
- the aldehyde / ketone
22. Comparison between alkanes and alkenes
