Decoder*
I/O pins: Iout, Iref_in, Addr<0:8>, clk Analog Signals: Iref_in, Iref<0:4>, Iout Digital Signals: clk, Addr<0:8>, b<0:15>, en_out<0:6> All Blocks are analog except for the Decoders. Iref_in. Current source. Iref<0:4>. Iref<1>. Iref<2>. Iref<3>. Iref<4>. Iref<0>. Iout.
