Presentation Transcript
the green field myth
The “Green Field” Myth
  • Myth: There is no difference between starting a new IT process from scratch and migrating to a new process.
  • Truth: Migrating is often more difficult, because you must carry forward your data.
  • Truth: Managers actually know this about buildings, but fail to apply it to data.
for example
For example:
  • Install new email client.
  • Oops: All your saved mail is lost.
    • Can’t convert, find, or move folders for some reason.
  • Oops: Your address book is gone.
    • Same problem
  • And this is an easy task!
  • Imagine a real-life scenario with multiple databases.
solving the email client issue
Solving the Email Client Issue
  • Find the former assets
    • Look in c:/Users/username/AppData
    • Probably the “roaming” profile
    • Look for the app’s name
  • Is the mailbox format compatible?
    • Perhaps you can import
    • Or…Copy to the new location
  • A messy process – but experience helps
the bad news
The Bad News
  • You probably aren’t going to do anything “green field” unless you are starting a new company.
  • Even then, you’ll probably start small and do a larger-scale version later.
  • So you’ll almost always be migrating data at implementation time.
data migration approaches
Data Migration Approaches
  • Static
    • Hand Entry
  • Semi-Dynamic
    • Phased Roll
    • Process-Based
  • Live
    • Screen Scraping
    • EDI/EAI Connection
migration auditing how do you know it s right
Migration AuditingHow Do You Know It’s Right?
  • Totals
    • Number of transactions, amount of money
  • Codas
    • Identifiable batches that you can compare
    • May have to be time periods
  • Statistical Methods
    • Are we seeing reasonable ratios (inc/expense, etc)
    • Select sample transactions at random, follow the path
method hand entry
Method: Hand Entry
  • No electronic connection to old system needed.
  • Cleanup of old data done at data entry.
  • Appears to be simplest for computer people.
    • What about data entry error cleanup?
  • May be lots of work for clients.
    • Maybe not as much as you think
  • Default if other methods fail.
  • Probably used for some components anyhow.
  • How are you going to “prove” it is correct?
hand entry choice factors
Hand Entry Choice Factors

When to use

  • Small amount of data
  • Data is stable during conversion period
  • No other way to do it
  • Conceptually difficult to map former data onto new system
    • Perhaps the way the new system works is why you are changing!

When not to use

  • Lots of data
  • Data changes during conversion period
  • Quality typing unavailable
method phased roll
Method: Phased Roll
  • “Roll” data from old system to new system on a per-component basis
    • For example: This week we’ll “roll” Payroll. Next month we’ll “roll” Accounts Payable.
  • Requires building a roll process for each set of data
  • Inter-Relationships can be complex
campus shop roll circa 1977
Campus Shop Roll (circa 1977)
  • Administrative system was being copied to new system every night
  • Campus Shop system was ready to go on new system (and old was unusable)
  • “Your ID card will work at the Campus Shop tomorrow”
    • Individual could be entered manually
  • Campus shop transactions copied back to old system at end-of-month statement time

This is actually a very simple example. Real life is usually far more complex.

phased roll choice factors
Phased Roll Choice Factors

When to use

When not to use

Data relationships change during conversion period

Data is tightly coupled between systems

E.g. If the Campus Shop data needed to be available on the old system up-to-the-minute

You aren’t converting everything

  • Data involved in relationships is stable during conversion period
    • People could tolerate the ID card delay
  • Data is loosely coupled between systems
    • Only one file needed to come back from Campus Shop, monthly
method iterative
Method: Iterative
  • Like phased roll, except that:
    • A complete conversion is done repeatedly (daily?)
    • New systems are available only for read-access until all systems are complete
  • This is a Beckett-designed approach. Life is rarely so simple that you can do it this way – but I’ve done it twice
iterative method choice factors
Iterative Method Choice Factors

When to use

  • Large amount of data
    • Especially if large part is foundational to others (e.g. Academic Records)
  • Codas available
  • Data is not stable during conversion period
  • Need to show early success

When not to use

  • Conversion matrix is too complex
    • No specific foundational data
  • Time required for conversion run is long
  • Extensive hand-manipulation is necessary
method screen scraping
Method: Screen-Scraping
  • “Live” process emulates old workstations, captures data.
  • Usually requires some sort of “middle-ware” product
  • Requires former method to be character-mode (less likely in the future)
    • You could, however, use an HTML Mash-up
screen scraping choice factors
Screen-ScrapingChoice Factors

When to use

  • No alternative access is available
  • Former system is frozen
  • Occasional errors are:
    • Detectable
    • Correctable
    • Acceptable if detected & corrected

When not to use

  • Direct access to data is available
  • Former system is under development
  • Zero tolerance for data errors
    • Problem: No feedback

Any time you have a better alternative

method hand coded interface
Method: Hand-Coded Interface
  • Write a program for each connection between source and destination
    • Or add module into existing program
  • Have the program invoked either continuously or periodically to transport across
hand coded choice factors
Hand-CodedChoice Factors

When to use

  • Very few interfaces
  • You can achieve the “liveliness” needed

When not to use

  • Many interfaces are required
method eai
Method: EAI

Electronic Applications Integration

  • “Middleware” product used to keep current data on both sides.
  • Use EAI language (or modules you program) to define interfaces
eai choice factors
EAIChoice Factors

When to use

  • Integrating with system under development
  • You need live data
  • Bandwidth is available
  • Interfaces work

When not to use

  • Bandwidth and/or server overhead is intolerable
  • “Snapshot” view is preferred
  • Extreme security concerns about updating
myths of eai
Myths of EAI
  • Myth:
    • (N(N-1))/2 interfaces required for hand coding.
    • Only N interfaces required for EAI
  • Truth:
    • You don’t have all the modules sending data to each other.
    • EAI doesn’t excuse you from designing all your interfaces.
      • But…EAI systematizes the process, and that is a very good thing – probably as important as the magic that was promised!
html mash up
HTML Mash-Up
  • Write server-side code that reads a Web site
  • Parse the site to get the data you want
  • Present it in a useful manner to users
choice factors for mash up
Choice Factors for Mash-Up

Yes

No

The source data site changes often

You have no further resources to spend on the project

Downtime is intolerable

  • The source data site is stable
  • The mash-up is not more complex than you care to maintain
  • Downtime is tolerable if the source changes
    • Until you fix the problem, because you have no warning

If a Mash-Up smells like screen scraping, you’re right!

what s the best way
What’s the Best Way?
  • It’s a designer’s choice:
    • Meet the needs
    • Accept the risks
    • Accept the costs
the good news
The Good News
  • This is in the middle a CSA/CIS person’s expertise.
  • Modest programming skills will help.
  • Success at data migration is a key to moving up in the organization.
    • It’s a bullet point you can add to your resume’.
case study hazel co because you have other things to do
Case Study: Hazel & Co.“Because you have other things to do”
  • Maid service
  • Began with three maids working from one location
  • Now has 500 locations with 3,000 maids
    • 200 locations company-owned
    • 300 locations franchised
business challenges
Business Challenges
  • Quality service from minimum-wage people
  • Connect with external sources of info
    • Arrest records
  • Payroll data
    • Out-source (or in-source by our co. for franchisees)
history
History
  • Ran out of a checkbook register
  • Excel
  • Quickbooks
  • Got a payroll system
  • Got a General Ledger/Accts Pay system
  • Wrote conversion system to grab data from PR, GL, AP -> put into Quickbooks
slide31

Wrote a Web-based system that analyzes current info from PR, GL, AP – makes it look like Quickbooks

  • Requests for more / better info:
    • Write add’l modules for new system that gives that information
    • Write modules that create Excel sheets with desired analyses
