Presentation Transcript
product conformance
PRODUCT CONFORMANCE
  • Dimensional conformance - within tolerances as defined on product drawing
  • Structural conformance - defined by "Acceptance Criteria"
acceptance criteria
ACCEPTANCE CRITERIA
  • organized by basic structural configurations
    • laminates
    • sandwich panels (honeycomb)
    • sandwich panels (rohacell)
    • bonded laminates
  • for each defect
    • imperfection name
    • description
    • method of inspection
    • acceptance criteria (dependent on the application for which the structure is to be used, see pg. 8)
      • primary
      • non-primary
  • examples of different types of defects - identify acceptance criteria in document
nonconforming reject part
NONCONFORMING (REJECT) PART
  • requires disposition (in accordance with standard repair procedure or by MRB/Engineering)
  • part to be
    • scrapped
    • reworked
    • repaired
