Building a Robust Speaker Recognition System Old řich Plchot , Ondřej Glembek , Pavel Matějka

1. Building a Robust Speaker Recognition SystemOldřichPlchot, Ondřej Glembek, Pavel Matějka December 9th 2012

2. The PRISM Team SRI International Harry Bratt, Lukas Burget, Luciana Ferrer, Martin Graciarena, Aaron Lawson, Yun Lei, Nicolas Scheffer SachinKajarekar, Elizabeth Shriberg, Andreas Stolcke Brno University of Technology Jan H. Cernocky, OndrejGlembek, PavelMatejka, OldrichPlchot

3. PRISM Robustness ~ ~ ~ ~ Error rates lowered “How did we achieve these results?” “What are the outstanding research issues?” BEST Phase I PI conference, Nov. 29th, 2011

4. Robustness • A need for effectiveness on non-ideal conditions • Moving beyond biometric evaluation on clean, controlled acquisition environments • Extract robust and discriminative biometric features, invariant to such variability types • A need for predictability • A system claiming 99% accuracy should not give 80% on unseen data • Unless otherwise warned by the system BEST Phase I PI conference, Nov. 29th, 2011

5. A comprehensive approach Multi-stream High order and Low order features Advanced speaker modeling and system combination Prediction of difficult scenarios – QM vector Robustness vs.Unknown– Carefully test on held-out data, bewareofovertraining BEST Phase I PI conference, Nov. 29th, 2011

6. A comprehensive approach • Multi-stream High order and Low order features: Prosody, MLLR, constraints, and MFCC, PLP, … • Multiple HOFs: new complimentary information • Multiple LOFs: ditto + redundancy for increased robustness • Advanced speaker modeling and system combination: Unified modeling framework i-vector / probabilistic discriminant analysis • Robust variation-compensation scheme for multiple features and variability types • i-vector / PLDA framework adapted to all high- and low- level features • Discriminative training for more compact thus robust systems BEST Phase I PI conference, Nov. 29th, 2011

7. THE MAGIC? - iVectors iVector extractor is model similar to JFA with single subspace T  easier to train no need for speaker labels  the subspace can be trained on large amount of unlabeled recordings We assume standard normal prior factors i. iVector – point estimate of i – can now be extracted for every recording as its low-dimensional, fixed-length representation (typically 200 dimensions). However, iVector contains information about both speaker and channel. Hopefully this can by separated by the following classifier. Dehak, N., et al., Support Vector Machines versus Fast Scoring in the Low-Dimensional Total Variability Space for Speaker Verification In Proc Interspeech 2009, Brighton, UK, September 2009

8. Illustration Low dimensional vector can represent complex patterns in multi-dimensional space m1 m2 m1 m2 m1 m2 μ1 μ2 μ1 μ2 μ1 μ2 t11 t12 t21 t22 t11 t12 t21 t22 t11 t12 t21 t22 t13 t23 t13 t23 t13 t23 i1 i2 i3 = +

9. Probabilistic Linear Discriminant Analysis (PLDA) Let every speech recording be represented by iVector. What would be now the appropriate probabilistic model for verification? iVector are assumed to be normal distributed iVector still contains channel information  our model should consider both speaker and channel variability, just like in JFA. Natural choice is simplified JFA model with only single Gaussian. Such model is known as PLDA and is described by familiar equation:

10. For our low-dimensional iVectors, we usually choose U to be full rank matrix  no need to consider residual є We can rewrite definition of PLDA as or equivalently as Why PLDA ? … familiar LDA assumptions !

11. PLDA based verification Lets again consider verification score given by log-likelihood ratio for same and different speaker hypothesis, now in the context of modeling iVectors using PLDA: … before: intractable, with iVectors: feasible. All the integral are now convolutions of Gaussians and can be solved analytically, giving, after some manipulation: FAST !

12. Baseline (relevane MAP) Eigenchannel adapt. JFA iVector+PLDA Performance compared to Eigenchannels and JFA NIST SRE 2010, tel-tel (cond. 5) iVector+PLDA system: • Implementation simpler than for JFA • Allows for extremely fast verification • Provides significant improvements especially in important low False Alarm region

13. iVector+PLDA iVector+PLDAfullcov UBM LDA150+Length normalization red + Mean normalization iVector+PLDA – enhancements NIST SRE 2010, tel-tel (cond. 5) Ideas behind the enhancements: • Make it easier for PLDA by preprocessing the data by LDA • Make the heavy tail distributed iVectors more Gaussian • Help a little bit more with channel compensation by condition-based mean normalization

14. Diverse systems unified %FA @ 10% Miss “All features are now modeled using the i-vector paradigm, even for combination” “New technologies for prosody modeling, e.g. subspace multinomial modeling” BEST Phase I Final review, Nov. 3rd, 2011

15. BEST evaluation submissions Early iVector fusion, optimal %FA @ 10% Miss PRIMARY Complex multi-feature / combination of low- and high- level systems ½% False Alarms @10% Miss for our PRISM MFCC system: Look at another operating point? (if that low for the evaluation) BEST Phase I Final review, Nov. 3rd, 2011

16. A comprehensive approach • Multi-stream High order and Low order features: Prosody, MLLR, constraints, and MFCC, PLP, … • Advanced speaker modeling and system combination: Unified modeling framework • Prediction of difficult scenarios: Universal audio characterization for system combination • Detect the difficulty of the problem, eg: enroll on noise, test on telephone • React appropriately, eg: calibrate scores for sound decisions BEST Phase I PI conference, Nov. 29th, 2011

17. Predicting challenging scenarios Microphone Noise 20db Tel Noise 8db Reverb 0.3 Reverb 0.7 Noise 15db Reverb 0.5 • Unified acoustic characterization: A novel approach to extract any metadata in a unified way • Designed with the BEST program goal in mind: ability to handle unseen data, or compounded variability types • Avoid the unnecessary burden to develop a new system for each new type of metadata • IDentificationsystem, where the training data is divided into conditions • Investigating how to integrate intrinsic conditions: language and vocal effort BEST Phase I Final review, Nov. 3rd, 2011

18. Robust calibration / fusion • Condition prediction features as new higher order information for calibration • Calibration: scale and shift scores for sound decision making on all operating points • Confidence under matched vs. mismatch conditions will differ • Discriminative training of the bilinear form • Model is giving a bias for each condition type • Further research • Assess generalization • Affect system fusion weights not just calibration • Early inclusion of the information BEST Phase I Final review, Nov. 3rd, 2011

19. Fusion with QM • Offset • Linear combination weigths • Score from system k • Vectors of metadata • Bilinear combination matrix BEST Phase I PI conference, Nov. 29th, 2011

20. A comprehensive approach • Multi-stream High order and Low order features: Prosody, MLLR, constraints, and MFCC, PLP, … • Advanced speaker modeling and system combination: Unified modeling framework • Prediction of difficult scenarios: Unified condition prediction for system combination • Robustness vs. unknown: The PRISM data set • Expose systems to a diverse enough variability types of interest • Aim for generalization on non-ideal or unseen data scenarios • Use advanced strategies to compensate for these degradation BEST Phase I PI conference, Nov. 29th, 2011

21. The PRISM data set 08dB 15dB 20dB Noisy data set • Noises from freesound.org, mixied using FaNT (Aurora) • Real noise sample: cocktail party type, office noises • Different noises for training and evaluation Reverb data set • Uses RIR + Fconv • Choose 3 RT30 values: 0.3, 0.5, 0.7 • 15 different room configurations • 9 for training, 3 enrollment, 3 test • A multi-variability, large scale, speaker recognition evaluation set • Unprecedented design effort across many data sets • Simulation of extrinsic variability types: reverb & noise • Incorporation of intrinsic and cross-language variability • 1000 speakers, 30K audio files and more than 70M trials • Open design: Recipe published at SRE11 analysis workshop [Ferrer11] • Extrinsic data simulation • Degradation of a clean interview data set from SRE’08 and ‘10 (close mics) • A variety of degradation aiming at generalization: Diversity of SNRs / reverbs to cover unseen data BEST Phase I Final review, Nov. 3rd, 2011

22. Research opportunities • Multi-feature systems • Use novel low-level features for noise robustness • Noise / Reverb robust pitch extraction algorithms • Deeper understanding of combination: Aiming for simpler systems • Information fusion at earlier stage than score level • New speech feature design? • Acoustic characterization • Deep integration of condition prediction in the pipeline • Affecting fusion weights during system combination • Integrate language and intrinsic variations • Assessing improvements on unseen data, compounded variations • Hard extrinsic variations brings up new domains of expertise borrowed from speech recognition and others (noise robust modeling, speech enhancement: De-reverberation, de-noising, binary masks, …) BEST Phase I PI conference, Nov. 29th, 2011

23. Research opportunities Relaxing constraints even more • Compounded variations: Reverb + noise + language switch • Explore new types of variations • New kinds of intrinsic variations: vocal effort (furtive, oration), Aging, Sickness • Naturally occurring reverberant and noisy speech • Other parametric relaxations • Unconstrained duration for speaker enrollment and testing (as low as a second?) • Robustness to multi-speaker audio enrollment and testing: another kind of variability: VERY important for interview data processing BEST Phase I PI conference, Nov. 29th, 2011

24. Questions?
