Presentation Transcript
objectives subsystem design
Objectives: Subsystem Design
  • Understand the purpose of Subsystem Design and where in the lifecycle it is performed
  •  Define the behaviors specified in the subsystem's interfaces in terms of collaborations of contained classes (mentioned in Use Case Design)
  •  Document internal structure of the subsystem
  •  Determine the dependencies upon elements external to the subsystem that may be needed to support the responsibilities of the interface.
subsystem design in context in the up
Subsystem Design in Context in the UP

At this time in ourDesign,

we have defined classes,

subsystems, their interfaces,

and their dependencies.

Have looked at components

or sub-systems, i.e.,

‘containers’ of complex

behavior that we have

treated as a black box.

Now we need to flesh out

the internal interactions, i.e.,

what classes exist in the

subsystemand how do they

collaborate to support

responsibilities documented

in the subsysteminterfaces.

This is what subsystem design is all about.

Architectural

Analysis

Review the

Architecture

Describe

Architectural

Describe

Architecture

Reviewer

Architect

Concurrency

Design

Distribution

Subsystem Design

Use-Case

Analysis

Review the

Use-Case

Design

Design

Design

Designer

Reviewer

Class

Design

subsystem design in context
Subsystem Design in Context

Here in subsystem design: We look at:

1) the detailed responsibilities

of the subsystem and define

and refine the classes needed

to implement responsibilities,

while

2) refining subsystem

dependencies as needed.

The internal interactions are

expressed as collaborations

of classes and possibly other

components or subsystems.

The focus is on the subsystem.

The activity is iterative and

recursive, but eventually

feeds Class Design.

Architectural

Analysis

Review the

Architecture

Describe

Architectural

Describe

Architecture

Reviewer

Architect

Concurrency

Design

Distribution

Subsystem Design

Use-Case

Analysis

Review the

Use-Case

Design

Design

Design

Designer

Reviewer

Class

Design

subsystem design overview

Design Subsystems and Interfaces

(updated)

Design Subsystems and Interfaces

DesignGuidelines

Design Classes

Use-Case Realization

(updated)

Subsystem Design Overview

Subsystem Design is performed once per Design Subsystem.

Purpose: to definethe behaviors specified in the interface via its contained classes:

to document the internal structure of the subsystem,

to define realizations between subsystem’s interface(s) and contained classes, &

to determine the dependencies upon other subsystems.

Subsystem

Design

Use-Case Realization

review subsystems and interfaces

<<subsystem>>

Subsystem Name

<<interface>>

Interface

Realization (Canonical form)

Interface

Subsystem

<<subsystem>>

Subsystem Name

Interface

Realization (Elided form)

Review: Subsystems and Interfaces
  • Subsystem is a “cross between” a package and a class
    • Has semantics of a package
      • (i.e., can contain other model elements)
    • and a class (has behavior).
  • Subsystem realizes one or more interfaces which define its behaviors
review subsystems and interfaces7

<<subsystem>>

Subsystem Name

<<interface>>

Interface

Realization (Canonical form)

Interface

Subsystem

<<subsystem>>

Subsystem Name

Interface

Realization (Elided form)

Review: Subsystems and Interfaces
  • An interface is a model element which defines a set of behaviors (set of operations) offered by a classifier model element (e.g., class, subsystem or component).
  •  A classifier may realize one or more interfaces.
  •  An interface may be realized by one or more classifiers.
review subsystems and interfaces8

<<subsystem>>

Subsystem Name

<<interface>>

Interface

Realization (Canonical form)

Interface

Subsystem

<<subsystem>>

Subsystem Name

Interface

Realization (Elided form)

Review: Subsystems and Interfaces
  • Interfaces are not classes; provide no default behavior.
  • Realization is a semantic relationship between two classifiers – one serves as contract (the interface ‘class’) ; other, carries it out that is ‘realizes’ the contract.
    • via its subsystem contents and its dependencies
subsystem guidelines

<<subsystem>>

A

<<subsystem>>

B

<<subsystem>>

C

Key is abstraction and encapsulation

Subsystem Guidelines
  • Goals
    • Loose coupling; as independent as possible
    • Insulation from change - minimized
    • Replaceable elements in the model.
  • Strong Suggestions for Subsystems:
    • Don’t expose details, only the interfaces
    • No element contained by a subsystem should

have public visibility.

    • No elementoutside the subsystem should depend

on a particular element inside the subsystem.

    • Only depend on interfaces of other model

elements so that it is not directly dependent on

any specific model element outside the subsystem.

subsystem guidelines10

<<subsystem>>

A

<<subsystem>>

B

<<subsystem>>

C

Key is abstraction and encapsulation

Subsystem Guidelines

Exception: can share some class definitions

done with packages in lower layers to ensure

common definition of classes which must pass

between subsystems

All dependencies on a subsystem should be

dependencies on the subsystem interfaces only!!

 clients not dependent on inside!

 subsystem can be replaced by different

subsystem that realizes same interface.

modeling convention for subsystems and interfaces

<<subsystem>>

CourseCatalogSystem

<<subsystem proxy>>

CourseCatalogSystem

ICourseCatalogSystem

Modeling Convention for Subsystems and Interfaces

Represent subsystems as three items in model:

1. <<subsystem>> package;

2. <<subsystem proxy>> class,

3. subsystem interface (class with stereotype <<interface>>).

Subsystem package provides a container for the elements in the subsystem.

The interaction diagrams describe how the

subsystem elements collaborate to

implement the operations of the

interface the subsystem realizes,

Note: <<subsystem proxy>>

class actually realizes the

interface and will orchestrate

the implementation of the

subsystem operations.

Different (additional) interfaces would have their own proxy!

subsystem design major steps
Subsystem Design: Major Steps
  • Distribute Subsystem behaviors to Subsystem Elements
    • that is, the design components inside the subsystem.
  • Next, Document Subsystem Elements (e.g. classes…)
  • Document internal structural relationships among classes
  • Then document the interfaces upon which the subsystem itself is dependent.
  • Then, review the results of your subsystem design.
  • Now, let’s look at each of these
subsystem responsibilities

<<subsystem>>

CourseCatalogSystem

<<interface>>

ICourseCatalogSystem

getCourseOfferings()

Subsystem Responsibilities
  • Subsystem responsibilities defined by the interface it realizes
  •  When a subsystem realizes an interface, it makes a commitment to support every operation defined by the interface.
  •  Interface operations may be realized by
    • Internal class operations (which may require collaboration with other classes or subsystems)
    • An interface realized by a contained subsystem.

subsystem responsibility

modeling convention subsystem interaction diagrams general
Modeling Convention: Subsystem Interaction Diagrams - General

Design Element 2

Subsystem Proxy

Design Element 1

Subsystem Client

performResponsibility( )

Op1()

subsystem responsibility

Internal subsystem interactions

Op2()

Op3()

Op4()

Subsystem interface not shown

modeling convention subsystem interaction diagrams general15
Modeling Convention: Subsystem Interaction Diagrams - General

Design Element 2

Subsystem Proxy

Design Element 1

Subsystem Client

performResponsibility( )

Op1()

subsystem responsibility

Internal subsystem interactions

Op2()

Op3()

Op4()

  • A message should be drawn from the <<subsystem>> client to the <<subsystem proxy>>
  • Note: interfacedoes not appear on internal subsystem interaction diagram.
  • Remainder of diagram should model howthe <<subsystem proxy>>classdelegates
  • responsibility for performing the invoked operation to the other subsystem elements.
  •  Recommend you name the interaction diagram <interface name>::<operation name>>.
  • This convention simplifies future tracing of interface behaviors to the classes implementing the
  • interface operations.
example coursecatalogsystem subsystem in context 1 of 2
Example: CourseCatalogSystem Subsystem In Context (1 of 2)

subsystem interface

: RegisterForCoursesForm

: RegistrationController

: ICourseCatalogSystem

: Schedule

: Student

: Student

1: // create schedule( )

2: // get course offerings( )

Student wishes to

3: getCourseOfferings(Semester)

create a new

schedule

subsystem responsibility

4: // display course offerings( )

A list of the available

  • This sequence diagram sets the context of what will be performed in Subsystem Design.
  • Puts requirements on the subsystem, and
  • Is the primary input specification to the
  • task of creating local interactions
  • within the subsystem.

course offerings for this

semester are displayed

Note: I have ‘cut’ a lot of detail

out of this sequence diagram and

the next one so that it is ‘easy’ to

see the thrust of this slide…

example coursecatalogsystem subsystem in context 2 of 2
Example: CourseCatalogSystem Subsystem In Context (2 of 2)

subsystem interface

: RegisterForCoursesForm

: RegistrationController

: ICourseCatalogSystem

: Schedule

: Student

: Student

1: // create schedule( )

2: // get course offerings( )

3: getCourseOfferings(Semester)

subsystem responsibility Legacy RDBMS

Database Access

  • The ICourseCatalogSystem::getCourseOfferings()
  • documentation specifies: “Retrieve the course
  • offerings available for the specified semester.”
  • So retrieval of the course offerings from legacy
  • database is responsibility of CourseCatalog system.
  • Now, must show exactly HOW this is done using the
  • RDBMS persistency mechanism. This will be shown
  • when we actually do the subsystem design (ahead)
review incorporating jdbc steps of steps
Review: Incorporating JDBC: Steps of Steps
  • (Done:) Provide access to the class libraries needed to implement JDBC; (i.e., Provide java.sql package)
  • (Done. Seen in Persistency:) Create the necessary DBClasses and their dependencies (for objects requiring persistency)
    • Remember, the proxy class is the class that manages the responsibilities of the subsystem as found in its interface.
    • You may think of it as a ‘control class’ for a particular interface.
  • Review slide 14 (and others) in lecture 29. DBClass and PersistentClassList and PersistentClass (and others) were stereotyped <<role>>, which implied their specific implementation is built by the designer when applying a mechanism such as persistency, legacy database access, etc.
    • Recall DBClass had methods like read(), update(), delete() create()…
  • In the next couple of slides, we are doing exactlythat with the DBCourseOffering class in attempting the access the legacy RDBMS to read data, execute a query, and more.
  • We have a DBCourseOffering along with CourseOfferingList and a CourseOffering to get results from executeQuery() (ahead)

(continued)

slide19
more
  • Note also that the Course Catalog System is clearly an Actor, which, of course, it should be, AND it is shown as such – in place – in the Sequence Diagram.
  • Note that the proxy class, DBCourseOffering, and the objects within java.sql are all involved in constituting the interface with the legacy RDBMS system.
  • So, we are seeing HOW the Course Catalog Subsystem via the proxy class and its dependencies are handling responsibilities.
  • Note that the next couple of slides do NOT have the caveat ‘Context.’
    • They do not show the context for the subsystem or its interface; rather, this is the design implementation of the interface!
    • This is the subsystem design.
ex local coursecatalogsystem subsystem interaction

CourseCatalog

:

:

: Connection

: Statement

:

:

: ResultSet

: Course Catalog

System Client

CourseCatalogSystem

DBCourseOffering

CourseOfferingList

CourseOffering

1. getCourseOfferings(Semester)

Retrieve all available course

offerings for the current

semester

1.1. read(string)

1.1.1. createStatement( )

sql statement is passed in

1.1.2. executeQuery(String)

specifying the search criteria --

course offerings in the current

1.1.2.1. // executeQuery( )

semester

Create a list to hold all

retrieved course offerings

1.1.3. new( )

Repeat these operations for each

element returned from the

executeQuery() command.

1.1.4. new( )

The CourseOfferingList is loaded

with the data retrieved from the

2. getString( )

database.

3. setData( )

The getData and setData

operations are called for each

attribute in the each retrieved

4. add(CourseOffering)

class instance.

Add the retrieved course offering

to the list to be returned

Ex: Local CourseCatalogSystem Subsystem Interaction
  • Internals of subsystems should yield interaction diagrams
  • that look like this.
  • We seecollaborations to implement the getCourseOfferings
  • operation of the ICourseCatalogSystem interface.
  • Recall: legacy system stores course offerings in an RDBMS.
  • Here we show how the RDBMS persistency mechanism
  • identified in Architectural Design is realized in the design.

Subsystem Proxy

(represents Subsystem)

RDBMSRead

CourseCatalogSystem (proxy) is in subsystem. DBCourseOffering object is created by designer

(think DBClass in past lectures) as needed persistency and legacy interfacing.

There is a dependency between the DBCourseOfferings and objects in java.sql starting with

Connection and the actual access to the RDBMS via actor CourseCatalog.

Note the design objects: CourseOfferingList and CourseOffering (no longer <<role>>

ex local coursecatalogsystem subsystem interaction21

CourseCatalog

:

:

: Connection

: Statement

:

:

: ResultSet

: Course Catalog

System Client

CourseCatalogSystem

DBCourseOffering

CourseOfferingList

CourseOffering

1. getCourseOfferings(Semester)

Retrieve all available course

offerings for the current

semester

1.1. read(string)

1.1.1. createStatement( )

sql statement is passed in

1.1.2. executeQuery(String)

specifying the search criteria --

course offerings in the current

1.1.2.1. // executeQuery( )

semester

Create a list to hold all

retrieved course offerings

1.1.3. new( )

Repeat these operations for each

element returned from the

executeQuery() command.

1.1.4. new( )

The CourseOfferingList is loaded

with the data retrieved from the

2. getString( )

database.

3. setData( )

The getData and setData

operations are called for each

attribute in the each retrieved

4. add(CourseOffering)

class instance.

Add the retrieved course offering

to the list to be returned

Ex: Local CourseCatalogSystem Subsystem Interaction
  • To read the course offerings, the persistency client requests
  • a service from the subsystem interface, represented by the
  • proxy class, who asks the DBCourseOffering class to retrieve a
  • course offerings for the specified semester.
  • DBCourseOffering creates a new statement using Connection
  • class’s createStatement() operation.
  • The statement is executed; data is returned to ResultSet object.
  • DBCourseOffering then creates a list of CourseOffering
  • instances, CourseOfferingList, populates it with retrieved
  • data, and returns it to the client.

Subsystem Proxy

RDBMSRead

slide22
If we have time, we’ll go through the Billing System. But the ideas are the same…
  • Idea behind the Billing System is almost the same, but the Billing System does not require a persistency mechanism.
  • Start with the Billing subsystem interface object in the next slide at the end…
  • Really showing how the submitBill(Student, double) is implemented in the subsystem. But first:
  • Billing System in Context – then Local
example billing system subsystem in context
Example: Billing System Subsystem In Context

subsystem interface

:

:

:

:

: Schedule

: Student.

:

: Registrar

CloseRegistrationForm

CloseRegistrationController

ICourseCatalogSystem

CourseOffering

IBillingSystem

  • Here, will demonstrate design of a subsystem that does
  • not require a persistency mechanism.
  • This is at portion of the Close Registration use-case
  • realization sequence diagram.
  • The internals of the Billing System Subsystem
  • have not been designed yet. That is
  • the purpose of this activity, Subsystem Design

1. // close registration( )

1.1. // is registration open?( )

Retrieve a list of course

offerings for the current

semester

2. // close registration( )

Close

registration for

2.1. getCourseOfferings(Semester)

each course

Repeat twice this is

If the maximum number of

offering

for simplicity;

selected primary courses have

2.2. // close registration( )

realistically, an

not been committed, select

indefinite number of

alternate course offerings).

iterations could

occur)

2.3. // level( )

Finally commit or

2.4. // close( )

Currently assuming tuition based on

cancel the course

number of offerings taken and certain

offering once all

attributes of students. If different offerings

leveling has occurred

get different prices this will change slightly.

2.5. getTuition( )

Send student and tuition to

the Billing System, which will

do the actual billing to the

2.6. submitBill(Student, double)

student for the schedule.

subsystem responsibility

Now, we are really after the next slide…

example billing system subsystem in context24
Example: Billing System Subsystem In Context

subsystem interface

:

:

:

:

: Schedule

: Student.

:

: Registrar

CloseRegistrationForm

CloseRegistrationController

ICourseCatalogSystem

CourseOffering

IBillingSystem

  • Here we put requirements on the subsystem, and
  • the sequence diagram is the primary input spec to
  • creating local interactions for the subsystem.
  • We see the operations subsystem must support. Shows
  • the simple way some client (CloseRegistrationController
  • here) deals with the task of submitting bill to
  • the legacy Billing System.

1. // close registration( )

1.1. // is registration open?( )

Retrieve a list of course

offerings for the current

semester

2. // close registration( )

Close

registration for

2.1. getCourseOfferings(Semester)

each course

Repeat twice this is

If the maximum number of

offering

for simplicity;

selected primary courses have

2.2. // close registration( )

realistically, an

not been committed, select

indefinite number of

alternate course offerings).

iterations could

occur)

2.3. // level( )

Finally commit or

2.4. // close( )

Currently assuming tuition based on

cancel the course

number of offerings taken and certain

offering once all

attributes of students. If different offerings

leveling has occurred

get different prices this will change slightly.

2.5. getTuition( )

Send student and tuition to

the Billing System, which will

do the actual billing to the

2.6. submitBill(Student, double)

student for the schedule.

subsystem responsibility

More coming…

slide25

Explanation for next slides

  • The IBillingsystem::submitBill() documentation specifies
  • the following: “Billing information must be converted
  • into a format understood by the external Billing System
  • and then submitted to the external Billing System.
  • Thus the actual generation and submission of the bill is responsibility of the Billing System subsystem once the bill and proper parameters are passed to it.
  • But the billing information must be converted into a format that the Billing System can understand.
  • Let’s see how allthis is done…
example local billingsystem subsystem interaction
Example: Local BillingSystem Subsystem Interaction

Subsystem Proxy

Billing System

:

:

: Student.

:

: Billing System

Client

BillingSystem

StudentBillingTransaction

BillingSystemInterface

1. submitBill(Student, double)

Retrieve the

information that must

be included on the bill

1.1. create(Student, double)

1.1.1. // get contact info( )

1.2. submit(StudentBillingTransaction)

Logic here must convert the contract info

into a format (StudentBillingTransaction)

that the Billingsystem can understand.

Given this, the proxy will orchestrate

opening, processing, and closing the

connection (and submitting the bill).

No DBCourseOffering is needed here

But StudentBillingTransaction is designed to convert

data into a form the Billing System can understand

from Student information and the ‘double.’

We simply see HOW the subsystem interface is realized.

1.2.1. // open connection( )

1.2.2. // process transaction( )

1.2.3. // close connection( )

example local billingsystem subsystem interaction27
Example: Local BillingSystem Subsystem Interaction

Subsystem Proxy

Billing System

:

:

: Student.

:

: Billing System

Client

BillingSystem

StudentBillingTransaction

BillingSystemInterface

1. submitBill(Student, double)

Retrieve the

information that must

be included on the bill

1.1. create(Student, double)

1.1.1. // get contact info( )

1.2. submit(StudentBillingTransaction)

1.2.1. // open connection( )

  • The client object initiating the interaction
  • is abstracted. Again, we don’t care…
  • The BillingSystem subsystem proxy
  • class actually realizes the
  • IBillingSystem interface and drives this
  • realization by delegating the
  • implementation of the interface to the
  • subsystem elements.

1.2.2. // process transaction( )

1.2.3. // close connection( )

example local billingsystem subsystem interaction28
Example: Local BillingSystem Subsystem Interaction

Subsystem Proxy

Billing System

:

:

: Student.

:

: Billing System

Client

BillingSystem

StudentBillingTransaction

BillingSystemInterface

  • The BillingSystem proxy class instance
  • creates a StudentBillingTransaction
  • specific to the external Billing System.
  • This transaction will be in a format that
  • the Billing System can process.
  • The StudentBillingTransaction knows
  • how to create itself using information
  • from the given Student.

1. submitBill(Student, double)

Retrieve the

information that must

be included on the bill

1.1. create(Student, double)

1.1.1. // get contact info( )

1.2. submit(StudentBillingTransaction)

Note that only a single message is

sent to the proxy: submitBill(…)

The proxy, then, implements this

responsibility by calling

create(Student,double) and

submit(StudentBillingTransaction).

1.2.1. // open connection( )

1.2.2. // process transaction( )

1.2.3. // close connection( )

After creating the StudentBillingTransaction, the BillingSystem

proxy class instance submits the transaction to the class

instance that actually communicates with the Billing System.
