  1. Testing systems with deferred reactions CTesK Training Course

  2. A scenario of using Event Monitor Listener1 Listener2 EventMonitor ControlCenter register( "host1:2024" ) register( "host2:2381" ) event( "S12 failed" ) notify( "S12 failed" ) notify( "S12 failed" ) unregister( "host1:2024" ) event("S12 restarted") notify( "S12 restarted" )

  3. Internal interface of Event Monitor void event( const char* event_description );

  4. notify event External interface of Event Monitor register, unregister "R|host:port" - registration request "U|host:port" - unregistration request "N|event_desc" - event notification

  5. Support library of Event Monitor void register_listener( const char* addr ); void unregister_listener( const char* addr );

  6. dfsm Scenario Oracle Mediator SUT event_scen( y1, y2 ) event_spec( y1 ) event_media( y1 ) even( y1 ) Wait “N|y1” “N|y1” { (x1,y1), (x2,y1) } {(x1,y1), (x2,y1)}, verdict event_spec( y2 ) event_media( y2 ) event( y2 ) Wait “N|y2” “N|y2” { (x1,y2), (x2,y2) } {(x1,y2), (x2,y2)}, verdict verdict Initial state:x1 andx2 are registered.

  7. dfsm Scenario Oracle Mediator SUT unreg_event_scen( x1, y ) unreg_spec( x1 ) unreg_media( x1 ) “U|x1” void verdict event_spec( y ) event_media( y ) event( y ) Wait “N|y” { notify(x2,y) } { notify(x2,y) }, verdict verdict Initial state:x1 andx2 are registered.

  8. dfsm Scenario Oracle Mediator Catcher SUT unreg_event_scen( x1, y ) unreg_spec( x1 ) unreg_media( x1 ) “U|x1” void verdict event_spec( y ) event_media( y ) event( y ) void “N|y” to x2 verdict verdict Wait getReactions() { notify(x2,y) } Serialize
