Presentation Transcript
slide1

PROGRESS OVERVIEW:

COLTO STANDARD SPECIFICATIONS

TMH AND TRH DOCUMENTS

OTHER DOCUMENTS

slide2

COLTO STANDARD SPECIFICATIONS

  • Prepared Business Plan for RCB
  • Formation of RCB Subcommittee
  • RCB Subcommittee Membership
    • National DOT
    • 9 Provincial Road Authorities
    • Municipal Authorities (Metro’s)
    • SANRAL (SA National Roads Agency Ltd)
    • RAL (Road Agency Limpopo)
    • JRA (Johannesburg Road Agency)
slide3

COLTO STANDARD SPECIFICATIONS

  • Stakeholders identified for consultation:
slide4

COLTO STANDARD SPECIFICATIONS

  • Procurement of Secretariat for the Revision of the Document
    • RCB Subcommittee to nominate list of service providers (April 2008)
    • SANRAL to prepare tender documents (May 2008)
    • SANRAL to invite nominated service providers (June 2008)
    • SANRAL to appoint service providers (July 2008)
slide5

COLTO STANDARD SPECIFICATIONS

  • Programme
    • Subcommittee will set up programme
    • Estimated completion time – 18 to 24 months
  • Funding
    • All RCB subcommittee members to contribute
    • Estimated cost of project ± R4million
slide6

TMH AND TRH DOCUMENTS

2 500 People have visited the SANRAL website to download documents

  • TMH1 Revision
    • The final revised drafts were submitted to SABS in January 2008
  • SET A – Covers roughly A1 to A5 of TMH1
  • 3001-GR1 The Wet Preparation and Particle Size Analysis of Graded Materials.
  • 3001-GR10 The Determination of the One-Point Liquid Limit, Plastic Limit, Plasticity Index and Linear Shrinkage.
  • 3001-GR11 The Determination of the Liquid Limit, Two-Point Method.
  • 3001-GR12 The Determination of the Liquid Limit, Flow Curve Method.
  • 3001-GR20 The Determination of Moisture Content by Oven-Drying.
slide7

TMH AND TRH DOCUMENTS

  • SET B – Covers roughly A6 and B18 of TMH1 and two new methods
  • 3001-GR2 The Dry Preparation and Dry Particle Size Analysis of Graded Materials.
  • 3001-AG2 The Determination of the Average Least Dimension of Aggregates by Direct Measurement.
  • 3001-PR2 The Determination of the Average Least Dimension of a Surfacing Aggregate by Computation.
  • 3001-PR3 The Computation of soil-mortar percentages, coarse sand ratio, grading modulus and fineness modulus.
  • SET C – Covers A7 and A8 of TMH1
  • 3001-GR30:06 The Determination of the maximum dry density and optimum moisture content of graded materials.
  • 3001-GR31:06 The Determination of the California Bearing Ratio of graded materials.
slide8

TMH AND TRH DOCUMENTS

  • The production of essential normative reference methods which are being done in the next phase were needed before SABS can publish Sets A to C.
  • Work on next phase (Sets 1 to 5) is progressing well

SET 1

  • 3001-AG1 The particle size analysis of aggregates by sieving. **
  • 3001-AG3 The determination of the flakiness index of coarse aggregate.
  • 3001-AG10 Aggregate crushing value of coarse aggregates.
  • 3001-AG11 FACT value (10% fines aggregate crushing value) of coarse aggregates.
  • 3001-AG20 The determination of the dry bulk density, apparent relative density and water absorption of material retained on the 5mm sieve.
  • 3001-AG21 The determination of the dry bulk density, apparent relative density and water absorption of material passing the 5mm sieve.

** Needs to be given priority as it is required as a normative reference for methods in Pilot Stage.

slide9

TMH AND TRH DOCUMENTS

SET 2

  • 3001-GR31 The determination of the maximum dry density and optimum moisture content of laboratory mixed stabilized graded materials.
  • 3001-CO1 Mixing in the laboratory, sampling of freshly mixed concrete, casting and curing of test specimens.
  • 3001-CO2 Consistency of freshly mixed concrete – the determination of the slump.
  • 3001-C10 Dimensions, tolerances and uses of cast test specimens.
  • 3001-C11 Compressive strength of matured concrete.
  • 3001-PR10 The handling, maintenance and sieving techniques for test sieves. **
  • ** Needs to be given priority as it is required as a normative reference for methods in Pilot Stage.
slide10

TMH AND TRH DOCUMENTS

SET 3

First drafts have been submitted by SABITA to their members for comment.

MTC had a meeting in January 2008 with SABITA regarding these test methods.

  • 3001-AS1 Making of briquettes for Marshall tests
  • 3001-AS2 The determination of Marshall flow and stability
  • 3001-AS10 The determination of bulk relative density and void content of compacted asphalt
  • 3001-AS11 The determination of the maximum theoretical relative density of asphalt mixes and the quantity of binder absorbed by the aggregate
  • 3001-AS20 The determination of the binder content of a bituminous mixture (indirect method).
slide11

TMH AND TRH DOCUMENTS

SET 4

Second drafts have been prepared based on industry feedback.

  • 3001-GR31 The determination of the maximum dry density and optimum moisture content of laboratory mixed stabilized graded materials.
  • 3001-GR50 The preparation, compaction, and curing of specimens of laboratory mixed stabilized graded materials.
  • 3001-GR51 Sampling, preparation, compaction and curing of field mixed freshly stabilized graded materials including the determination of the maximum dry density and optimum moisture content.
  • 3001-GR52 Sampling and preparation of cored specimens of field compacted matured stabilized graded material.
  • 3001-GR52 The determination of the Unconfined Compressive Strength of stabilized graded materials.
  • 3001-GR53 The determination of the Indirect Tensile Strength of stabilized graded materials.
slide12

TMH AND TRH DOCUMENTS

SET 5

  • 3001-BT20 Calibration of dipsticks for bitumen distributors
  • 3001-BT22 Power and road speed indicator tests for bitumen distributors
  • 3001-BT23 Pump system performance for bitumen distributors
  • 3001-BT24 Test for measuring the transverse distribution of a bitumen distributor (“Bucket” test)
slide13

TMH AND TRH DOCUMENTS

  • Busy with second drafts on stabilization
  • Investigation into calibration, validation and standard blocks for nuclear gauges was completed in December 2007.
  • Will not submit further material to SABS until they have made progress with pilot phase. (Sets A to C)
slide14

TMH AND TRH DOCUMENTS

  • TRH Revisions
    • TRH 12: Road Rehabilitation Guidelines – Feedback by Dr Jordaan
    • TRH 20: The structural design construction and maintenance of unpaved roads.
slide15

OTHER DOCUMENTS

  • Routine Road Maintenance Guideline Document
    • Busy with revision of final draft
    • Plan to have workshops in June 2008
slide16

OTHER DOCUMENTS

  • South African Materials Manual
    • Finalised frame work / scope of work
    • Task team approved
    • Made PDF’s of Road Authority Manuals
    • Need to set up meeting with Task Team to discuss:
      • Scope of work
      • Hourly rate
      • Timelines
      • Task leaders
