Modern Compiler Design

1. 1 Mooly Sagiv and Greta Yorsh School of Computer Science Tel-Aviv University gretay@post.tau.ac.il http://www.cs.tau.ac.il/~gretay Modern Compiler Design

2. 2 TA1 Submit 08/12/04 today after class or 09/12/04 tomorrow to my mail box Schreiber 271 Questions � after the session

3. 3 Course Requirements Compiler Project 60% Theoretical Assignments 5% Exam 35% (must pass to get credit)

4. 4 PA2 Average grades automatic 88 manual 91 total 89 Main pitfalls special characters in strings newline and EOF in comments too long strings

5. 5 Today Goals Implementing Type Checking for Cool Cool Type Rules Next week MIPS Recap � short (longer at the last session 15-16) Stack Frames

6. 6 Major Semantic Tasks Inheritance graph construction and checking Symbol table construction construct symbol table for features using inheritance tree assign enclosing scope for each AST node Scope checking check program using symbol tables Check for Main class and main method Type checking uses inheritance graph and symbol tables assign type for each AST node

7. 7 Inheritance Graph What do we put in it? all predefined classes: Int, String, Bool, Object, IO all user-defined classes Why do we put it there ? to be able to check that something is a type to be able to compare types (for type checking)

8. 8 Implementation Mapping class names to nodes in the graph For each node keep parent (and children) in the inheritance graph is the class reachable/unreachable from the Object class via the "inherits from" relation? Compare types by comparing Symbols Compare types by comparing Symbols

9. 9 Check Inheritance Graph Local properties - do not require traversing inheritance graph base class is defined base class can be inherited from Global properties find all classes reachable from root class Object check that it really is a tree (no cycles)

10. 10 Major Semantic Tasks Inheritance graph construction and checking Symbol table construction construct symbol table for features using inheritance tree assign enclosing scope for each AST node Scope checking check program using symbol tables Check for Main class and main method Type checking uses inheritance graph and symbol tables assign type for each AST node

11. 11 Semantic Checks Scope rules identifiers are defined no multiple definition of same identifier local variables are defined before used program conforms to scope rules Type rules which types can be combined with certain operator assignment of expression to variable formal and actual parameters of a method call

12. 12 Type Checking - example

13. 13 Type Checking - Implementation Single traversal over AST Types passed up the tree Type environment passed down the tree

14. 14 Example

15. 15 Example

16. 16 Cool Types How types are represented ? Symbol compare types by comparing Symbols When are types are created? during lexer/parsing predefined types

17. 17 Cool Types The types are Class Names SELF_TYPE The user declares types for identifiers The semantic analysis infers types for expressions Every expression has a unique type A language�s type system specifies which operations are valid for which types The goal of type checking is to ensure that operations are used with the correct types Enforces intended interpretation of values Cool is statically typed: type checking during compilation

18. 18 Cool Types O, M, K ? e: T O --- mapping Object Id�s to types types to free identifiers in the current scope O(x) = T O(T/y) --- O modified to return T on argument y M --- mapping methods to method signatures M(C, f) = (A, B, D) means there is a method f(a:A, b:B): D defined in class C (or its ancestor) there maybe a method and an object id with the same name K --- the class in which expression e appears when SELF_TYPE is involved

19. 19 Type rules O, M, K ? e1 : Int O, M, K ? e2 : Int O, M, K ? e1 + e2 : Int Rules give templates describing how to type expressions By filling the templates, we can produce complete typings for expressions

20. 20 Subtyping Define a relation ? on classes X ? X X ? Y if X inherits from Y X ? Z if X ? Y and Y ? Z A ? C B ? Object E ? D and D ? E

21. 21 Least Upper Bounds lub(A,B) = C lub(C,D) = D lub(C,E) = Object In Cool, the least upper bound of two types is their least common ancestor in the inheritance tree

22. 22 Least Upper Bounds Z is the least upper bound of X and Y lub(X, Y)=Z X ? Z and Y ? Z Z is upper bound X ? Z� and Y ? Z� ? Z ? Z�Z is the least upper bound

23. 23 Dynamic and Static Types in Cool A variable of static type A can hold the value of static type B if B ? A

24. 24 Dynamic and Static Types The dynamic type of an object is the class that is used in the new expression a runtime notion even languages that are statically typed have dynamic types The static type of an expression captures all the dynamic types that the expression could have a compile-time notion

25. 25 Soundness A type system is sound if ? e. dynamic_type(e) ? static_type(e) whenever the inferred type of e is T ( denoted by ? e : T ) Then e evaluates to a value of type ? T in all executions of the program We only want sound rules But some sound rules are better than others

26. 26 Assign

27. 27 Let Rule with Initialization Both rules are sound but more programs typecheck with the second one uses subtyping

28. 28 If-Then-Else

29. 29 Case

30. 30 Dispatch

31. 31 Static Dispatch

32. 32 SELF_TYPE Example What can be a dynamic type of object returned by foo() ? any subtype of A

33. 33 SELF_TYPE Research idea Helps type checker to accept more correct programs C,M,K ? (new A).foo() : A C,M,K ? (new B).foo() : B SELF_TYPE is NOT a dynamic type Meaning of SELF_TYPE depends on where it appears textually

34. 34 Where can SELF_TYPE appear ? Parser checks that SELF_TYPE appears only where a type is expected How ? But SELF_TYPE is not allowed everywhere a type can appear

35. 35 Where can SELF_TYPE appear ? class T1 inherits T2 { � } T1, T2 cannot be SELF_TYPE x : SELF_TYPE attribute let case new SELF_TYPE creates an object of the same type as self foo@T(e) T cannot be SELF_TYPE foo(x:T1):T2 {�} only T2 can be SELF_TYPE

36. 36 new Example class A { foo() : A { new SELF_TYPE }; }; class B inherits A { � } � (new A).foo(); (new B).foo();

37. 37 Subtyping for SELF_TYPE SELF_TYPEc ? SELF_TYPEc SELF_TYPEc ? C It is always safe to replace SELF_TYPEc with C SELF_TYPEc ? T if C ? T T ? SELF_TYPEc is always false because SELF_TYPEc can denote any subtype of C

38. 38 lub(T,T�) for SELF_TYPE lub(SELF_TYPEc, SELF_TYPEc) = SELF_TYPEc lub(T, SELF_TYPEc) = lub(T,C) the best we can do

39. 39 New Rules

40. 40 Other rules A use of SELF_TYPE refers to any subtype of the current class Except in dispatch because the method return type of SELF_TYPE might have nothing to do with the current class

41. 41 Dispatch which class is used to find the declaration of foo() ? It is safe to use the class where the dispatch appears

42. 42 Example class A { foo() : A { self }; }; class B inherits A { � } � (new A).foo(); (new B).foo();

43. 43 Static Dispatch

44. 44 SELF_TYPE Example

45. 45 Error Recovery Error detection is easy What type is assigned to an expression with no legitimate type ? influences type of enclosing expressions cascading errors let y : Int ? x + 2 in y + 3 Better solution: special type No_Type inheritance graph can be cyclic

46. 46 Major Semantic Tasks Inheritance graph construction and checking Symbol table construction construct symbol table for features using inheritance tree assign enclosing scope for each AST node Scope checking check program using symbol tables Check for Main class and main method Type checking uses inheritance graph and symbol tables assign type for each AST node Remaining Semantic Checks checks that require type + symbol table information combined Disclaimer: This is a na�ve phase ordering. Phases could be mixed, combined, optimized, re-ordered etc.
