Presentation Transcript
slide1

Scrap Convergence Plan

Wuhan lens line #1

Update Feb 5th

Frédéric MORET

Feb 5, 2007

scrap convergence plan wuhan lens line 1 background
Scrap Convergence Plan – Wuhan lens line #1Background
  • Wuhan lens line #1 results were:
    • > 50% scrap rate
    • < 40% normal capacity

since it started in April 2006

scrap convergence plan wuhan lens line 1 background3
Scrap Convergence Plan – Wuhan lens line #1 Background
  • VLS fast recovery plan
    • 20% scrap rate target by end of Jan 07 for Wuhan lens line #1
    • Branch coating specialist staying in Wuhan forcing results
    • No recorded scrap improvement after 2 months
    • Decision to launch scrap convergence plan on Jan 3 in order to achieve VLS fast recovery plan target
scrap convergence plan wuhan lens line 1 scope
Scrap Convergence Plan – Wuhan lens line #1 Scope
  • To reduce Wuhan lens line #1 average scrap rate:
    • From >50 to 20% from February 1st, 2007
    • From 20 to 10% from April 1st, 2007
  • Include trainings & networking to keep consistent results over time
scrap convergence plan wuhan lens line 1 latest scrap production weekly results
Scrap Convergence Plan – Wuhan lens line #1 Latest scrap & production weekly results

Arrival of Branch team. Reduction of cycle times

W2 & 3: Trials & tunings resulting in scrap

Close to target before Feb 1st

scrap convergence plan wuhan lens line 1 agenda of presentation
Scrap Convergence Plan – Wuhan lens line #1 Agenda of presentation
  • Step II: Achievements & status
    • Team, organization & trainings
    • Capacity
    • Equipment
    • Molding
    • Coating
    • Inspection
  • Step III: Action plan & expected results
scrap convergence plan wuhan lens line 1 team
Scrap Convergence Plan – Wuhan lens line #1 Team

Decision for new organization

Arrival of Branch team in Wuhan

2 people in charge of new T21 jigs

Integration of 2 jig makers

Production of W5 totally managed by Wuhan team without any support of Branch team

scrap convergence plan wuhan lens line 1 organization
Scrap Convergence Plan – Wuhan lens line #1 Organization

Change in organization

since Jan 26, 2007 to restore

« process » APU structure

« Product » APU organization

since Sept 1, 2006

People having background

to manage lens line

Champion for lens line scrap reduction

Future Champion for lens scrap reduction to be coached by present one

Champion for HL assembly

scrap convergence plan wuhan lens line 1 trainings
Scrap Convergence Plan – Wuhan lens line #1 Trainings
  • Trainings done
    • In meeting room
      • 5 courses
        • Reaction modes for:
          • Molding defects
          • Grain defect (varnishing)
          • Fallen lens & varnish dot defects (varnishing)
        • Inspection
          • IRIS
          • Lens inspection
      • 30-35 people attending each time
  • OJT
    • 5 trainings
      • Supplier for jig manufacturing
      • Production team for jig tuning
      • Production team for molding
      • Maintenance team
      • Quality inspection
scrap convergence plan wuhan lens line 1 documentation
Scrap Convergence Plan – Wuhan lens line #1 Documentation
  • Database
    • All results & documents related to this plan, including updated action plans
    • All data related to lens line & its maintenance
  • Booklet
    • Reaction modes
    • Working instructions
    • Main messages of trainings
scrap convergence plan wuhan lens line 1 organization11
Scrap Convergence Plan – Wuhan lens line #1 Organization
  • Further improvements of the team
    • Coaching of line supervisor by APU manager
    • Varnishing method engineer position to fill
scrap convergence plan wuhan lens line 1 capacity
Scrap Convergence Plan – Wuhan lens line #1 Capacity
  • Capacity issue because of low « real » TRS
  • Snowball effect
    • Not enough capacity
    • No time to improve
    • More inefficiency
  • 1st priority has been to recover capacity and to use it for improving:
    • Reduce injection cycle time (-24%)
    • Reduce changeover time by installing a fork on press platen (-30%)
    • Learn team how to avoid stoppages
    • Do not accept new product trials which are not mandatory
scrap convergence plan wuhan lens line 1 equipment
Scrap Convergence Plan – Wuhan lens line #1 Equipment
  • No major issue on equipment & maintenance
    • Haitian press & Wittmann robot
      • No major issue
      • Maintenance action plan done: Hot runner heater changed, robot gear changed
    • Saico line
      • No major issue
      • Maintenance globally well done
      • Maintenance action plan done: 13 improvements, detailed maintenance documents
scrap convergence plan wuhan lens line 1 achievements status
Scrap Convergence Plan – Wuhan lens line #1 Achievements & Status
  • Molding
    • Molds
      • X11J: No major issue
      • R23: Small crack issue, solved by team (change in tool)
      • T21: Silver streak (5%) because of poor design & making of tool, cannot be solved by process, needs a tool improvement (on-going action plan). Design of new tool (expected by end of March) checked.
    • Operation
      • Black dot scrap reduced by avoiding stoppages and respect of re-start instruction
scrap convergence plan wuhan lens line 1 achievements status15
Scrap Convergence Plan – Wuhan lens line #1 Achievements & Status
  • Coating
    • Jigs
      • For all: poor making and bad tuning
        • In-feed conveyor: All jigs tuned as well as possible, new jig design tested on Feb 1st
        • Varnishing conveyor:
          • X11J & R23: Tuning of jig improved
          • T21: New design of jig tested, complete new set done, installed on Feb 1st
    • Process
      • No major issue, some flow-coater tunings have been improved
    • Operation
      • Bad jig design and tuning results in many door opening (to set lens on jig) and so many grain and varnish dot defects. Improved by team, still possible to improve.
scrap convergence plan wuhan lens line 1 jig sub project
Scrap Convergence Plan – Wuhan lens line #1 Jig sub-project
  • Design & manufacturing of new T21 jigs as a project
    • Selection of supplier (8 visited), 1 selected
      • Good design & manufacturing means, but no autonomy in design & manufacturing
    • Training of supplier for design, prototyping & manufacturing
    • Making & test of prototype 1: OK
    • Making & test of prototype 2 (simplified design): OK
    • Making of complete set
    • Installation & tuning of complete set on Feb 1
    • Detailed manufacturing instruction provided
scrap convergence plan wuhan lens line 1 achievements status17
Scrap Convergence Plan – Wuhan lens line #1 Achievements & Status
  • Quality inspection & logistics
    • IRIS
      • Badly known and implemented resulting in overquality. Training provided, tools updated.
    • Production quality
      • Defects badly known by operators. No inspection standard per product. Setting of operator training by quality each 2 weeks. Update of all inspection standards.
      • Re-organization of line quality, in order upstream quality engineer is now in charge of auditing quality of all actions on the line.
      • QRAP restarted.
      • Rules for standard reaction defined (line QRQC). Action plan defined with quality, time schedule to be defined with APU manager and supervisor.
      • Line management: Display boards re-organized to provide just necessary up-to-date information
    • Logistics
      • Use of cardboxes, plastic bags and foam sheets for packaging WIP lenses resulting in many wastes (operator time, footprint, scrap, packaging materials). Was limitating cycle time reduction.Replaced by standard lens plastic totes.
    • Scrap follow-up sheet (Kosu sheet)
      • Sheet updated for defect definition (more precise), removal of injection trial shots. Change to be made to remove a mistake in fallen part calculation.
    • STOP Scrap
      • Standard display of trend charts and action plans for X11J and T21. Definition of scrap convergence plan actions according to STOP Scrap system.
scrap convergence plan wuhan lens line 1 step ii
Scrap Convergence Plan – Wuhan lens line #1 Step II
  • Main issues remaining on Jan 22
    • Varnish dot defect on T21 (18% of total scrap)
      • Only solution is new jig (tested, production of complete set followed-up by Marc Bourgeois)
    • Grain defect on X11J (16% of total scrap)
      • Closed door operation (to be followed-up by supervisor)
    • Silver streaks on T21 (9% of total scrap)
      • Injection process parameters to be developed by Maxime Hugol
    • Fallen parts on all products (7% of total scrap)
      • Robot & jig tuning (to be followed-up by supervisor)
    • Stoppages, maintenance & changeover delays (5% of total scraps, 40% of productive time)
      • Short mold changeover device to be used, maintenance & operation management (to be followed-up more closely by maintenance manager & supervisor)
scrap convergence plan wuhan lens line 1 step ii19
Scrap Convergence Plan – Wuhan lens line #1 Step II
  • Roadmap defined on Jan 22
    • W4: Closed door operation for X11J, jig tuning for fallen parts, closer management to reduce stoppage & changeover times
    • W5: New jig for T21, new injection process parameters for T21, jig tuning for fallen parts, closer management to reduce stoppage & changeover times
    • W6 & W7: Tunings to decrease rate of other scraps
scrap convergence plan wuhan lens line 1 step iii
Scrap Convergence Plan – Wuhan lens line #1 Step III
  • To reduce Wuhan lens line #1 average scrap rate:
    • From 20 to 10% from April 1st, 2007
  • Definition of action plans in progress
  • 2nd period of Branch team defined (3 weeks in March)
