환경공학과 200911533 김동철. EFDC Explorer 7 Overview Part 1. Overview of EFDC_Explorer7 Capabilities and Features EFDC_Explorer7 기능 및 특징 개요. agenda overview of EFDC introduction to EFDC Model model architecture EFDC Features EFDC_DSI Enhancements Overview of EFDC_Explorer Ver7
E N D
환경공학과 200911533 김동철 EFDC Explorer 7 Overview Part 1
Overview of EFDC_Explorer7 Capabilities and Features EFDC_Explorer7 기능 및 특징 개요
agenda overview of EFDC • introduction to EFDC Model • model architecture • EFDC Features • EFDC_DSI Enhancements • Overview of EFDC_Explorer Ver7 • Model Setup • Model Calibration • Visualizations • Overview of Constituent Sub-models 목록 EFDC의 개요 • EFDC 모델 소개 • 모델 구조 • EFDC 특징 • EFDC_DSI 향상 • EFDC_Explorer Ver7 개요 • 모델 설정 • 모델 보정 • 시각화 • 구성 하위 모델의 개요
The EFDC MODEL • The Environmental Fluid Dynamics Code (EFDC) is a general-purpose modeling package • Simulates 1,2&3-D flow, transport, and • biogeochemical processes in surface water systems(rivers, streams, lakes, estuaries, coastal waters and open ocean) • EFDC model was originally developed at the Virginia institute of Marine Science • EFDC is public domain model • EFDC_DSI is Dynamic Solutions-International's enhanced and optimized version EFDC 모델 • 환경 유체 역학 코드 (EFDC)은 범용 모델링 패키지 • 1,2 및 3-D 흐름, 수송, 및 시뮬레이션 • 지표수 시스템 (강, 하천, 호수, 하구, 연안 바다와 대양)의 생지화학 과정 • EFDC 모델은 원래 해양 과학의 버지니아 연구소에서 개발되었다. • EFDC는 퍼블릭 도메인 모델 • EFDC_DSI 동적 솔루션 - 국제의 향상된 최적화 된 버전이다.
EFDC STRUCTURE EFDC 구조 유체 역학 • 전송 • 물의 염색/나이 • 퇴적물 • 독성 물질 • 수질 • 라그랑지안 입자 • 추적 • 역학 • (E, U, V, W, 혼합) 온도 염분 • 필드 깃털 근처 • EFDC's hydrodynamics are based on the 3D hydrostatic equations formulated in curvilinear-orthogonal horizontal coordinates and a sigma or stretched vertical coordinate system. • EFDC is a coupled model eliminating model linkage issues • EFDC의 유체 역학은 곡선-직교 수평 좌표와 시그마 또는 수직 좌표 시스템에 뻗은 공식화된 3D 수압 방정식을 기반으로 한다. • EFDC은 모델에 결합 문제를 제거 결합 모델이다.
EFDC Features • Wettin & drying • Vegetation resistance • Boundary Conditions: - Flow(in and/or out) - open/pressure - hydraulic structures - withdrawal/Return - Wind speed/direction * Multiple Stations - Atmospheric Conditions(heat transport) * Multiple Stations EFDC 특징 • 웨틴 및 건조 • 식물 저항 - 경계 조건 : - 흐름 (내부 / 축소) - 열림 / 압력 - 유압 구조 - 취소 / 반품 - 바람의 속도 / 방향 * 여러 역 대기 조건 (열 수송) * 여러 역
EFDC Horizontal Grids EFDC 수평 그리드 • Cartesian(Rotated) • 데카르트 (회전) • Curvilinear Orthogonal • 직교 곡선
EFDC Vertical Grid EFDC 수직 그리드 • Z-grid • Z-그리드 • sigma stretch (EFDC) • 시그마 스트레치 (EFDC)
EFDC_DSI Enhancements • Dynamic Solutions-international (DSI) has developed an enhanced version the code (EFDC_DSI) which includes: • Lagrangian Particle Tracking • Dynamic Memory Allocation • Improved/Simplified External Wave Model Linkage • Internal Wind wave Generation • Improved Water Quality Model with Dynamic Time stepping • Rooted Plant and Epiphyte Model (RPEM) • Age of Water/Residence Times • Open MP - Multi-Threading • EFDC_DSI 향상 • 동적 솔루션 - 국제 (DSI)는 향상된 버전이 포함 된 코드 (EFDC_DSI)를 개발했다 : • 라그랑지안 입자 추적 • 동적 메모리 할당 • 개선 / 간체 외부 웨이브 모델 연계 • 내부 바람, 파도, 생성 • 동적 시간 스테핑 수질 개선 모델 • 뿌리 식물 및 착생 식물 모델 (RPEM) • 물 / 레지던스 시간의 시대 • MP를 연다 - 멀티 스레딩
The Graphical User Interface for EFDC EFDC_Explorer EFDC를위한 그래픽 사용자 인터페이스 EFDC_Explorer
What is EFDC_Explorer? • EFDC_Explorer (EE) is a pre-and post-processing tool developed by DSI for two versions of EFDC: • - EFDC_DSI (Primary model) • - EFDC_GVC/EFDC/EPA (Legancy applications) • EE7 significantly streamlined the modeling process: • - Model input preparation • - Use of 2D GIS type information to define and edit model inputs • - Context Sensitive Point & Click access to cell properties and BC assignments • EE7 provides a significantly enhanced yet simpler interface than previous versions of EE • EFDC_Explorer은 무엇입니까? • EFDC_Explorer (EE)는 EFDC의 두 가지 버전 DSI에서 개발 한 사전 및 사후 처리 도구입니다 : • - EFDC_DSI (기본 모델) • - EFDC_GVC / EFDC / EPA (Legancy응용 프로그램) • EE7 크게 간소화 모델링 과정 : • - 모델 입력 준비 • - 모델 입력을 정의하고 편집 할 2D GIS 형식 정보 사용 • - 상황에 맞는 포인트 및 셀 속성 및 BC 할당에 대한 액세스를 클릭 • EE7은 EE의 이전 버전보다 크게 향상되었고 간단한 인터페이스를 제공합니다
