Profiling Field Initialisation in Java Stephen Nelson, David J. Pearce & James Noble Victoria University of Wellington New Zealand

Motivation • “Favour Immutability”, #13, Effective Java: • "Classes should be immutable unless there's a very good reason to make them mutable....If a class cannot be made immutable, limit its mutability as much as possible.” • “Immutable classes are easier to design, implement, and use than mutable classes” -- Josh Bloch

Motivation • “Favour Immutability”, #13, Effective Java: • "Classes should be immutable unless there's a very good reason to make them mutable....If a class cannot be made immutable, limit its mutability as much as possible.” • “Immutable classes are easier to design, implement, and use than mutable classes” -- Josh Bloch Q) How well does Java support this?

Field Initialisation abstract class Parent {private final Child child;public Parent(Child c) { this.child = c; } } abstract class Child {private Parent parent; public void set(Parent p) { parent = p; } } • Java provides final fields to prohibit modification and show intent • Unfortunately, in this example, cannot declare parent field final

Stationary Fields • A field is stationary if, for all objects, every write occurs before first read • Unkel & Lam (POPL’08) statically inferred stationary fields • Across corpus of 26 Java Applications, found between 40-60% of fields were stationary W W R R W R W R

More on Stationary Fields • Final fields are subset of stationary fields: • Distinguish Declared Final and Undeclared Final W W R R CE W R R R CE W W R R CE

Rprof – Overview • Our Runtime Profiling Tool: • Whole-program, including standard libraries • No sampling, record and analyseevery event • Tracks constructor entry/exit and field read/write

Rprof – Map/Reduce • Problem: how to handle billions of events? • Answer: throw more hardware at it! • Event processing done using Map/Reduce • Events processed in parallel to give more manageable results • Worker threads spread over multiple machines • Consequence: less flexibility • Must customise map/reduce procedure for each distinct analysis

Rprof – Map/Reduce Example 1. W #1.f 2. W #2.g 3. W #1.f 4. R #2.g 5. W #2.g 6. R #1.f 1. W #1.f 2. W #2.g 3. W #1.f 4. R #2.g 5. W #2.g 6. R #1.f LW: 3 FR: 6 Reduce LW: 5 FR: 4 1. W #1.f 2. W #2.g 3. W #1.f 4. R #2.g 5. W #2.g 6. R #1.f Reduce

Experimental Setup • Methodology: • Profile single run of benchmark with default input • OpenJDK 1.8.0-ea-b37 was the experimental platform (*) • Opteron 254 (2.8GHz) dual CPU with 4GB was experimental machine • Dacapo Benchmark Suite • 14 Applications • 701 - 8246 classes • Non-trivial memory loads • Workloads provided • No User Interaction • Reproduceable Results

Results – Overall Key Observation: 70% -- 80% of fields are stationary

Results – Primitives vs References

Threats to Validity • Benchmark Inputs • Cannot generalise program behaviour from a single run! • Better to use a set of inputs – but how to generate them? • Benchmark Scope • Unclear whether DeCapo representative of general population • Conclusion: • Our results provide upper bound on number of stationary fields • Unkel & Lam provide lower bound on number of stationary fields

Conclusion • Unkel & Lam • Static inference of stationary fields • Found 40-60% of fields were stationary • Static analysis conservative -> lower bound • Our results • Complement that of Unkel & Lam • Use runtime profiling instead of static inference • Found 70-80% of fields are stationary • Runtime profiling is unsound -> upper bound
