  1. DIALOG Jubail Supply Base Jubail, Saudi Arabia

  2. Dialog Jubail Supply base - History Dialog secured a lease agreement with the Saudi Ports Authority / Jubail Commercial Port for the a leased land of 34,500 square meters for 20 years. An extensive case study, design and concept was made and submitted to the Port Authorities & RC for the construction of the Supply Base. Dialog invested SR130m to enhance the given piece of land by extending the berth by 24 mtrs (back filling) and created a 400 mtr berth length with current land space is 47,500 square meter with a -6 mtr water depth during low tide. Acutal Land securedOngoing Construction in Aug 2011

  3. Introduction • The Dialog Jubail Supply Base within the Jubail Commercial Port is strategically located in a close proximity to the major offshore oil and gas fields in the Arabian Gulf, as well as the nearby integrated petrochemical complex in Jubail Industrial City. • Dialog Services Saudi Arabia, Is a Saudi/Malaysian Joint Venture between Dialog Group Berhad, Malaysia & Sedres Maritime, Kingdom of Saudi Arabia. • Our Mission • The Dialog Jubail Supply Base is established and is ready to serve the oil and gas industry within the Arabian Gulf. • Our mission is to be recognized as a reputable integrated offshore supply baseof choice for our customers, employees and investors through innovative, high quality, value- added business solutions delivered with enthusiasm, integrity and professionalism with the utmost regard to the safety of individuals, cargoes and materials handled and the protection • of the environment. • Location and Facilities • The Jubail Base station is located in a very well weather protected area within the Custom Boundaries of the Jubail Commercial Port where it has leased 45440 sq m and a service quay accessible 24 / 7 for Off Shore Boats , Cargo Handling , Crew Changes and able to accommodate six (6) Off Shore Vessels concurrently. The locations and facilities are the main advantage to the offshore vessels to serve oil & gas offshore activities by offering faster turnaround and being closed to some of the offshore oil and gas field. • Facilities • 400 Meter long supply Quay in a water depth of 6 Meters • 22000 sq m of open storage area • 1680 sq m Warehouse • 960 m2 of Workshop complete with overhead crane • 4400 M3 Fresh Water Storage Tank • 10,000 M3 Fuel Diesel Tank • 5,000 M3 Drilling Base Oil Tank • Single Buoy Mooring SBM repair ramp • Refrigerated food containers electrical connection facilities • Mobile machineries

  4. Planned Future Facilities • Barite and Bentonite silos • Cement Silos • Mud Plant • Services • We offer the following range of services: • Dock and Vessels • Cargo handling • Embarkation / Disembarkation of offshore crews and personnel • Supply of labor and equipments. • Storage of goods • Bunker of Water and Fuel • Drilling Base Oil • Vessel repairs and maintenance • Supplies • Rental of cargo container unit • Think of DIALOG JUBAIL OFFSHORE SUPPLY BASE when you plan to deliver your offshore exploration and drilling materials at the most effective and efficient way.

  5. LOCATION Proposed Phase 1

  6. PHASE 1

  7. WORKSHOP 3 X 5000 M3 - LIQUID BULK CARGO TANKS 2 X 2200 M3 WATER TANKS 35 M X 48 M X 9M WAREHOUSE 400 MTR BERTH LENGTH SBM – MAINTENANCE FACILITY

  8. Dialog Jubail Supply Base

  9. Dialog Jubail Supply Base (taken Jan 2012)

  10. Tug Boats & Barges at our Jubail Supply Base

  11. Team members at Dialog Jubail Supply Base

  12. CONCEPT OF JUBAIL SUPPLY BASE • A one-stop, fully integrated offshore logistic support centre for the oil & gas industry (multi user concept.) • A central staging point for deployment of offshore supply vessels to support offshore Arabian Gulf E & P operations.

  13. Jubail Port DHAHRAN

  14. Close proximity to several major offshore oilfields Potential Cost saving in terms of fast turn around. Logistic Benefits to our Clients Distances in NM

  15. Logistics Benefit to Clients • Based within an active and secure port with customs and immigration facilities • Supported by hinterland of Jubail Industrial City

  16. Dialog Jubail Supply Base Co. Ltd Contact:

  17. DDIALOG JUBAIL SUPPLY BASE We welcome everyone to visit us at Jubail !! THANK YOU …….
