Presentation Transcript
web based enterprise telephony application development

Web-based Enterprise Telephony Application Development

Johnny Wong

Principal Member of Technical Staff

Oracle Corporation

enterprise applications
Enterprise Applications
  • Enterprise Telephony Apps
    • Phone-accessed applications
    • Access enterprise back-ends
    • Have call control capabilities (make a call, auto-answer)
  • Sample Apps
    • Call Centers / Customer Support
    • IVRs: Corporate Directory
    • Unified Messaging
    • Conferencing
    • Next-Gen Telephony Apps
      • Click to Dial
      • Notification Services
      • Personal Assistant
  • Demo: Click-To-Dial

Johnny Wong – Oracle Corporation

development tools
Development Tools
  • Elements of Development & Standard Technologies
    • Voice:
      • VXML, SALT, X+V, X+X
    • Call Control:
      • JTAPI, TAPI, JAIN SLEE, SIP, Parlay, Parlay X
    • Media Resources:
      • Media Servers
    • Visual Integration:
      • Web UI, Windows UI

Johnny Wong – Oracle Corporation

potential issues
Potential Issues
  • Voice: VXML
    • Good approach (standards-based) but,
    • Various interpretations of spec / No total support

 Interoperability Hassle & potential Vendor Lock-in

  • Call Control:
    • JTAPI, TAPI, SLEE, SIP, Parlay, Parlay X
    • CTI integration – Standalone Server
    • Infrastructure Assumptions
      • Underlying network: SIP network
      • Extra Framework: Parlay Gateways

Johnny Wong – Oracle Corporation

new architecture
New Architecture
  • Web-based Open-Standards Approach
  • X+X (XHTML / Xforms): Audio UI
    • Handle VXML translation
  • Web Service-based Call Control APIs
    • Handle 3pcc, routing and management
    • Agnostic to underlying protocol
  • Media Server
    • Mixing of Audio
    • VXML resources: TTS / ASR
  • Visual UI
    • Web UI (integration with other modalities)

Applications

(Call Center, Vmail,

PBX apps, iMeeting,

IVR, Voice Apps)

(X+X / JSP / WS)

Telephony

Resources

(PBX, PSTN,

VoIP phones)

VXML

browser

Telephony

MCS

App Server

Telephony

Backend

Media

Server

Drivers

Drivers

Other Resources

Ie. Email Store

Johnny Wong – Oracle Corporation

a case study
A Case Study
  • Oracle’s Application Server & Conferencing System
  • App Server with Telephony Support
    • XHTML / Xforms, Web Services, Database
    • First version: SIP support
  • Conferencing Application
    • 40K employees across the world
    • Reuse company’s IT infrastructure:
      • SIP gateways, PBX systems, VXML platforms, IP Phones
    • Solution Implemented within 3 months with 2 engineers
      • Brazilian Pilot set to start in January

Johnny Wong – Oracle Corporation

conferencing app flow

XHTML

WS

VXML

Conferencing App Flow
  • Conference Bridge – Event Flow

Conference

App

(JSPs)

PSTN

Gateway

Telephony

Driver

10g

Platform

PSTN

phone

VXML

browser

Media

Server

Telephony Signalling

Voice Stream

Application Communication

  • Demo: App Initiated Conference

Johnny Wong – Oracle Corporation

value proposal of architecture enterprise view

Agent Client

Software

Call

Routing

Middleware

Abstractor

Interaction

Center

Apps

Intel’s CT Connect

CISCO ICM

Genesys

Aspect

IVRs

(Avaya, etc)

PBX

PBX

phones

Voicemail &

Fax App

(Java classes /

C functions)

CT Media

Server

Email Store

S.100 (C code)

JTAPI (Java)

SIP

-

PBX

GW

SIP

Proxy

Server

Dialogic

Cards

iMeeting

Conference

Recording

SIP

phones

Oracle 9iASW

Voice & Wireless

Applications

VXML browser

Value Proposal of ArchitectureEnterprise View

Go From All This:

To This:

Applications

(Call Center, iMeeting,

Vmail, PBX apps,

IVR, Voice Apps)

(X+X / JSP / WS)

PSTN

Telephony

MCS

SIP

Gateway

-

SIP

Proxy

Oracle10g AS

SIP

Server

Backend

VXML

browser

PBX

Drivers

Drivers

Other Resources

Ie. Email Store

SIP

phones

high level benefits
High-Level Benefits
  • Ease of Development
    • Existing technologies
      • XHTML, JSPs, Web Services, Web Model
    • Large Development Community
  • Interoperability & Open Standards
    • VXML gateways and underlying networks
    • Applications use same infrastructure
  • Reusability (Cost Savings)
    • Reuse same hardware / software platforms for development and deployment

Johnny Wong – Oracle Corporation

conclusions
Conclusions
  • Telephony Development
    • Integrated with Web Development
    • Promotes Data & Channel Convergence
  • Knowledge Reuse, Open-Standards, Interoperability, Infrastructure Reuse
    • XHTML/Xforms or VXML
    • Web Services

Johnny Wong – Oracle Corporation

thanks questions

Thanks! Questions?

Johnny Wong

Johnny.x.wong@oracle.com

Principal Member of Technical Staff

Wireless, Voice & Telephony

Oracle Corporation
