hemilabile coordination complexes as fluorescent chemosensors the groundwork rupome

Hemilabile Coordination Complexes as Fluorescent ChemosensorsThe Groundwork: RuPOMe

Anthony Tomcykoski

overview
Overview

Introduction

Synthetic Approach

Characterization

Conclusions

Future Work

introduction
Introduction
  • Hemilabile Coordination
    • Polydentate chelates
      • Inert and labile binding positions
    • Phosphine-ether ligands

Hemilabile coordination complex in the presence of a small polar molecule

(1)

introduction1
Introduction
  • Examples of Hemilabile Ligands

Tris(2,6-methoxyphenyl)phosphine

P(OMe)6

Bis(2-methoxyphenyl)phenylphosphine

P(OMe)2

POMe

Diphenyl(2-methoxyphenyl)phosphine

introduction2
Introduction
  • Photosensitizer
    • [Ru(bpy)3]+2
    • Long lived 3MLCT
  • Fluorescent Chemosensor
    • Molecular sensing
    • Monitor photophysical properties
synthetic approach
Synthetic Approach

Step One:

Make a suitable starting material

.2 H2O

Starting Material

Ru(bpy)2Cl2.2H2O

synthetic approach1
Synthetic Approach

Step Two:

Remove inner sphere chloride

Introduce non- coordinating anion (BF4-)

2

Solvated bis(bipyridyl) complex

synthetic approach2
Synthetic Approach

Step Three:

Coordinate phosphine-ether hemilabile ligand

Isolate product

RuPOMe

hemilabile coordination complexes
Hemilabile Coordination Complexes

Tolylterpyridylchromophores

Tridentate Ligands

RuPOMe

RuP(OMe)6

Bipyridyl Chromophores

Bidentate Ligands

RuP(OMe)2

Ru(bpy)2P(OMe)6

characterization
Characterization

UV/Vis Spectroscopy

Infrared Spectroscopy

Emission Spectra

Excited State Lifetime

NMR (1H, 13C, 31P)

uv vis spectroscopy bipyridyl systems
UV/Vis SpectroscopyBipyridyl Systems

MLCT energy gap varies in each complex

[Ru(bpy)3](PF6)2 450nm

RuCl3.nH2O 420nm

Ru(bpy)2Cl2 376, 548nm

[RuPOMe](PF6)2 450nm

[Ru(bpy)2P(OMe)6](PF6)2 430nm

in EtOH/Acet 476nm

[Ru(bpy)3](PF6)2

RuCl3.nH2O

Ru(bpy)2Cl2.2H2O

jablonski diagram mlct ru bpy 3 2
Jablonski Diagram MLCT[Ru(bpy)3]+2

Short, sub-picosecond ISC

1MLCT

Long, ~5μs

S1

3MLCT

T1

E

Radiative Decay

Nonradiative Decay

  • Interested in Monitoring
    • 3MLCT Lifetime
    • Radiative Decay or Emission

S0

uv vis spectroscopy tolylterpyridyl systems
UV/Vis SpectroscopyTolylterpyridyl Systems

MLCT Bands

Ru(ttpy)Cl3

440nm

[Ru(ttpy)2]Cl2

486nm

[RuP(OMe)6](BF4)2

460nm

emission spectra room temperature
Emission SpectraRoom Temperature

[RuPOMe](PF6)2

emission

601nm

excitation

463nm

[Ru(bpy)2P(OMe)6](PF6)2

emission

505nm

excitation

430nm

RuP(OMe)6](BF4)2

emission

413nm

excitation

343nm

excited state lifetime
Excited State Lifetime

[Ru(bpy)3]+2

 = 5µs (77K, literature)

 = 132.4ns (Room Temperature, CH3CN, experimental)

emission

610nm

RuPOMe

 = 319ns

emission

601nm

  • Conclusion:
    • Room temperature lifetimes are inconsistent
    • The lifetime of tolylterpyridine ruthenium complexes are on the order of picoseconds
nmr studies
NMR Studies
  • 1H NMR
    • Methoxy proton shifts
    • Observe bound and unbound ligand signal
  • 13C NMR
    • Signal:Noise low, numerous peaks
  • 31P NMR
    • High number of scans (6400 scans)
    • Unique 31P resonances with analyte complexation
    • Long T1 Relaxation (PPh3=13.369s, POMe=18.396s)
1 h nmr
1H NMR

2,2’-bipyridine

free ligand

Aromatics > 7ppm

POMe

free ligand

-OCH3 3.70ppm

[RuPOMe](PF6)2

-OCH3 2.05ppm

31 p nmr
31P NMR

[RuPOMe](PF6)2

[2.85 x 10-3M] in Acetone-d6

56ppm Ether Bound

-143ppm(septet) PF6-

POMe free ligand

-14.45ppm

[RuP(OMe)6](BF4)2

[3.0 x 10-3M] in Acetone-d6

15.5ppm Ether bound

-63.5ppm(d) undesired product

-68.5ppm(d) undesired product

P(OMe)6 free ligand

-70.8ppm

conclusions
Conclusions
  • [RuPOMe](PF6)2 successfully synthesized and characterized
  • [RuP(OMe)2] and [RuP(OMe)6] require different synthetic approach
  • Tolylterpyridine is not ideal as a chromophoric ligand
  • MLCT electronic state observed for bipyridyl and tolylterpyridylchromophores
  • Complexes are luminescent, but minimal at room temperature
future work
Future Work
  • Concentration Dependence
  • Analyte selectivity titrations
  • Low Temperature (77K) Photophysics
  • 31P NMR in Determining Equilibrium
  • Quantum Yield Measurements
  • Use Fluorescent Polymer Units as Hemilabile Ligands
acknowledgements
Acknowledgements
  • Jones’ Group
    • Dr. Jones, Dr. Martin, Dr. Flynn
    • Jasper, Wenrong, Catherine, Sherryllene, Dickson, Peter
    • Undergraduates
  • Dr. Jürgen Schulte
  • Chemistry Department
  • Binghamton University
references
References
  • Rogers, C.W.; Zhang, Y.; Patrick, B.O.; Jones, W.E.; Wolf, M.O. Inorg. Chem. 2002, 41, 1162-1169
  • Kalyanasundaram, K. Photochemistry of Polypyridine and Porphyrin Complexes; Academic Press: London, 1992.
  • Angell, S.E.; Zhang, Y.; Rogers, C.W.; Wolf, M.O.; Jones, W.E.; Inorg. Chem. 2005, 44, 7377-7384
  • Alary, F.; Heully, J.L.; Bijeire, L.; Vicendo, P. Inorg. Chem. 2007, 46, 3154-3165.
  • Wang, J.; Fang, Y.Q.; Hanan, G.S.; Loiseau, F.; Campagna, S. Inorg Chem. 2005, 44, 5-7.
  • Rogers, C.W.; Wolf, M.O. Chem. Comm. 1999, 2297-2298.
  • Angell, S.E., Rogers, C.W.; Zhang, Y.; Wolf, M.O.; Jones, W.E.; Coordination Chemistry Reviews. 2006, 250, 1829-1841.
  • Demas, J.N.; Adamson, A.W. J. Am. Chem. Soc.1971, 93, 1800-1801
