Presentation Transcript
microscope
Microscope

One or more lense that makes an enlarged image of an object.

slide3

Types of Microscopes

  • Simple
  • Compound
  • Stereoscopic
  • Electron
simple microscope
Simple Microscope
  • Similar to a magnifying glass and has only one lense.
compound microscope
Compound Microscope
  • Lets light pass through an object and then through two or more lenses.
stereoscopic microscope
Stereoscopic Microscope
  • Gives a three dimensional view of an object. (Examples: insects and leaves)
electron microscope
Electron Microscope
  • Uses a magnetic field to bend beams of electrons; instead of using lenses to bend beams of light.
a lense
A Lense
  • Enlarges an image and bends the light toward your eye.
eyepiece lense
Eyepiece Lense

Usually has a power of 10 x

slide10
Eyepiece Lense

X

Objective Lense

=

Total Magnification

slide11

Objective Lenses

Low Power = 4 x

Medium Power = 10 x

High Power = 40 x
