Presentation Transcript
challenges in evaluating heat rate performance of new technologies in real world applications

Challenges in Evaluating Heat Rate Performance of New Technologies in Real World Applications

Brad Woods – McHale & Associates

Mary Glass – Mexel USA

Dennis Pednault – McHale & Associates

EPRI Heat Rate Improvement Conference

February 5-7, 2013Scottsdale, Arizona

slide2

Discussion

  • Background
  • Project Approach
  • Project Results
  • Lessons Learned
slide3

Nuclear Power Plant Case Study

  • 1675 MW PWR – 2 units
  • 2.4 million GPM Circ Water
  • 75,000 l/s CW/Condenser
  • 396,000 GPM/Condenser
  • 6 condensers with continuous mechanical ball-cleaning systems
  • Treated one condenser on Unit 2 with Mexel.
slide7

Project Background

  • Objectives
    • Measure fouling rates
    • Compare efficacy of Mexel against non-treated
  • Instrumentation (Temporary vs. Station)
    • Accuracy vs Repeatability (Uncertainty)
    • Timing
  • ASME PTC 12.2 Steam Surface Condensers
slide8

Project Approach

  • Plant Goals
    • Down power events
    • Macro-fouling
    • Micro-fouling
  • Protocol/Planning
  • Work Packages
  • Installation
  • Monitoring
  • Results
slide10

Test Approach

  • Fouling Resistance
slide11

Test Approach

  • .Differential Pressure
slide12

Test Approach

  • Corrected LMTD
    • Temperature
    • Velocity
    • Load
slide13

Instrumentation

  • Permanent Plant
  • Temporary Test
slide14

Project Experience

  • Humidity
  • Data Loss
    • Water
    • Drivers
  • Hydroids
  • Trends
  • Fouling Events
    • Hydroids
    • Grass
    • Horseshoe crabs
    • Blue crabs
slide15

Issues

  • Test Interruptions
slide16

Issues

  • Crabs
slide17

Issues

  • Grass
slide18

Issues

  • Data Acquisition
slide19

Test Results

  • LMTD
  • TTD
  • Heat Transfer Coefficient
  • Fouling
  • Expected Power Benefit
  • Paired t-Test
slide29

Results

  • Plant Observed Results
    • Plant personnel reported no discernible improvement
    • Overall plant output
  • Conclusions
    • Small proportion of plant treated
    • Condenser Interconnection affected pressure
    • Statistical tests
slide30

Assessment

  • Paired t-test
slide31

Lessons Learned

  • Instrumentation
  • Data Acquisition
  • Data
    • Nuclear limitations
    • Performance monitoring
    • Correlations
  • Methods
  • Quick /relative to demonstrate expectations.
  • Small difference but statistically significant
  • Verification
slide32

Expectations

  • Assume 300 MW
  • Assume summer peak Energy = $80/MW
  • Assume 4 month period = 2,920 hours
  • Expected Power difference = 2.2% (6.6 MW)
  • Summer Savings = $0.77 million
contact information
Contact Information

McHale & Associates, Inc.

www.mchale.org

18378 Redmond Way, Redmond, WA 98052

(425) 883-2058

Mexel USA

http://www.mexelusa.com/

1655 N. Fort Myer Drive, #350

Arlington, VA 22209

(703) 349-3347
