1. National Communications System (NCS)ESF #2 Training ConferenceSPECTRUM MANAGEMENT
2. Overview Terminology
National Spectrum Management
FCC and NTIA Coordination
IRAC Frequency Assignment Process
ESF #2 Frequency Assignment Process
Summary
Useful Websites Introduce the overview items
Objective of this presentation: The student should be able to generally describe :
-- The U.S. national spectrum management agencies
-- The normal frequency assignment process
-- The alternative frequency assignment process
Introduce the overview items
Objective of this presentation: The student should be able to generally describe :
-- The U.S. national spectrum management agencies
-- The normal frequency assignment process
-- The alternative frequency assignment process
3. Terminology Spectrum Management
Frequency Band
Frequency Assignment
Temporary Frequency Assignment Definitions to set standards and clear up differences between the FCC terminology and the NTIA terminology for similar itemsDefinitions to set standards and clear up differences between the FCC terminology and the NTIA terminology for similar items
4. Terminology Spectrum Management
Scientific evaluation, engineering processes, and administrative procedures which permit a variety of telecommunications operations to operate effectively, and share the radio spectrum without interference What we are supposed to be doing.
Emphasis placed on the sharing aspect and insuring there is no interference.
If we don’t know you are there, we can’t protect youWhat we are supposed to be doing.
Emphasis placed on the sharing aspect and insuring there is no interference.
If we don’t know you are there, we can’t protect you
5. Terminology This list is a sample of band allocation. The land mobile bands during an emergency response have the potential for the greatest level of congestion depending on the type of emergency being supported.
--Federal bands are managed by NTIA
--Non-Federal bands are managed by FCC
--Many of the bands that are primarily NTIA or FCC may have users from the other entity. These assignments / licenses are coordinated between the two agenciesThis list is a sample of band allocation. The land mobile bands during an emergency response have the potential for the greatest level of congestion depending on the type of emergency being supported.
--Federal bands are managed by NTIA
--Non-Federal bands are managed by FCC
--Many of the bands that are primarily NTIA or FCC may have users from the other entity. These assignments / licenses are coordinated between the two agencies
6. Terminology
Frequency Assignment
The authorization issued by NTIA for a government radio station or by the FCC for a non-federal radio station operate a radio transmitter on a discrete frequency or a frequency band at a particular location(s) under specified conditions
Issued on a Primary, Secondary, or Non-interference Basis
Varied expiration dates A frequency assignment in FCC terminology would be a license to operate.
Assignments are
--Regular: Unspecified time period, but subject to periodic review of either 5 or 10 years
--Temporary: For a specific period of time based on expiration date
--Trial: Renewable 2 year assignment used to find a suitable frequency but must not cause interference
--Group: Provides an assignment for planning purposes for either non-continuous operation authority or for protected planning not to exceed 3 yearsA frequency assignment in FCC terminology would be a license to operate.
Assignments are
--Regular: Unspecified time period, but subject to periodic review of either 5 or 10 years
--Temporary: For a specific period of time based on expiration date
--Trial: Renewable 2 year assignment used to find a suitable frequency but must not cause interference
--Group: Provides an assignment for planning purposes for either non-continuous operation authority or for protected planning not to exceed 3 years
7. Terminology
Temporary Assignments (NTIA)
For a specific period of time based on expiration date
Trial: Renewable 2 year assignment used to find a suitable frequency but must not cause interference
Special Temporary Authority (STAs) (FCC)
Case-by-case, extraordinary circumstances
Limited time duration (less than six months)
8. National Spectrum Management
9. National Spectrum Management The FCC is an independent United States government agency, directly responsible to Congress
Established by the Communications Act of 1934
Charged with regulating interstate and international communications by radio, television, wire, satellite and cable
Jurisdiction covers the 50 states, the District of Columbia, and U.S. possessions
Chairman and four Commissioners
Title III of the Act – Special Provisions Relating to Radio
Section 301 - “…No person shall use or operate any apparatus for the transmission of energy or communications or signals by radio…except under and in accordance with this Act and with a license in that behalf granted under the provision of this Act.”
Section 303 - General Powers of the Commission
FCC Rules contained in Title 47
of the Code of Federal Regulations (47 CFR)
10. National Spectrum Management NTIA Performs spectrum management and assignment for all Federal spectrum use
Section 305 of the Act – Government Owned Stations
“Radio Stations belonging to and operated by the United States shall not be subject to the provision of sections 301 and 303 of this Act. All such Government stations shall use such frequencies as shall be assigned to each or to each class by the President.”
Established by Reorg. Plan No.1 (1977), EO 12046, March 1978
Part of Department of Commerce (DoC) in the Executive branch
Headed by the Assistant Secretary reporting to the President and the Secretary of the DoC
Regulations published in Manual of
Regulations and Procedures for
Federal Radio Frequency Management
(NTIA Manual)
11. National Spectrum Management
12. National Spectrum Management Frequency allocations determine the type of use allowed in the block or band of frequencies
Table Entry or Footnote Allocation
Services: terrestrial and satellite, Fixed, Mobile, Broadcast, etc.
Status: Primary, Secondary, Non-Interference Basis
International allocations
Adopted at World Radio Conferences, Three Regions
Bilateral and Multilateral Agreements
Domestic allocations
Federal exclusive, Non-federal exclusive, Shared Allocations
Large amount of spectrum is shared between federal and non-federal users
13. National Spectrum Management
14. National Spectrum Management Agencies conduct four major functions in regulating radio services
Allocate Spectrum to various radio services
Develop Service Rules to provide administrative procedures, technical standards, and other operational requirements for shared intra- and inter-service use of the spectrum
Assign Frequencies to individual systems or authorize specific equipment use, assignments coordinated domestically and internationally
Enforce Rules and ensure compliance of radio equipment
15. FCC and NTIA Coordination 1940 agreement between FCC and NTIA (last updated January 2003)
Parties shall give notice of all proposed actions that could effect one another with sufficient time for the other agency to comment prior to final action
FCC and NTIA will maintain up-to-date lists of their respective authorized transmitting frequency assignments
FCC, NTIA and other Federal agencies coordinate spectrum matters through the Interdepartment Radio Advisory Committee (IRAC)
The IRAC advises and assists NTIA in assigning frequencies to federal government stations and in developing and executing policies, programs, procedures, and technical criteria for allocation, management, and use of spectrum
16. FCC and NTIA Coordination
Main Committee
NTIA Chairs the IRAC and holds Executive Secretary position
Members appointed from federal agencies with spectrum interests
Defense Departments: Army, Navy, Air Force
Commerce, Justice, Homeland Security, Treasury and State Departments
NASA, NSF, FAA, Transportation, Energy, BBG, Postal
FCC Liaison
Six Subcommittees
Frequency Assignment Subcommittee
Emergency Planning Subcommittee
SPS, SSS, RCS, TSC
Ad Hoc working groups (as needed)
AH 214 (Public Safety Communications)
Few others
17. IRAC Frequency Assignment Process Frequency Assignment Subcommittee (FAS) of the Inter-department Radio Advisory Committee (IRAC)
The IRAC/FAS consists of 20+ Federal Agencies (including the FCC)
Departments/Agencies submit proposals through designated chain to NTIA/FAB for coordination and authorization of frequencies in federal, non-federal and shared frequency bands
FAB processes all coordination requests submitted for approval by D/As, validates technical and administrative information
D/As review proposals in the IRAC/FAS to ensure incumbent systems are protected from harmful interference
After IRAC/FAS review, FAB authorizes D/A frequency assignments, approved assignments are entered into the Government Master File
GMF is not accessible to the public
18. IRAC Frequency Assignment Process FCC is an IRAC/FAS member
Non-federal applicants file electronically with FCC using Universal Licensing System, International Bureau Filing System, and Experimental Licensing System
FCC/OET submits proposals to NTIA/FAB for coordination of frequencies in federal and shared frequency bands
OET reviews D/A coordination requests in the IRAC/FAS to ensure incumbent non-federal systems are protected from harmful interference
IRAC/FAS records sent back by OET for FCC Bureau/Office for action
FCC Bureaus/Offices grants or dismisses non-Federal applications using ULS, IBFS or ELS
ULS, IBFS and ELS are accessible to the public
19. IRAC Frequency Assignment Process Special Temporary Authority (STAs)
Case-by-case, extraordinary circumstances, limited time duration Equipment Authorizations
Waivers
Case-by-case, rules may not yet be established, risk of interference is low
20. ESF #2 Frequency Assignment Process Planning Assumptions
In situations of NS/EP, all normal spectrum management functions will continue to operate as usual
In the case of a national emergency and the activation of ESF #2, the FCC and the NTIA will continue normal processing of all frequency assignment requests for the declared emergency
The U.S. Northern Command (USNORTHCOM) deploys, as appropriate, spectrum managers to the JTF/TF Joint Spectrum Management Element (JSME) to serve as the single USNORTHCOM point of contact (POC) for JTF/TF spectrum requirements As much as possible the intent is for the spectrum management process to continue as normal regardless of the situation at hand. This may be done from several different locations as necessary in order to adapt to the situation.
NORTHCOM becomes involved should a Joint Task Force be established in order to coordinate the DoD response to a situation. As part of the effort to maintain routine operations, the NORTHCOM JTF spectrum manager would use the standard DoD coordination channels.
The JTF spectrum and ESF spectrum teams will coordinate their efforts in order to limit the potential of unwanted interference.As much as possible the intent is for the spectrum management process to continue as normal regardless of the situation at hand. This may be done from several different locations as necessary in order to adapt to the situation.
NORTHCOM becomes involved should a Joint Task Force be established in order to coordinate the DoD response to a situation. As part of the effort to maintain routine operations, the NORTHCOM JTF spectrum manager would use the standard DoD coordination channels.
The JTF spectrum and ESF spectrum teams will coordinate their efforts in order to limit the potential of unwanted interference.
21. ESF #2 Frequency Assignment Process Spectrum dependant systems that will be brought into the area will be coordinated prior to arrival or activation.
This includes:
Area assignments that their agency intends to use in the affected emergency area. (Federal users)
Existing systems operating in the emergency area that require additional frequency authorizations or changes to current authorization
Collectively we need to realize that with many responding packages there are internal communications systems that come along. If there is a search and rescue team, there will probably be associated communications. If there is a convoy moving in or any other relief effort there will more than likely be some form of communications associated.
Responders need to be asked the right questions in order to ensure they can accomplish the task that they have come in to execute.Collectively we need to realize that with many responding packages there are internal communications systems that come along. If there is a search and rescue team, there will probably be associated communications. If there is a convoy moving in or any other relief effort there will more than likely be some form of communications associated.
Responders need to be asked the right questions in order to ensure they can accomplish the task that they have come in to execute.
22. ESF #2 Frequency Assignment Process
Support the Federal Emergency Communications Coordinator (FECC)
Deconflict/Coordinate prior to deployment
Identify sources of frequency interference, mitigate the interference, and resolve interference problems
At the deployed location, serve as a liaison when requests or questions arise, and direct the requirement to the appropriate decision-maker(s) or individual(s) in accordance with established spectrum management rules, regulations and policies
The best way to avoid having issues within the operational area is to clear all frequencies for use if they were not already in-use prior to the incident. Statewide assignments should still be noted if they are being pulled into a specific point. Nationwide assignments need to be reported also.
If there is an issue of interference, the Spectrum Management Team will work to resolve the issue.The best way to avoid having issues within the operational area is to clear all frequencies for use if they were not already in-use prior to the incident. Statewide assignments should still be noted if they are being pulled into a specific point. Nationwide assignments need to be reported also.
If there is an issue of interference, the Spectrum Management Team will work to resolve the issue.
23. ESF #2 Frequency Assignment Process Communications equipment and spectrum Authorization:
External to the JFO, representatives request through the ESF Spectrum Management Team if unable to access their normal agency process
Internal JFO, representatives request through the DHS Wireless Management Office on-site representative
Responsibilities:
Normally any internal JFO communications will be handled by the DHS WMO personnel on site. If there is coordination or support required the spectrum management team will accomplish this task as necessary.
All other communications will initially be handled through the specific agencies chain with the ESF Spectrum team available if the D/A is unable to reach back to its normal channels.
Ideally most of these issues would be taken care of prior to entry into the area.Responsibilities:
Normally any internal JFO communications will be handled by the DHS WMO personnel on site. If there is coordination or support required the spectrum management team will accomplish this task as necessary.
All other communications will initially be handled through the specific agencies chain with the ESF Spectrum team available if the D/A is unable to reach back to its normal channels.
Ideally most of these issues would be taken care of prior to entry into the area.
24. ESF #2 Frequency Assignment Process Coordinate with state and local government, private sector entities concerning frequency requirements prior to deployment or operation
Assist in processing Special Temporary Authorizations (STAs) and waiver requests utilizing normal processing procedures or expedited procedures established for the incident
Serve as an FCC liaison for deployed field elements and assist in coordinating with the FCC Headquarters as appropriate the processing of all spectrum licensing requests for use in the emergency area of operations
25. ESF #2 Frequency Assignment Process Notify Federal department and agency spectrum managers concerning their responsibility to identify their agency’s spectrum requirements prior to deployment or operation in the emergency area
Notify Federal department and agency spectrum managers concerning their responsibility to identify the operational status of spectrum-dependent systems in the affected emergency area
Provide normal spectrum management services for Federal government agencies including DHS and DoD In order to make best use of the available spectrum in an area it is important to have a good baseline of operations in the area. As part of our operating procedures we would need to know of any incumbent systems that are off-line due to the current incident. After proper coordination this would allow the reuse of frequencies until such time as the incumbent system is ready to resume operations
Any changes to systems should be reported through your D/A in order to maintain a current operational picture.In order to make best use of the available spectrum in an area it is important to have a good baseline of operations in the area. As part of our operating procedures we would need to know of any incumbent systems that are off-line due to the current incident. After proper coordination this would allow the reuse of frequencies until such time as the incumbent system is ready to resume operations
Any changes to systems should be reported through your D/A in order to maintain a current operational picture.
26. ESF #2 Frequency Assignment Process Generally speaking the flow of spectrum support / frequency request will follow what is laid out in this diagram.
All roads lead to the national level for clearance.
The take-away from this is that the ESF team works together and coordinates at multiple levels. Resolution is sought with focus on mission accomplishment for the end user.Generally speaking the flow of spectrum support / frequency request will follow what is laid out in this diagram.
All roads lead to the national level for clearance.
The take-away from this is that the ESF team works together and coordinates at multiple levels. Resolution is sought with focus on mission accomplishment for the end user.
27. Summary Summary Items
Objective of this presentation: The student should be able to generally describe :
-- The U.S. national spectrum management agencies
-- The normal frequency assignment process
-- The alternative frequency assignment process
Summary Items
Objective of this presentation: The student should be able to generally describe :
-- The U.S. national spectrum management agencies
-- The normal frequency assignment process
-- The alternative frequency assignment process
