  1. Rudolf Diesel: The End of the Beginning

  2. Paris-tiden • Började med ångmotorer. Ökadtemperaturgradiengenomöverhettadammoniakånga(Carnotprincipen) • Genommisslyckandeinriktadpåkompressionsförbränning

  3. Förstapatentet • Fem möjligaförbränningscykler(konstanttryck, volymochtemperatur) • Valdedetsistnämda: • Komprimera till 200-300 bar • Insprutninggradvisefter TDC förattåstadkommakonstanttemperatur

  4. Förstaprototypen • Tillsammans med v. Buz(Maschinenfabrik Augsburg) • Övergivitkonstanttemperatur, nu konstanttryck. • Problem med lågttryck(18 iställetför 44 bar), kompression(ingakolvringar). • Insprutningenbyggdepåatttrycket I cylindernvarlägreänmaxtryck. • Gickaldrigföregenmaskin, visade dock attkompressionräckteförantändning

  5. Andraprototypen • Nytt: Separata avgas ochinsugsventiler, bättresmörjningochkylning, separatkompressorförinsprutning. • Gickien minut, 88rpm 13.2hp • Insprutningsproblem, testadegasbränslen. • Försök med elektrisktändning

  6. Tredjeprototypen • Nytt: Separatventilstyrning, flexifuel, bränslespridare. • Tändstiftetslutadefungera, visade sig varaonödigt. Gickpåbåde gas ochfotogen • Separatkompressorförinsprutningen, senareintegrerad. • Spridarnasatteigentrots fleramodifikationer • Dåliggasväxlingpgalitenventil

  7. Fjärdeprototypen • Nybyggdfrångrunden. • Bättreinsprutningpgahögretryckdifferens. “Soft” combustion
