uclinux vs linux context switching and ipc performance comparison

uClinux vs Linux Context Switching and IPC Performance Comparison

2004.09.10

Heechul Yun

Digital Media R&D Center

contents
Contents
  • Introduction
  • ARM9 Cache Architecture
  • Benchmark
  • IPC Performance
  • Context Switching Performance
  • Conclusion
  • Future Works
introduction
Introduction
  • Objective
    • Fair performance comparison of uClinux and Linux
    • Focused on Context Switching and IPC
  • Context switch
    • Restore register and address space of next process
  • IPC (Inter Process Communication)
    • Send & recv messages between processes
uclinux vs linux
uClinux vs Linux
  • Linux
    • Separate virtual address space for each process
    • Need to recover address space on context switching
  • uClinux
    • Single shared address space for all process
    • No need to recover address space on context switching

uClinux may be better on context switching

arm9 mmu architecture
Virtually-indexed caches:

Flush cache on context switch

Direct cost : 1k~18k cycles

Indirect cost : up to 54k cycles

 Up to 270us on 200MHz

VA

PA

TLB

Perm

Memory

CPU

I-Cache

D-Cache

Data

ARM9 MMU Architecture

Observation:

  • Can avoid cache flush if no address overlap
arm926ej s virtual cache architecture
ARM926EJ-S Virtual Cache Architecture

0

32

12

11

5

4

2

1

  • Fully virtual address based index & tag
  • Separate 4way set-associative 16K I&D Cache.
  • 8word for each cache line

Tag

Index

Word

Byte

1

2

3

4

. TAG

.

1

2

3

4

2

5

6

7

8

.

.

.

.

128

=

=

Hit

Read data

benchmark

Master

Child1

Child2

read

read

read

write

write

write

FIFO 0

FIFO 1

FIFO 2

Benchmark
  • Lmbench2 [Lmbench]
    • Famous OS benchmark
    • Modified for uClinux (vfork, FIFO)
    • lat_ctx, lat_fifo, bw_pipe is used..

‘lat_ctx’ FIFO architecture

benchmark setup
Benchmark Setup
  • Same H/W, Same Benchmark program are used
  • The only difference is kernel (uClinux, Linux)

LMBench2

lat_fifo, lat_ctx, bw_pipe used

App

Linux-2.6.7

uClinux 2.6.7

Kernel

H/W: SMDK24A0

- ARM926ejs based S3C24A0

- 16K I&D Cache

H/W

context switching performance
Context Switching Performance
  • 0KB workload
    • Each proc immediately switch to next
    • pure ctx overheadcomparison
conclusion
Conclusion
  • The first fair performance comparison between uClinux and Linux
    • Same H/W platform
    • Same benchmark S/W
  • uClinux has better IPC & Context switching performance
    • Because cache is valid on context switching
    • Beneficial for
      • Real-time critical application
      • IPC oriented application
future work
Future Work (?)
  • Extending benchmarks
    • Interrupt latency, ….
    • Share the result with community
  • Improving uClinux
    • Need protection
      • inherit ‘Single Address Space Operating System’ research for 64bit processors
    • More compatibility
      • No fork()
      • Fixed heap & stack size
reference
Reference
  • [FASS’03] Adam Wiggins et el. “Implementations of Fast Address-Space Switching and TLB Sharing on the StrongARM Processor”, in the Proceddings of the 8th Australia-Pacific Computer Systems Architecture Conference, Aizu-Wakmatsu City, Japan, September 2003.
  • [LmBench’96] McVoy, L., Staelin, C. “lmbench: Portable tools for performance analysis”. In: Proceedings of the 1996
  • [UC] uClinux/ARM 2.6 Project.http://opensrc.sec.samsung.com/
  • USENIX Technical Conference, San Diego, CA, USA (2996)
  • [24A0] Samsung S3C24A0 Product Datasheet.http://www.samsung.com/Products/Semiconductor/SystemLSI/MobileSolutions/MobileASSP/MobileComputing/S3C24A0/S3C24A0.htm
  • [926] ARM926EJ-S Technical Reference Manual. http://www.arm.com/pdfs/DDI0198D_926_TRM.pdf
  • [ARM] ARM Architecture Reference Manual. ARM LTD.
