An Investigation of the Resistivity of Charcoal. Presented by: Si Hongbo Lin Siqi Wang Chengxu Arun Balasubramaniam. Resistivity.

Download Presentation
## An Investigation of the Resistivity of Charcoal

**An Image/Link below is provided (as is) to download presentation**
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

**An Investigation of the Resistivity of Charcoal**Presented by: Si Hongbo Lin Siqi Wang Chengxu Arun Balasubramaniam**Resistivity**• Electrical resistivity (also known as specific electrical resistance) is a measure of how strongly a material opposes the flow of electric current. • where • ρ/ Ωm, is the resistivity • R/ Ω, is the electrical resistance of a uniform specimen of the material • l/m, is the length of the specimen • A/m², is the cross-sectional area of the specimen http://en.wikipedia.org/wiki/Image:Resistivity_geometry.png**Theories & Principles**• Ohm’s Law: • where I is the current, V is the potential difference, and R is a constant called the resistance • Resistivity equation:**Hypothesis**• Charcoal sticks are not made of pure carbon, but mixed with soil. • Hence, the resistivity measured would be higher than the resistivity of pure carbon • Resistivity of carbon is about 3.5×10-5Ωm • Therefore, I hypothesize that the resistivity of charcoal would be larger than the conventional resistivity of carbon.**Objective & Setups**• To investigate the resistivity of charcoal. • 6 thin charcoal sticks with the same diameter but different lengths**Procedure**• Measuring the length of the charcoal stick. • Adjust the rheostat to the highest resistance. Close the switch. • Adjust the rheostat to certain extent, and record down the voltage V and ampere A shown. • Calculate the resistance values using Ohm’s Law. • Plot a graph of lnR vs. lnl. Determine the average resistivity of charcoal.**Results & Data**Cross-sectional area = 0.00005 m²**Results & Analysis**lnA = -9.9 Plot a graph of lnR vs. lnl, so the y-intercept is**Results & Graph**Plot a graph of lnR vs. lnl We can get the y-intercept to be (0 , 1.65), which is**Conclusion**• We have gotten the experimental value of the resistivity of charcoal, which is about 2.6 x 10-4 Ωm. • The value is larger than the resistivity of carbon, but still very low. • The hypothesis is accepted. The objective is fulfilled.**Precautions**• Experimental precautions: • Charcoal sticks: homogeneous • Temperature • rheostat adjustment • Safety precautions: • keep the voltage within a safety range • To protect the ammeter and voltmeter**Evaluation**• Assumptions: • There is no temperature change. • The charcoal sticks are in regular shape and are thin cylinders. • The charcoal sticks are homogeneous: the percentage of carbon and soil is consistent for all 6 sticks. The carbon and soil are evenly dispersed.**Evaluation**• Assumptions: • The resistance of the voltmeter is extremely large, since its resistance would affect the ampere values recorded. • The experiment is done under constant voltage, since the power supply may work inconsistently.**Evaluation**• Error sources: • Temperature changes affect the resistances of most conductors, since the speed of the delocalized electrons or ions varies with temperature. • High voltage and current cause more heat, due to Joule’s Law: • Inconsistent voltage supply**Evaluation**• Improvement & Extension: • To use electronic multi-meters, which can measure the variables more accurately, instead of classical mechanical ammeters and voltmeters. • To get a better and more consistent power supply. • To get purer charcoal, so that eventually we can measure the resistivity of carbon approximately.**Evaluation**• Personal Comments: • This is the 1st experiment on electricity we have ever carried out since last year. • Experiments (high school level) on electricity & magnetism are relatively easier to conduct. The results are easier to recorded. • From this experiment, we revised the knowledge on resistance, and its related matters.
