Presentation Transcript
lecture 7 clustering and decomposition of a document to authorial components

Lecture 7: Clustering and Decomposition of a Document to Authorial Components

Moshe Koppel and NavotAkiva

clustering
Clustering
  • The idea is to define “natural” clusters
  • Position in space depends on feature set
  • Need to have some notion of what you want in order to choose right feature types
    • e.g., cluster by topic: content words
    • e.g., cluster by author: style features
  • With many features, clusters aren’t so elegant
how many clusters
How Many Clusters?
  • Some methods decide in advance
  • Some methods try to optimize k based on data
    • e.g., in previous example, would want 3 clusters
  • Caution: some optimization criteria biased towards one giant cluster or many tiny ones
flat clustering k means algorithm
Flat Clustering: K-Means Algorithm

Select K random docs {s1, s2,… sK} as seeds.

Until clustering converges or other stopping criterion:

For each doc di:

Assign di to the cluster cjsuch that dist(xi, sj) is minimal.

For each cluster cj:

sj= (cj)(Update the seeds to the centroid of each cluster)

k means example k 2

Pick seeds

Reassign clusters

Compute centroids

Reassign clusters

x

x

Compute centroids

x

x

x

x

K-Means Example (K=2)

Reassign clusters

Converged!

termination conditions
Termination conditions
  • Several possibilities, e.g.,
    • A fixed number of iterations.
    • Doc partition unchanged.
    • Centroid positions don’t change.
convergence
Convergence
  • Why should the K-means algorithm ever reach a fixed point?
    • A state in which clusters don’t change.
  • K-means is a special case of a general procedure known as the Expectation Maximization (EM) algorithm.
    • EM is known to converge.
    • Number of iterations could be large.
convergence of k means
Convergence of K-Means
  • Define goodness measure of cluster k as sum of squared distances from cluster centroid:

Gk = Σi (di – ck)2 (sum over all di in cluster k)

G = Σk Gk

  • Reassignment monotonically decreases G since each vector is assigned to the closest centroid.
dependence on seed choice
Dependence on Seed Choice
  • Results depend on random seed selection.
  • Some tricks for avoiding bad seeds:
    • Choose seed far from any already chosen
    • Try out multiple seed sets

If you start with B and E as centroids

you converge to {A,B,C} and {D,E,F}

If you start with D and F you converge to {A,B,D,E} and {C,F}

a problem
A Problem…
  • The methods we’ve discussed so far don’t always give very satisfying results.
  • Have a look at this example….
spectral methods
Spectral Methods
  • Because of examples like that, spectral methods have been developed.
  • Here’s the idea: Imagine weighted edges between points, where weight reflects similarity. Zero out all edges except k nearest neighbors with high weights.
  • Now make the “cheapest” cuts that result in separate components.
spectral clustering
Spectral Clustering

Properly formulated, the min Ncut problem is NP-hard. But there are some nice linear algebra tricks we can use to get reasonable approximate solutions:

  • Pre-processing
    • Construct a matrix representation of the dataset.
  • Decomposition
    • Compute eigenvalues and eigenvectors of the matrix.
    • Map each point to a lower-dimensional representation based on one or more eigenvectors.
  • Grouping
    • Assign points to two or more clusters, based on the new representation.
new problem separating document components
New Problem: Separating Document Components
  • Often documents consist of multiple authorial components.
  • Our object is to tease apart the components of a composite document.
basic idea
Basic Idea
  • Divide the document into natural chunks (e.g., chapters, paragraphs)
  • Vectorize chunks using some feature set
  • Cluster the vectors
classic example the bible
Classic Example: The Bible
  • Great historic and cultural interest
  • Much prior research on components
  • Has been manually tagged in every conceivable way
test case
Test Case

Let’s throw the chapters of Ezekiel and Jeremiah into a hat and see if we can separate them out.

  • Each is presumably the work of a single (primary) author.
  • There’s no reason to think it’s the same author.
  • They are thematically quite similar, though far from identical.
clustering jeremiah ezekiel
Clustering Jeremiah+Ezekiel
  • Chunks = chapters (no sequence info)
  • Features = bag of words
  • Cluster method = Ncut
  • # clusters = 2
results using all words
Results using all words
  • Not too exciting. We must be picking up thematic or genre-related differences that cross books.
  • Let’s try using only function words.
results using function words
Results using function words
  • Not any better.
  • Let’s try a new approach.
a better idea
A Better Idea
  • Exploit the fact that different authors use different synonyms for the same idea (e.g., makel/mateh).
  • It would be really convenient if it turned out that Jeremiah and Ezekiel made consistently different choices for various synsets.
  • Note that words aren’t synonyms, rather word senses are synonyms. (For example mateh=staff is a synonym of makel, but mateh=tribe is not.)
automatically finding synonyms
Automatically Finding Synonyms
  • There are various clever methods for identifying synsets, but most are not exact enough for our purpose.
  • Conveniently, for the Bible, we have many useful tools, including careful translations and manual sense tagging.
  • We identify as synonyms word senses that are translated into the same English word (e.g., makel=staff and mateh=staff). (We even get sense disambiguation for free.)
  • Due to polysemy (in English), this method overshoots. We manually delete mistakes. (This is the only manual intervention we will ever do.)
synonym method
Synonym Method
  • The usual similarity measures (e.g., cosine, inverse Euclidean distance) aren’t quite right.
    • If two docs use the same synonym, they are similar.
    • If two docs use opposite synonyms, they are different.
    • If one of the docs uses one of the synonyms, but the other doesn’t, cosine would regard them as different. But are they?
  • For measuring similarity, we only consider synsets represented in both docs.
results using synonyms
Results using synonyms
  • Now we’re getting somewhere.
  • But we’re not done yet…
core of a cluster
Core of a Cluster
  • Some chapters are in a cluster because they really belong there; some just have to be somewhere.
  • Let’s consider only chapters near one centroid and far from the other. These are the “cores” of the respective clusters.

36

2

12

3

36

7

4

cluster cores1
Cluster cores

Ezekiel 1, 10

expanding the core
Expanding the Core
  • Now that we have a core, we can use supervised methods (e.g., SVM) to learn a boundary.
  • In fact, we can use function words as our features.
    • Using synonyms will just get us back where we started.
    • And besides, FW are generally very reliable for supervised authorship attribution.
svm expansion of core
SVM expansion of core
  • Two training examples are “misclassed” by SVM.
  • Incredibly, these are Ezekiel 1 and 10, which were part of Jeremiah core, but are on Ezekiel side of optimal SVM boundary.
  • The only exception is Ezekiel 42, a non-core chapter which lies in the SVM margin.
decomposing unsegmented text
Decomposing Unsegmented Text
  • Until now, we’ve assumed that our units (chapters) were all pure Ezekiel or pure Jeremiah. That’s a major unrealistic assumption.
  • Let’s create a munged “Jer-iel” book by alternately taking a random number of verses from each book until we run out of verses.
  • Can we tease that apart?
chunks might be mixed
Chunks Might Be Mixed

xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

chunks might be mixed1
Chunks Might Be Mixed

xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

decomposing unsegmented text1
Decomposing Unsegmented Text
  • Start with some arbitrary chunking of the munged text. (Some of these chunks will be mixed.)
  • Now proceed exactly as above, until you have cluster cores.
  • With a bit of luck, the chunks in the core will be the “pure” chunks.
a munged document
A Munged Document

xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

decomposing unsegmented text2
Decomposing Unsegmented Text
  • As above, use SVM to learn a classifier, using the core chunks as training examples.
  • But at the last step, classify individual verses instead of chapters.
  • Some smoothing techniques are necessary to:
    • Deal with the sparseness of features in individual verses
    • Take advantage of serial correlation
a munged document1
A Munged Document

xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

a munged document2
A Munged Document

xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

a munged document3
A Munged Document

xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

multiple books
Multiple Books
  • The same method works if we create a munged book out of k>2 constituent books.
  • BUT, we need to be given the k.
  • So we don’t yet know how many components there are, only how to best split into a given number of components.
open question
Open Question
  • Can we extend this method so it can be used also for texts that don’t have canonical translations like the Bible?
  • Can we use this method to identify plagiarized sections of a text?
