Preparing Printed Circuit Boards (PCB’s) for Flight Computers. AEM 1905, Fall 2008. Begin with copper-covered plastic sheet called PCB Laminate. Cut the PCB Laminate to size (I used a radial-arm saw). Deburr the edges (I used a Dremel tool with a grinding stone on it).

loader
I am the owner, or an agent authorized to act on behalf of the owner, of the copyrighted work described.
capcha
Download Presentation

PowerPoint Slideshow about 'Preparing Printed Circuit Boards (PCB’s) for Flight Computers' - niveditha


An Image/Link below is provided (as is) to download presentation

Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.


- - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - -
Presentation Transcript
slide6

Scour the boards with a Scotch-brite pad then rinse with acetone. Notice the fingerprints on the board which has not been scoured yet.

slide8

Use an iron (no steam!) on the hottest setting to iron the pattern onto the copper surface. Press down hard for about 3 min.

slide9

Another option is to iron the pattern onto the board rolling on a dowel – easier to apply more pressure to every point on the board.

slide11

After soaking, remove as much backing paper as possible with the fingers. The ink pattern will stick to the copper below.

slide12

After cleaning off as much paper as possible by hand, use a toothbrush to scrub the surface some more. The ink should not come off the copper at all during this process.

slide13

Here is a set of boards, ready for etching. The ink serves as a “etch mask” to protect the copper when it is submerged in etchant.

slide15

Etching is done with a solution that is two parts hydrogen peroxide to one part muriatic acid. Acetone is used for clean-up.

slide17

When immersed in etchant for a few minutes the exposed copper is dissolved. This board is not quite done near the bottom edge.

slide18

Continuously agitate the solution while etching, always wearing gloves. The etch solution turns greens from the copper.

slide20

Here is a fully-etched board, ready for clean up. The plastic under where there used to be copper is actually white.

slide21

Use acetone to wash off the ink etch mask. At right is a set of finished boards, all of which have been etched (because the plastic looks white) but only 3 of which have been cleaned.

drill holes in the pcb i use a dremel tool drill press and a 64 bit for use with pcb s

Drill holes in the PCB (I use a Dremel tool drill press and a #64 bit for use with PCB’s).

Drill gently – it is easy to break off a drill bit that small.
