Presentation Transcript
what is streaming technology
What is streaming technology?
  • A technique for transferring data such that it can be processed as a steady and continuous stream
  • client does not have to download the entire file to view it.

Data

Source

Network

The portion in the buffer

The portion client is viewing

using a web server

G

E

T

:

a

u

d

i

o

/

v

i

d

e

o

f

i

l

e

1

Using a web server
using web server with metafile1
Using web server with metafile
  • Metafile: It contains information i.e. a URL and the type of file , so that media player can identify appropriate media.
  • Media player is directly connected to the web server and streamed over HTTP.
  • Web server stores two files:
    • Actual audio/video file.
    • Metafile.
  • Drawback:
    • Browser and media player use services of HTTP.
    • HTTP is designed to run over TCP.
    • This is appropriate to retrieve the metafile but not audio/video file because TCP retransmits a lost or damaged segment which is counter to the philosophy
using a media server and rtsp operation
Using a media server and RTSP Operation:

HTTP GET

Web

Server

Web

Browser

HTTP

Response

Setup

Play

Media

Player

Media

Server

Media Stream

RTSP

Pause

Teardown

using media server and rtsp
Using Media Server and RTSP
  • Why to use RTSP?

To control the media i.e.

playback of continuous media by

pausing playback,

repositioning ,

fast forwarding ,

rewinding and so on.

  • control protocol designed to add more functionalities to the streaming process.
  • RTSP allows a media player to control the transmission of media stream.
  • RTSP is an out-of-band protocol, similar to second connection in FTP.
  • RTSP messages can be sent over either TCP or UDP.
  • RTSP works in the conjunction with RTP to deliver streaming audio & video content
  • RTSP maintains a server state during transmission unlike HTTP
example of rtsp session
Example of RTSP session :

C->S: SETUP rtsp://example.com/media.mp4/streamid=0 RTSP/1.0

CSeq: 3

Transport: RTP/AVP;unicast;client_port=8000-8001

S->C: RTSP/1.0 200 OK

CSeq: 3

Transport: RTP/AVP;unicast;client_port=8000-8001;server_port=9000-9001

Session: 12345678

C->S: PLAY rtsp://example.com/media.mp4 RTSP/1.0

CSeq: 4

Range: npt=5-20

Session: 12345678

S->C: RTSP/1.0 200 OK

CSeq: 4

Session: 12345678

RTP-Info: url=rtsp://example.com/media.mp4/streamid=0;seq=9810092;rtptime=3450012

C->S: PAUSE rtsp://example.com/media.mp4 RTSP/1.0

CSeq: 5

Session: 12345678

S->C: RTSP/1.0 200 OK

CSeq: 5

Session: 12345678

C->S: TEARDOWN rtsp://example.com/media.mp4 RTSP/1.0

CSeq: 8

Session: 12345678A

S->C: RTSP/1.0 200 OK

CSeq: 8

references
References
  • www.cs.unibo.it/~ghini/didattica/sistmultimed/Streaming.pdf
  • www.ida.liu.se/~TDDD36/tddd36-streaming.pdf
  • James F. Kurose, Keith W. Ross. Computer Networking, 5thEdition, Addison Wesley Longman, Inc, 2003
  • http://en.wikipedia.org/wiki/Real_Time_Streaming_Protocol
