Presentation Transcript
slide2
Aim
  • To explain how to ensure the quality of samples for an External Quality Assessment Scheme
outline of presentation
Outline of Presentation
  • Issues involved in sample preparation
  • Distributing panels to EQAS participants in SEA/WP
slide4

Ensuring the quality of EQAS samples:

Issues to be considered

  • 2. Material (sample bank)
  • collect samples
  • characterise samples
  • maintain database
  • 1. Resources
  • laboratory facilities, train staff
  • equipment, space
  • material
  • 4. Sample distribution
  • produce documents
  • coordinate shipping
  • review sample state
  • 3. Panel preparation
  • pose a ‘question’
  • select samples from the Bank
  • retest samples, prepare panel
preparing quality eqas samples
Preparing quality EQAS samples
  • Try and decide:
    • Who?
    • What?
    • Where?
    • When?
    • Why?
    • How?
slide6

Ensuring the quality of EQAS samples:

Issues to be considered

  • 2. Material (sample bank)
  • collect samples
  • characterise samples
  • maintain database
  • 1. Resources
  • laboratory facilities, train staff
  • equipment, space
  • material
  • 4. Sample distribution
  • produce documents
  • coordinate shipping
  • review sample state
  • 3. Panel preparation
  • pose a ‘question’
  • select samples from the Bank
  • retest samples, prepare panel
1 resources required to coordinate an eqas laboratory
1. Resources required to coordinate an EQAS - Laboratory

Samples need to be tested

Therefore provider should have access to a:

  • laboratory with testing facilities

*provider may contract out laboratory services

  • laboratory with technical competence
    • participate in other EQAS
    • hold accreditations
1 resources required to coordinate an eqas trained staff
1. Resources required to coordinate an EQAS - Trained Staff
  • Provider should train staff in EQAS procedures
    • significant amount of time is required to train staff during EQAS development
  • Staff need to:
    • coordinate sample bank, perform testing
    • prepare panels, coordinate shipments
    • communicate with participants
    • be prepared to educate participants
1 resources required to coordinate an eqas equipment and space
1. Resources required to coordinate an EQAS - Equipment and Space

Provider should have access to:

  • equipment required for testing of serology samples
  • general items such as:
    • fridge, freezers, bottles
    • vials, shipping boxes
  • space
    • for packaging samples for distribution
    • for general purpose storage
slide14

1. Resources required to coordinate an EQAS - Biological Material

Providers must develop and maintain a sample bank:

  • Significant resources required during development
    • source material
    • characterise new samples
    • develop data base
  • Continual resources to maintain
slide15

Ensuring the quality of EQAS samples:

Issues to be considered

  • 2. Material (sample bank)
  • collect samples
  • characterise samples
  • maintain database
  • 1. Resources
  • laboratory facilities, train staff
  • equipment, space
  • material
  • 4. Sample distribution
  • produce documents
  • coordinate shipping
  • review sample state
  • 3. Panel preparation
  • pose a ‘question’
  • select samples from the Bank
  • retest samples, prepare panel
2 sample bank
2. Sample Bank

Collection of biological material (1)

  • large volumes
  • best possible quality
  • plasma or serum?
    • thrombinisation and recalcification
      • technically difficult
      • risk of bacterial contamination
2 sample bank17
2. Sample Bank

Collection of biological material (2)

  • Representative of the geographical area
  • Unusual samples
    • may be required to purchase
  • Collect from
    • collaborating laboratories
    • participants
    • purchase
2 sample bank18
2. Sample Bank

Processing and storage of material

  • Allocate material with unique identifier
  • Aliquot material into smaller volumes
  • Monitor freeze/thaw cycles
  • Use polypropylene tubes and bottles
  • Label all bottles/tubes
  • Store at -20C or -40C
2 sample bank19
2. Sample Bank

Characterisation of material

  • Test according to testing strategy
    • determine disease status
  • WHO recommend:
    • two immunoassays (2nd with different Ags)
    • one specific supplemental assay
    • Similar technology to assays used in region
2 sample bank20
2. Sample Bank

Store data on all material in sample bank

  • Store sample information in a Database
  • For each sample store:
    • volume available and location
    • information provided with the material
    • characterisation results
      • assays used, S/Co ratio, disease status
    • other information, e.g. subtype/genotype
slide22

Ensuring the quality of EQAS samples:

Issues to be considered

  • 2. Material (sample bank)
  • collect samples
  • characterise samples
  • maintain database
  • 1. Resources
  • laboratory facilities, train staff
  • equipment, space
  • material
  • 4. Sample distribution
  • produce documents
  • coordinate shipping
  • review sample state
  • 3. Panel preparation
  • pose a ‘question’
  • select samples from the Bank
  • retest samples, prepare panel
3 panel preparation
3. Panel Preparation

Design each panel to ask a “question”

Specific questions that may be addressed:

  • Do Laboratories:
    • identify the status of samples correctly?
    • produce consistent results?
    • follow their testing strategies?
    • follow the manufacturers protocol?
    • check samples are correctly labelled?
3 panel preparation24
3. Panel Preparation

Selection of EQAS Panel samples (1)

  • Review sample bank database
  • Select 8-10 specimens
    • with a definite serostatus
    • strongly reactive, weakly reactive and negative
    • select different numbers of positive and negative samples for each panel
3 panel preparation25
3. Panel Preparation

Selection of EQAS Panel samples (2)

  • Replicates
  • Diluted and pooled samples
    • increases the available volume
    • such samples are not representative of true samples
3 panel preparation26
3. Panel Preparation

Preparation of EQAS Panel samples (1)

  • Biocides
    • Not recommended but can use Bronidox L (0.05%)
  • Heat Inactivation
    • 60 minutes at 56ºC for HIV
    • Better to treat everything as infectious

EQAS samples should be representative of routine diagnostic specimens

3 panel preparation27
3. Panel Preparation

Preparation of EQAS Panel samples (1)

  • Lyophilisation
    • May be necessary if transport conditions indicate
    • Requires expensive equipment

EQAS samples should be representative of routine diagnostic specimens

3 panel preparation28
3. Panel Preparation

Preparation of EQAS Panel samples (2)

  • Ensure traceability
    • use checklists, record who did what and when
  • Remove material from sample bank
    • thaw, if material was stored in >1 bottle - pool
    • centrifuge
    • re-test sample to ensure serostatus has not changed
      • specific confirmatory test e.g. Western blot
3 panel preparation29
3. Panel Preparation

Preparation of EQAS Panel samples (3)

  • Tube integrity and labelling
    • leak proof screw capped plastic tubes
    • good quality labels, electronically prepared
    • segregated tube labelling
3 panel preparation30
3. Panel Preparation

Preparation of EQAS Panel samples (3)

  • Aliquot material
    • segregated aliquotting
      • only one sample in hood at one time
    • store panel at 4º, dispatch as soon as possible
3 panel preparation31
3. Panel Preparation

Sample Validation: Homogeneity Testing

  • Panel samples should be tested to ensure that they are homogenous.

Homogenous (evenly distributed)

Non-Homogenous

3 panel preparation32
3. Panel Preparation

Sample Validation: Stability Testing

  • Panel samples should be tested to ensure that their reactivity is stable over time

Unstable

slide33

Ensuring the quality of EQAS samples:

Issues to be considered

  • 2. Material (sample bank)
  • collect samples
  • characterise samples
  • maintain database
  • 1. Resources
  • laboratory facilities, train staff
  • equipment, space
  • material
  • 4. Sample distribution
  • produce documents
  • coordinate shipping
  • review sample state
  • 3. Panel preparation
  • pose a ‘question’
  • select samples from the Bank
  • retest samples, prepare panel
4 sample distribution
4. Sample Distribution
  • Documentation to be included with the panel

i) Covering letter

    • identifies the sample details
    • gives instructions for testing
    • designated the due date for return of results

ii) Result forms

iii) Ask laboratories to confirm:

    • that samples were received
    • confirm contact and shipping address details
4 sample distribution35
4. Sample Distribution

Co-ordinate panel distribution

  • Panels should be distributed in accordance with IATA regulations for other regulation for shipping dangerous goods
  • Ensure all documents are supplied
slide36

Shipping of samples to the South East Asian and Western Pacific Regions: Anti-HIV, anti-HCV and HBsAg.

National Serology Reference Laboratory, Australia

the nrl experience
The NRL experience

Problems encountered

  • Complex contact details
  • Complex paperwork
  • Complex communications
the nrl experience38
The NRL experience

Problems encountered

  • Results are often not returned by some participants
  • Obtaining accurate information from participants is often difficult and time consuming
the nrl experience40
The NRL experience

Tips for minimizing shipping costs

  • Cost savings:
      • good courier company
      • collaborators picking up samples from the airport
      • collaborators redistributing samples within one country
summary
Summary
  • Good quality samples are required for participants to have confidence in the EQAS.
  • Best quality samples are planned for at each step of the EQAS.
  • Resources are required to achieve the best possible quality samples
