  1. AGATALocal Level Processing Present implementation Daniele, Dino, Enrico, Francesco

  2. Gobal Trigger Detector preamps Detector Level Digitisers Ancillary Clock 100 MHz T-Stamp Core + 36 seg. PSA Pre-processing Ancillary GlobalLevel EventBuilder/Merger Control, Storage… Tracking Ancillary Detectors Structure of EDAQ

  3. Goals of the local level processing • Manage all processing that is done on the germanium detectors • Readout the front end electronics • Local event builder to merge the data of master and slave ATCA carrier cards • Write the events into Crystal Frame • Preparation of data: -> calibrations, cross-talk corrections, timing,… • Pulse Shape Analysis • Tracking (formally part of the global level processing)

  4. Implementation issues • Extremely difficult to write programs in a distributed parallel environment as Narval • Almost no debugging tools (up to printouts) • Joa Ljungvall has developed an emulator (C_Test) based on shared libraries loaded at runtime (like in narval) major step forward allowing the the use of debug and profiling tools (gdb, valgrind, KDevelop…) • Two-class approach: • Most usual tasks (set-up and decoding/recoding of the events from/to adf frames ) taken up by the mother class • algo-specific parts (e.g. PSA, Tracking) can be done by an inherited class that re-implements the Process() virtual method • The driver program (“Narval emulator”) loads the shared libraries and takes care of passing the data from • Based on this, a self contained emulator was developed locally with the driver program (WinCtest) extended to handle several crystals in parallel, an event builder and a (pseudo) merger for ancillary data

  5. Emulator WinCtest • Written using the free Microsoft IDE Visual Studio Express by (mainly because of its excellent Debugger) • Runs on Cygwin and GNU Linux using the gcc toolchain • The makefiles for Linux produce the libXXX.so used in Narval • Multi-core CPUs exploited using threads provided by the Boost library (version > 1.35) • Joa’s C_Test is still used as a final test before going to Narval  Don’t use the emulator if you analyse more then 1 ATC  Install and learn to use Narval

  6. Organization of directoriessource code narval_emulator misc_actors1 filters filters/Preprocessing WinCtest environment variable ADF_CONF_PATH Still using a “local” version of ADF

  7. ReadoutCrystalProducer/CrystalProducerATCA • The main problem to solve was the readout of the master and slave ATCA cards in such a way that they do not block each other • Readout performed by 2 independent threads and bounded buffers (ring buffers) • Synchronization with the main program done using mutex and conditions • All this can be excluded when reading data from files (by not defining the USETHREADS symbol) • The local event builder is derived from previous work done to merge the 10 TNT2 digitizers used previously as DAQ of a single crystal • The events are formatted into an ADF data:crystal frames • Estimated readout is ~50 kevents/s (not using adf methods), which is the design goal of AGATA • This is still a Mother-Daughter class approach but will probably be merged into a single class as it is unlikely to be changed much • The original data can be written to disk and replayed with the same program • Very useful to develop and debug the programs • Usually we write the locally merged data • This is the bottleneck of the whole processing chain  1 event = 14 kiB • Used also to read ancillary data (DANTE) in the 2009-week27 test

  8. Preprocessing PreprocessingFilter/PreprocessingFilterPSA • Decoding and recoding of events done by the mother class using the ADF methods (decoding the input could be done without) • Data processing (Process method) is done in the daughter class, also heavily based on previous work with the single crystal • Energy calibrations and cross-talk corrections • Calibration and xTalk coefficient produced automatically by a set of program and procedures prepared by Francesco. • Baseline removal and energy calibration of traces (no cross talk correction yet) • Digital CFD applied to the core to better determine T0 • Loss of efficiency at low energy (which we tried to avoid in the front end electronics by using a LE discriminator) • All traces are shifted event-by-event by the same (integer) amount • The subsample interpolation of T0 passed to the PSA but not presently used • Several Energy and Time spectra displayed with GRU or saved to disk in a flat binary format. • The output format is data:ccrystal frames with 80 samples as 4-byte floats instead of the original 160 2-byte shorts • ~same size as input • Estimated throughput is 5 kevents/s/process • xTalk correction of traces could slow down significantly

  9. PSA PSAFilter/PSAFilterGridSearch • Input data decoded to local structures using adf methods • Grid Search algo by Roberto Venturelli ported originally to the the daughter class by Joa • Reads the signal basis (binary format) in the initialization phase • Multi-segment events are decomposed in single-segment hits • Assumes only 1 interaction in the hit segments • Does not (normally) use the net-charge signal but only nearest neighbours in the search • The actual grid search can done in parallel either by multiple instances of the actor (Narval feature) or by assigning it to worker threads running in one process • ~0.5 kevents/s/core with the full search • ~4 kevents/s/core with a 2-steps search • Several spectra or matrices to be displayed with ViGRU or written as flat binaries to disk. • Output data formatted as data:psa frames (~200 B/hit which could be reduced a lot by using float instead of double and removing the errors which are not calculated by this algorithm)

  10. Ancillary readoutAncillaryProducerTCP • Written by Enrico Calore • TCP server using the skstream • Non blocking • Data formatted as data:ranc0 (a plain array of integer numbers plus timestamp and event number in the key part of the frame) • Not using ADF • Original data can be saved to disk and replayed like for the CrystalProducers

  11. Ancillary processingAncillaryFilter/AncillaryFilterDante • Developed first for Dante (data taken with the AGATA electronics) • Being extended now by Daniele and Enrico for PRISMA • Mother-daughter structure similar to the other actors • Decoding from ADF data:ranc0 frames done by the SetInput() in the mother class • Analysis done by Process() in the daughter class • Calibrations • analysis of DANTE to obtain the recoil velocity vector (in the AGATA reference frame) • analysis of PRISMA to select reaction channel and determine velocity vector in the PRISMA/AGATA reference frame • Coding back to data:ranc1 done by SetOutput() in the mother class  Francesco has added the possibility to write the data into raw binary files or a root tree • This is the most variable part of the online libraries and needs to be organized carefully

  12. EventBuilder • C++ version to emulate the Narval (ADA) event builder written by Xavier Grave • Builds events using timestamp or event number • Data formatted as event:data:psa • For ancillaries: • First, data:ranc1 frames are packed together with data:psa frames into event:data:psa • Then a merger function is called to reformat the event:data:psa frame into an event:data frame, containing the event:data:psa and the data:ranc1 frames • The ancillary part is enabled by the AddMerger keyword in the setup-file EventBuilder.conf

  13. TrackingTrackingFilter/TrackingFilterOFT • Mother class in charge of set-up and decoding (SetInput) and recoding (SetOutput) • Orsay Forward Tracking implemented in the daughter class (Process methods) • This actor is presently used also to control the experiment/analysis but this stuff should be moved to other actors (e.g. PreTracking and PostTracking) or to the watchers • With 2 ATCs can handle ~2 kevents/second/process Should run multiple instances in parallel (Narval)

  14. Organization directoriesdata taking and offline analysis zCurrentNarvalDataDir Conf Conf/1R Data Out Conf/Ancillary Standardized names for directories and (most of the) configuration files Should introduce environment variables to point to the actual directories

  15. Topology for 2 ATCs + Ancillary Chain 3 1R/ Producer CrystalProducerATCA Filter PreprocessingFilterPSA Filter PSAFilterGridSearch Chain 3 1G/ Producer CrystalProducerATCA Filter PreprocessingFilterPSA Filter PSAFilterGridSearch Chain 3 1B/ Producer CrystalProducerATCA Filter PreprocessingFilterPSA Filter PSAFilterGridSearch Chain 3 2R/ Producer CrystalProducerATCA Filter PreprocessingFilterPSA Filter PSAFilterGridSearch Chain 3 2G/ Producer CrystalProducerATCA Filter PreprocessingFilterPSA Filter PSAFilterGridSearch Chain 3 2B/ Producer CrystalProducerATCA Filter PreprocessingFilterPSA Filter PSAFilterGridSearch Chain 2 ./ Builder EventBuilder Filter TrackingFilterOFT ~3 GiB of memory needed Make your tests with 1 or 2 crystalsand run the real analysis in Narval
