    1. Introduction to the Web and .NET

    2. Internet Technologies The World Wide Web A way to access and share information Technical papers, marketing materials, recipes, ... A huge network of computers: the Internet Graphical, not just textual Information is linked to other information Application development platform Shop from home Provide self-help applications for customers and partners ... The Web can be viewed from many different perspectives.The Web can be viewed from many different perspectives.

    3. Internet Technologies WWW Architecture This is the basic architecture of the web. A browser running on a client machine makes a request to a server using the HTTP protocol over TCP/IP. The server responds with an HTML page, which is rendered in the browser.This is the basic architecture of the web. A browser running on a client machine makes a request to a server using the HTTP protocol over TCP/IP. The server responds with an HTML page, which is rendered in the browser.

    4. Internet Technologies WWW Architecture Client/Server, Request/Response architecture You request a Web page e.g. http://www.msn.com/default.asp HTTP request The Web server responds with data in the form of a Web page HTTP response Web page is expressed as HTML Pages are identified as a Uniform Resource Locator (URL) Protocol: http Web server: www.msn.com Web page: default.asp Can also provide parameters: ?name=Leon

    5. Internet Technologies Hypertext Markup Language (HTML) The markup language used to represent Web pages for viewing by people Designed to display data, not store/transfer data Rendered and viewed in a Web browser Can contain links to images, documents, and other pages Not extensible Derived from Standard Generalized Markup Language (SGML) HTML 3.2, 4.01, XHTML 1.0 Objects such as images, audio, video, and documents are not actually enclosed in the HTML Web page, but are referenced by the page. When you tell your browser to display a Web page, it may have to make multiple requests to the server (or possibly different servers) to get all the referenced objects. Example: Get default.asp may result in additional requests for the following files: Get image1.gif Get image2.jpeg Get video1.mpeg …Objects such as images, audio, video, and documents are not actually enclosed in the HTML Web page, but are referenced by the page. When you tell your browser to display a Web page, it may have to make multiple requests to the server (or possibly different servers) to get all the referenced objects. Example: Get default.asp may result in additional requests for the following files: Get image1.gif Get image2.jpeg Get video1.mpeg …

    6. Internet Technologies HTML Forms Enables you to create interactive user interface elements Buttons Text boxes Drop down lists Check boxes User fills out the form and submits it Form data is sent to the Web server via HTTP when the form is submitted

    7. Internet Technologies HTTP HTTP is a stateless protocol Each HTTP request is independent of previous and subsequent requests HTTP 1.1 introduced keep-alive for efficiency Statelessness has a big impact on how scalable applications are designed

    8. Internet Technologies Cookies A mechanism to store a small amount of information (up to 4KB) on the client A cookie is associated with a specific web site Cookie is sent in HTTP header Cookie is sent with each HTTP request Can last for only one session (until browser is closed) or can persist across sessions Can expire some time in the future

    9. Internet Technologies Multipurpose Internet Mail Extensions (MIME) Defines types of data/documents text/plain text/html image/gif image/jpeg audio/x-pn-realaudio audio/x-ms-wma video/x-ms-asf application/octet-stream

    10. Internet Technologies Browsers Client-side application Requests HTML from Web server and renders it Popular browsers: Netscape Internet Explorer Opera others Also known as a User Agent

    11. Internet Technologies Clients & Servers Clients Generally supports a single user Optimized for responsiveness to user User interface, graphics Servers Supports multiple users Optimized for throughput More: CPUs (SMP), memory, disks (SANs), I/O Provide services (e.g. Web, file, print, database, e-mail, fax, transaction, telnet, directory)

    12. Internet Technologies Proxy Servers & Firewalls Proxy Server A server that sits between a client (running a browser) and the Internet Improves performance by caching commonly used Web pages Can filter requests to prevent users from accessing certain Web sites Firewall A server that sits between a network and the Internet to prevent unauthorized access to the network from the Internet

    13. Internet Technologies Networks Network = an interconnected collection of independent computers Why have networks? Resource sharing Reliability Cost savings Communication Web technologies add: New business models: e-commerce, advertising Entertainment Applications without a client-side install Not too long ago it was quite reasonable to ask “Why do we need networks?” Now the question seems silly! Not too long ago it was quite reasonable to ask “Why do we need networks?” Now the question seems silly!

    14. Internet Technologies Networks Network technology is largely determined by scale: Local Area Network (LAN): Span up to a few kilometers. Bus vs. ring topologies Wide Area Networks (WAN): Can span a country or continent. WANs use routers as intermediate nodes to connect transmission lines

    15. Internet Technologies Networks Network technology Broadcasting Packets of data are sent from one machine and received by all computers on the network Multicast: packets are received by a subset of the machines on a network Point-to-point Packets have to be routed from one machine to another; there many be many paths In general, geographically localized networks use broadcasting, while disperse networks use point-to-point

    16. Internet Technologies Networks This figure depicts the different layers used in networking protocols.This figure depicts the different layers used in networking protocols.

    17. Internet Technologies Network Protocol Stack Physically, a request goes down the protocol stack on the client, across the network to the server, then up the server’s protocol stack (solid arrows). Logically, however, the corresponding layers on each machine “talk” to each other (dashed arrows).Physically, a request goes down the protocol stack on the client, across the network to the server, then up the server’s protocol stack (solid arrows). Logically, however, the corresponding layers on each machine “talk” to each other (dashed arrows).

    18. Internet Technologies Networks - Domain Name System (DNS) Provides user-friendly domain names, e.g. www.msn.com Hierarchical name space with limited root names DNS servers map domain names to IP addresses

    19. Internet Technologies Extensible Markup Language (XML) Represents hierarchical data A meta-language: a language for defining other languages Extensible Useful for data exchange and transformation Simplified version of SGML

    20. Programming Languages Machine code Assembly language High-level languages Fortran, LISP, Cobol C, Pascal, Basic, Smalltalk C++, Eiffel Java, C# Scripting languages Shell scripts, Perl, TCL, Python, JavaScript, VBScript

    21. Programming Paradigms Unstructured programming Structured programming Object-oriented programming Component-based programming Event-based programming

    22. Programming Paradigms Unstructured Programming See “Go To Statement Considered Harmful” at http://www.acm.org/classics/oct95/ In reality, the “go to” statement is not inherently “evil”, but should be used in a structured manner. C# supports “go to”s, but only in a limited way.In reality, the “go to” statement is not inherently “evil”, but should be used in a structured manner. C# supports “go to”s, but only in a limited way.

    23. Programming Paradigms Structured Programming Sequence Conditional if then else switch Looping for i from 1 to n do while do until Functions Exceptions Structured programming addresses the problems involved in writing a single procedure. It doesn’t help too much when large-scale systems are involved.Structured programming addresses the problems involved in writing a single procedure. It doesn’t help too much when large-scale systems are involved.

    24. Programming Paradigms Object-Oriented Programming Objects have data and behavior Data: members, fields, variables, slots, properties Behavior: methods, functions, procedures Using objects is easy First instantiate the type of object desired Then call its methods and get/set its properties Designing new types of objects can be hard Design goals often conflict: simplicity, functionality, reuse, performance Object-oriented programming actually builds upon structured programming. Structured programming techniques are used within individual methods.Object-oriented programming actually builds upon structured programming. Structured programming techniques are used within individual methods.

    25. Programming Paradigms Object-Oriented Programming Key object-oriented concepts Identity Encapsulation Data + behavior Information hiding (abstraction) Classes vs. instances Polymorphism Interfaces Delegation, aggregation Inheritance Patterns

    26. Programming Paradigms Component-Based Programming Components Independent modules of reuse and deployment Coarser-grained than objects (objects are language-level constructs) Includes multiple classes Often language-independent In the general case, the component writer and the component user don’t know each other, don’t work for the same company, and don’t use the same language Components build upon object-oriented concepts.Components build upon object-oriented concepts.

    27. Programming Paradigms Component-Based Programming Component Object Model (COM) Initial Microsoft standard for components Specifies a protocol for instantiating and using components in-process, across processes or across machine boundaries Basis for ActiveX, OLE, and many other technologies Can be created in Visual Basic, C++, .NET, … Java Beans Java standard for components Not language-independent

    28. Programming Paradigms Event-Based Programming When something of interest occurs, an event is raised and application-specific code is executed Events provide a way for you to hook in your own code into the operation of another system Event = callback User interfaces are all about events onClick, onMouseOver, onMouseMove… Events can also be based upon time or interactions with the network, operating system, other applications, etc.

    29. Programming the Web Client-Side Code What is client-side code? Software that is downloaded from Web server to browser and then executes on the client Why client-side code? Better scalability: less work done on server Better performance/user experience Create UI constructs not inherent in HTML Drop-down and pull-out menus Tabbed dialogs Cool effects, e.g. animation Data validation

    30. Programming the Web Client-Side Technologies DHTML/JavaScript COM ActiveX controls COM components Remote Data Services (RDS) Java Plug-ins Helpers Remote Scripting

    31. Programming the Web Dynamic HTML (DHTML) Script that is embedded within an HTML page Usually written in JavaScript (ECMAScript, JScript) for portability Internet Explorer also supports VBScript and other scripting languages Each HTML element becomes an object that has associated events (e.g. onClick) Script provides code to respond to browser events

    32. Programming the Web ActiveX Based on COM Native only to Internet Explorer Supported in Netscape with a plug-in Good when you know your users (e.g. intranet) or can specify which browser to use Small, efficient code

    33. Programming the Web Java Applets Based on Java bytecode Held great promise as a portable, pain-free way to download client-side code: “Write once, run anywhere” Fairly safe: code runs in a “sandbox” Compatibility and performance issues have prevented common usage

    34. Programming the Web Server-Side Technologies Common Gateway Interface (CGI) Internet Server API (ISAPI) Netscape Server API (NSAPI) Active Server Pages (ASP) Java Server Pages (JSP) Personal Home Page (PHP) Cold Fusion (CFM) ASP.NET

    35. Programming the Web Active Server Pages (ASP) Technology to easily create server-side applications ASP pages are written in a scripting language, usually VBScript or JScript An ASP page contains a sequence of static HTML interspersed with server-side code ASP script commonly accesses and updates data in a database

    36. Programming the Web ASP An ASP page receives input from a HTTP request, and then dynamically generates a new HTML page that is returned to the client. ASP can also return XML or other types of data.An ASP page receives input from a HTTP request, and then dynamically generates a new HTML page that is returned to the client. ASP can also return XML or other types of data.

    37. Introduction to .NET What is .NET? A vision of how information technology will evolve A platform that supports the vision A business model of software as a service .NET is a broad initiative that can be viewed from several perspectives..NET is a broad initiative that can be viewed from several perspectives.

    38. Introduction to .NET What is .NET? A vision Web sites will be joined by Web services New smart devices will join the PC User interfaces will become more adaptable and customizable Enabled by Web standards .NET will enable the next generation of applications. .NET will enable the next generation of applications.

    39. A platform The .NET Framework Visual Studio.NET .NET Enterprise Servers Database, Messaging, Integration, Commerce, Proxy, Security, Mobility, Orchestration, Content Management .NET Building Block Services Passport .NET My Services (“Hailstorm”) Goal: make it incredibly easy to build powerful Web applications and Web services Introduction to .NET What is .NET? Microsoft is providing a suite of products and services to facilitate building this next generation. This course focuses on the .NET Framework and Visual Studio.NET.Microsoft is providing a suite of products and services to facilitate building this next generation. This course focuses on the .NET Framework and Visual Studio.NET.

    40. Introduction to .NET The .NET Platform Each blue box represents a separate computer (or cluster of computers).Each blue box represents a separate computer (or cluster of computers).

    41. Web Services Evolution of the Web The first generation of Web applications was largely about delivering non-interactive content, i.e. publishing non-interactive HTML pages. For example, many applications simply operated in client/server mode and rendered HTML pages to send across the internet to browsers. The second generation of Web applications was about creating applications usable over the Web. E-commerce is an example; you can go to http://www.barnesandnoble.com/ select books, order them and pay for them. This second generation also includes a more scalable back-end (e.g. WinDNA architecture) and a richer UI (e.g. DHTML and ActiveX). However, useful though they may be, the second generation largely resulted in application islands on the Web. Yes, there are hyperlinks between sites, but for the most part, the actual applications at different sites do not interact. The third generation of Web application is about using Web protocols and XML throughout to allow better integration between services on the Web. Protocols such as XML and SOAP allow you to create Web Services, enabling people and companies to easily create integrated applications. The first generation of Web applications was largely about delivering non-interactive content, i.e. publishing non-interactive HTML pages. For example, many applications simply operated in client/server mode and rendered HTML pages to send across the internet to browsers. The second generation of Web applications was about creating applications usable over the Web. E-commerce is an example; you can go to http://www.barnesandnoble.com/ select books, order them and pay for them. This second generation also includes a more scalable back-end (e.g. WinDNA architecture) and a richer UI (e.g. DHTML and ActiveX). However, useful though they may be, the second generation largely resulted in application islands on the Web. Yes, there are hyperlinks between sites, but for the most part, the actual applications at different sites do not interact. The third generation of Web application is about using Web protocols and XML throughout to allow better integration between services on the Web. Protocols such as XML and SOAP allow you to create Web Services, enabling people and companies to easily create integrated applications.

    42. A set of technologies for developing and using components to create: Web Forms Web Services Windows Applications Supports the software lifecycle Development Debugging Deployment Maintenance The .NET Framework What Is the .NET Framework? The .NET Framework provides a set of technologies that makes creating, deploying, using and maintaining applications (including Web applications and Web Services) much easier and more robust.The .NET Framework provides a set of technologies that makes creating, deploying, using and maintaining applications (including Web applications and Web Services) much easier and more robust.

    43. The .NET Framework The .NET Framework and Visual Studio.NET The .NET framework exposes numerous classes to the developer. These classes allow the development of rich client applications and Web-based applications alike. The classes are shown here, divided into four areas. ASP.NET provides the core Web infrastructure, such as Web Forms for UI-based development and Web Services for programmatic interface development. User interface development on the Windows platform can be done using Windows Forms. ADO.NET and XML provide the functionality for data access. The core base classes provide infrastructure services such as security and transaction management. You can create code in any of a large number of languages. This code will integrate in a deep, seamless manner via a standard called the Common Language Specification. Visual Studio.NET provides tools that increases your productivity when creating applications.The .NET framework exposes numerous classes to the developer. These classes allow the development of rich client applications and Web-based applications alike. The classes are shown here, divided into four areas. ASP.NET provides the core Web infrastructure, such as Web Forms for UI-based development and Web Services for programmatic interface development. User interface development on the Windows platform can be done using Windows Forms. ADO.NET and XML provide the functionality for data access. The core base classes provide infrastructure services such as security and transaction management. You can create code in any of a large number of languages. This code will integrate in a deep, seamless manner via a standard called the Common Language Specification. Visual Studio.NET provides tools that increases your productivity when creating applications.

    44. The .NET Framework .NET Framework Classes This is but a brief illustration of the breadth of classes provided by the .NET Framework. We will explore many of these classes during this course. All of these classes are available to ALL languages.This is but a brief illustration of the breadth of classes provided by the .NET Framework. We will explore many of these classes during this course. All of these classes are available to ALL languages.

    45. Common Language Runtime Compilation As a developer you can write code in the language of your choice. Your code is compiled into an Assembly, which is represented as a DLL or EXE. As a developer you can write code in the language of your choice. Your code is compiled into an Assembly, which is represented as a DLL or EXE.

    46. Windows Forms Framework for building rich clients Built upon .NET Framework, languages Rapid Application Development (RAD) Visual inheritance Anchoring and docking Rich set of controls Extensible controls Data-aware Easily hooked into Web Services ActiveX support Licensing support Printing support Advanced graphics Windows Forms is a framework for building rich Windows client applications, and can be written in any language that supports .NET. Windows Forms provide the developer with many features, such as: The simplicity that Visual Basic 6 programmers are used to. Easy deployment. Windows Forms (as .NET applications) automatically takes advantage of the versioning and deployment features of the .NET Framework. Windows Forms offers an architecture for controls and control containers based on concrete implementation of the control and container classes. This significantly reduces control-container interoperability issues. Security. Windows Forms takes full advantage of the security features of .NET. This means that Windows Forms can be used to implement everything from an untrusted control running in the browser to a fully trusted application installed on a user's hard drive. Web Services Support. Windows Forms offer full support for quickly and easily connecting to Web Services. Rich Graphics. Controls. Windows Forms offer a rich set of controls that encompass all of the controls offered by Windows and new features such as new "flat look" styles for Buttons, Radio Buttons and Checkboxes. Data Awareness. Windows Forms offer full support for the ADO.NET data model. ActiveX Controls. Windows Forms offer full support for ActiveX controls. You can easily host ActiveX controls in a Windows Forms application. You can also host a Windows Form control as an ActiveX control. Licensing. Windows Forms take advantage of the .NET Framework enhanced licensing model. Printing. Windows Forms offer a printing framework that enables applications to provide comprehensive reports. Accessibility. Windows Form controls implement the interfaces defined by Microsoft Active Accessibility (MSAA), making it straightforward to build applications that support accessibility aids such as screen readers. Windows Forms is a framework for building rich Windows client applications, and can be written in any language that supports .NET. Windows Forms provide the developer with many features, such as: The simplicity that Visual Basic 6 programmers are used to. Easy deployment. Windows Forms (as .NET applications) automatically takes advantage of the versioning and deployment features of the .NET Framework. Windows Forms offers an architecture for controls and control containers based on concrete implementation of the control and container classes. This significantly reduces control-container interoperability issues. Security. Windows Forms takes full advantage of the security features of .NET. This means that Windows Forms can be used to implement everything from an untrusted control running in the browser to a fully trusted application installed on a user's hard drive. Web Services Support. Windows Forms offer full support for quickly and easily connecting to Web Services. Rich Graphics. Controls. Windows Forms offer a rich set of controls that encompass all of the controls offered by Windows and new features such as new "flat look" styles for Buttons, Radio Buttons and Checkboxes. Data Awareness. Windows Forms offer full support for the ADO.NET data model. ActiveX Controls. Windows Forms offer full support for ActiveX controls. You can easily host ActiveX controls in a Windows Forms application. You can also host a Windows Form control as an ActiveX control. Licensing. Windows Forms take advantage of the .NET Framework enhanced licensing model. Printing. Windows Forms offer a printing framework that enables applications to provide comprehensive reports. Accessibility. Windows Form controls implement the interfaces defined by Microsoft Active Accessibility (MSAA), making it straightforward to build applications that support accessibility aids such as screen readers.

    47. Web Forms Built with ASP.NET Logical evolution of ASP Similar development model: edit the page and go Requires less code New programming model Event-driven/server-side controls Rich controls (e.g. data grid, validation) Data binding Controls generate browser-specific code Simplified handling of page state The first incarnation of ASP proved very successful. As part of the .NET Framework, Microsoft supports ASP.NET. ASP.NET is a logical evolution of ASP that addresses many of the issues previously associated with ASP. ASP.NET is now compiled and not interpreted. This of course can go some way towards improving efficiency and also means that code can now support strongly typed variables other than VARIANTS. This makes ASP.NET much more flexible and easier to code. A great deal of work has also been done to make sure that ASP.NET development has become cleaner and more productive.The first incarnation of ASP proved very successful. As part of the .NET Framework, Microsoft supports ASP.NET. ASP.NET is a logical evolution of ASP that addresses many of the issues previously associated with ASP. ASP.NET is now compiled and not interpreted. This of course can go some way towards improving efficiency and also means that code can now support strongly typed variables other than VARIANTS. This makes ASP.NET much more flexible and easier to code. A great deal of work has also been done to make sure that ASP.NET development has become cleaner and more productive.

    48. Languages C# New language created for .NET Safe, productive evolution of C++ Key concepts: Component-oriented Everything is an object Robust and durable code Preserving your investment Submitted to ECMA for standardization Uses .NET Framework classes C# is a new language designed to take advantage of most of the features of the .NET Framework. C# was designed from the ground up to support component concepts like events, methods and properties. In C#, everything is an object, which allows the creation of very clean designs. C# was designed to make it easy to create robust and maintainable software. C# should allow you to preserve your existing investment by integrating easily with your existing code.C# is a new language designed to take advantage of most of the features of the .NET Framework. C# was designed from the ground up to support component concepts like events, methods and properties. In C#, everything is an object, which allows the creation of very clean designs. C# was designed to make it easy to create robust and maintainable software. C# should allow you to preserve your existing investment by integrating easily with your existing code.

    49. Languages Visual Basic.NET Modernizes and simplifies Visual Basic Inheritance Threading Exception handling Support for late binding Uses .NET Framework classes VB.NET is a modernized version of Visual Basic. It is integrated with the .NET Framework, but still provides language constructs, features and syntax that is familiar to Visual Basic developers.VB.NET is a modernized version of Visual Basic. It is integrated with the .NET Framework, but still provides language constructs, features and syntax that is familiar to Visual Basic developers.

    50. Conclusion Internet Technologies Programming Languages and Paradigms Programming the Web .NET Overview
