Presentation Transcript
dna fingerprinting

DNA Fingerprinting

A Method of Forensic Identification

how do you figure out that someone s dna is more similar to another s
How do you figure out that someone’s DNA is more similar to another’s?
  • The primary method of assessing similarities is by use of DNA fingerprinting or DNA restriction analysis.
  • This process makes use of special proteins called restriction enzymes and sections of the chromosome called tandem repeats
tandem repeats
Tandem Repeats
  • A region of the chromosome that contains multiple copies of a core DNA sequence that are arranged in a repeating fashion
  • Repeats act as fillers or spacers between coded sections of DNA
  • All humans have the same type of repeats but there is tremendous variation in the number of repeats that each of us has.
restriction enzymes
Restriction Enzymes
  • Restriction enzymes cut DNA but only at a certain combination of A, G, T, and C.
  • Different restriction enzymes cut DNA at different places—each has a unique sequence it recognizes.
  • The restriction enzyme EcoRI cuts DNA at the sequence GAATTC and will cut only at that sequence.
restriction fragment length polymorphisms rflp
Restriction Fragment Length Polymorphisms (RFLP)
  • RFLPs are different fragment lengths of base pairs that result from cutting a DNA molecule with a restriction enzyme
  • It is the length differences associated with DNA strands or RFLPs that allow one to distinguish one person from another.
an example using ecor i for a question of paternity
An Example Using EcoR I for a Question of Paternity
  • EcoR I cuts a similar section of DNA on Bob, Larry, and Mary
  • After the cut how many fragments Bob, Larry, and Mary have?
  • Answer: 2, 3, and none

Recall: EcoR I cuts only at GAATTC

example con t
Example Con’t
  • After the DNA is cut with EcoR I, Bob’s, Larry’s and Mary’s fragments are placed in different lanes on an agarose gel
  • The fragments are then subjected to an electric field
  • The smaller fragments move faster, the larger ones move slower
  • This process of separating the fragments by length is called electrophoresis.
resulting picture after electrophoresis
Resulting Picture after Electrophoresis
  • The bigger fragments are near the top
paternity test
Paternity Test
  • In general the child’s DNA must be a combination of Mary’s DNA and one of the men. Which man is the father?
  • Answer: Larry
