slide1

NALMA / Laboratory Advisory Committee Meeting

June 19, 2003

Paul Sauvé, CLS

Tolerances for MUN

?????

slide2

Types of Analytical Methods:

  • Reference methods
    • Primary reference methods
    • Secondary reference methods
  • Official methods
  • Routine methods
  • Modified methods
  • Screening methods
  • Rapid methods
  • Automated methods
  • Indirect methods
  • AND…
  • There are many different definitions for each.
slide3

For typical DHI applications, indirect methods are used. An indirect method must be “calibrated” to agree with a direct (reference) method.

FAT:

Routine method: Infrared transmission analysis (IR)

Reference method: Ether extraction (Mojonnier extraction)

PROTEIN:

Routine method: Infrared transmission analysis (IR)

Reference method: Kjeldahl nitrogen determination

slide4

MUN:

  • Routine method: Infrared transmission analysis (IR)
  • Reference method: differential pH analysis (CL-10)
  • AND…
  • Several “secondary reference methods” are also in use:
    • Skalar
    • FIA-Star
    • ChemSpec
slide5

Is it acceptable to have different tolerances for different types of methods?

YES

Tolerances for reference methods for fat and protein are tighter than for the IR methods. This is normal. The reference (calibration) method MUST be more accurate than the indirect method.

The problem we face with MUN testing is that both direct and indirect methods are being used for analysis of routine test samples.

Some labs using the more accurate direct methods would like to see tighter tolerances.

slide6

Are all of the methods capable of providing valuable information?

YES

While the validity of the indirect methods has been challenged frequently, there is a market for these services and evidence shows that valuable information is being delivered.

If tolerances are to be enforced for MUN testing, parameters will need to be wide enough to include the indirect procedures or separate tolerances should be developed for each of the three main classes of methods. The latter approach is preferred.

“FITNESS–FOR–PURPOSE”

“USER-CENTRED REQUIREMENTS”

slide7

Performance Indicators:

Mean Difference:

The average difference between reference (target values) and the lab values. MD

Standard Deviation of Differences:

The population standard deviation of the differences between reference (target values) and the lab values. SDD

Neither of these indicators can be used independently.

slide11

So…

We need tolerances for both MD and SDD or we need to use a different statistical indicator.

x

x

x

x

x

SDD

x

x

x

x

x

x

x

MD

slide12

If tolerances are assigned for MD and SDD, we can draw a box on the graph.

Points inside the box satisfy the tolerances.

x

x

x

x

x

SDD

x

x

x

x

x

x

x

MD

slide13

OR…

We can define a new parameter, D which represents the distance from the origin (0,0) on the graph.

x

x

x

x

x

SDD

x

x

x

x

x

D

x

x

MD

slide14

If tolerances are assigned for D, we can draw a semi-circle on the graph.

Points inside the semi-circle satisfy the tolerances.

x

x

x

x

x

SDD

x

x

x

x

x

x

x

MD

slide15

Calculating D:

z

x

y

x2 + y2 = z2

Or

z =

x2 + y2

slide16

x

x

x

x

x

SDD

x

x

x

x

x

D

x

x

MD

D = MD2 + SD2

slide17

What next?:

  • Decide on the performance indicators.
  • MD and SDD
  • D
  • Decide on values for each type of method.
  • “Level 1 certification”
  • “Level 2 certification”
  • Decide how tolerances should be applied.
  • Specifications must be met in every trial, in 3 of the last 4, …
