Presentation Transcript
slide1

WHAT EVIDENCE WAS USED

EARLY TO SUPPORT THE

CONCEPT OF PLATE TECTONICS?

slide3

ALFRED LOTHAR WEGENER, 1880-1930

  • Jig-saw puzzle fit of the continents
slide4

ALFRED LOTHAR WEGENER, 1880-1930

  • Jig-saw puzzle fit of the continents
  • Fit of geologic materials between continents.
slide5

ALFRED LOTHAR WEGENER, 1880-1930

  • Jig-saw puzzle fit of the continents
  • Fit of geologic materials between continents.
  • Global Distribution of plants and animals
slide6

1. JIG-SAW PUZZLE FIT OF THE CONTINENTS

Fit accomplished using continental

shelves rather than present coastlines

02.05.a1

slide7

1. JIG-SAW PUZZLE FIT OF THE CONTINENTS

South

America

Fit accomplished using continental

shelves rather than present coastlines

02.05.a1

slide8

1. JIG-SAW PUZZLE FIT OF THE CONTINENTS

Africa

South

America

Fit accomplished using continental

shelves rather than present coastlines

02.05.a1

slide9

1. JIG-SAW PUZZLE FIT OF THE CONTINENTS

Madagascar

Africa

South

America

Fit accomplished using continental

shelves rather than present coastlines

02.05.a1

slide10

1. JIG-SAW PUZZLE FIT OF THE CONTINENTS

Madagascar

Africa

India

South

America

Fit accomplished using continental

shelves rather than present coastlines

02.05.a1

slide11

1. JIG-SAW PUZZLE FIT OF THE CONTINENTS

Madagascar

Africa

India

South

America

Australia

Fit accomplished using continental

shelves rather than present coastlines

02.05.a1

slide12

1. JIG-SAW PUZZLE FIT OF THE CONTINENTS

Madagascar

Africa

India

South

America

Antarctica

Australia

Fit accomplished using continental

shelves rather than present coastlines

02.05.a1

slide13

1. JIG-SAW PUZZLE FIT OF THE CONTINENTS

Madagascar

Africa

India

South

America

Antarctica

Australia

Small fragments

of other continents

Fit accomplished using continental

shelves rather than present coastlines

02.05.a1

slide14

2. GEOLOGIC SIMILARITIES

BETWEEN CONTINENTS.

Geologic features formed before the Atlantic Ocean (200 mya) should now be separated by thousands of miles of ocean.

11.10.b1

slide15

2. GEOLOGIC SIMILARITIES

BETWEEN CONTINENTS.

Geologic features formed before the Atlantic Ocean (200 mya) should now be separated by thousands of miles of ocean.

Rocks of the Appalachian Mountains “end” in Newfoundland, but appear to continue on through the British Isles and Scandinavia.

11.10.b1

slide16

2. GEOLOGIC SIMILARITIES

BETWEEN CONTINENTS.

Geologic features formed before the Atlantic Ocean (200 mya) should now be separated by thousands of miles of ocean.

Rocks of the Appalachian Mountains “end” in Newfoundland, but appear to continue on through the British Isles and Scandinavia.

400 my old rocks (brown) in South America and Africa fit together like the pattern on jig-saw puzzle pieces.

11.10.b1

slide19

Evidence of glaciation (typical patterns or erosion and deposition).

Glaciers on land, not sea

Flow patterns match up when reconstructed

250 million years ago

Permian -Triassic

slide20

3. FOSSIL PLANTS AND ANIMALS.

Cynognathus

South America

and Africa

Lystrosaurus

Australia, Antarctica,

India, Africa

slide22

PANGEA NOT THE ONLY OR ORIGINAL “SUPER-CONTINENT”

Pangea

Earth’s History

Present

Pangea

Forsythe et al., 2009 Eos, 90(41), p. 361-362
