what do we know about l ledd accretion bhb ulx and how does astro h help
What do we know about L~Ledd accretion – BHB, ULX –and how does Astro-H help?

Chris Done, Chichuin Jin, Mari Kolehmainen

University of Durham

slide2

Astro-H

  • Next Japanese X-ray satellite due for launch in Dec 2015
  • Calorimeter 5eV spectral resolution
  • Broad bandpass

0.5-500 keV

slide6

Black hole binaries

  • Observe dramatic changes in SED with mass accretion rate onto black hole
  • Dramatic changes in continuum – single object, different days
  • Underlying pattern in all systems
  • High L/LEdd:soft spectrum, peaks at kTmaxoften disc-like, plus tail
  • Lower L/LEdd:hard spectrum, peaks at high energies, not like a disc (McClintock & Remillard 2006)
slide7

Moving disc – moving QPO

  • Energy spectra: disc moves 50-6ish Rg as make transition
  • Power spectra: low frequency break moves correlated with QPO, high frequency power more or less constant!
  • Large radius moves, Small radii constant
slide8

Moving disc – moving QPO

  • Energy spectra: disc moves 50-6ish Rg as make transition
  • Power spectra: low frequency break moves correlated with QPO, high frequency power more or less constant!
  • Large radius moves, Small radii constant
slide9

Variability of disc

  • L/LEddAT4max(Ebisawa et al 1993; Kubota et al 1999; 2001)
  • Constant size scale – last stable orbit!! BH spin
slide10

Disc spectra: last stable orbit

  • L/LEddT4maxEbisawaet al 1993; Kubota et al 1999; 2001
  • Constant size scale – last stable orbit!!
  • Not quite as simple as this
  • BHSPEC - Proper relativistic emissivity (Novikov-Thorne)
  • corrections for spectrum not being blackbody (fcol)
  • Corrections for relativistic propagation effects Davis et al 2005

Kolehmainen & Done 2010

relativistic effects
Relativistic effects (special and general) affect all emission (Cunningham 1975)

Emission from the side of the disc coming towards us is blueshifted and boosted by Doppler effects, while opposite side is redshifted and suppressed.

Also time dilation and gravitational redshift

Broadens spectrum at a give radius from a narrow blackbody

Relativistic effects

flux

Energy (keV)

Fabian et al. 1989

slide12

fcolkT

Theoretical disc spectra

  • Surely even disc spectra aren’t this simple!!!!
  • Disc annuli not blackbody – too hot, so little true opacity. Compton scattering important.
  • Modified blackbody Shakura & Sunyaev 1973
  • Describe by colour temperature fcol
  • And relativistic smearing effects on the spectra at each radius

kTeff

Log n f(n)

Log n

fcol changes but ok ledd
Fcol changes but OK <LEdd

XMM RXTE

  • Fcol up to 2 so peaks in vfv<4keV for Teff=0.5 keV disc
slide14

BHB Disc spectra:10 M L/LEdd~1

Kolehmainen et al 2013

  • LMC X-3
  • Peak at 3.5 keV for ~0.8LEdd
  • 3.5 x (10/107)1/4~0.1keV for 107 AGN (Ross, Fabian & Mineshige 1991)
  • ‘broadened disc’
slide15

Moving disc – moving QPO

  • Energy spectra: disc moves 50-6ish Rg as make transition
  • Power spectra: low frequency break moves correlated with QPO, high frequency power more or less constant!
  • Large radius moves, Small radii constant
slide16

Radius no longer constant!

  • Radius can be higher or lower when disc NOT dominant (steep PL)
  • Don’t do this!!

very high

disk dominated

high/soft

Kubota & Done 2004

very high state spectrum
Very High State: Spectrum

Kubota & Done 2004

  • Disc AND tail have roughly equal power. BE CAREFUL!!!
  • Now depends on models - Comptonized spectrum is NOT a power law close to seed photons!

Log n f(n)

  • Disc dominated(low L / high L)
  • Very high state (comp < disc)
  • Very high state (comp > disc)

Log E

very high state spectrum1
Very High State: Spectrum

Kubota & Done 2004

  • Disc AND tail have roughly equal power. BE CAREFUL!!!
  • Now depends on models - Comptonized spectrum is NOT a power law close to seed photons!

Log n f(n)

  • Disc dominated(low L / high L)
  • Very high state (comp < disc)
  • Very high state (comp > disc)

Log E

very high state photons
Very High State: photons

Kubota & Done 2004

  • But Comptonised photons come from the disc – optically thick so suppresses apparent disc emission
  • Correct for this

Log n f(n)

Log E

very high state energy
Very High State: energy

Kubota & Done 2004

  • But ENERGY of corona came from disc as well. Lower T under corona but more importantly lower L enhancing outer disc

L(R)

R-3

R

very high state energy1
Very High State: energy

Done & Kubota 2005

  • But ENERGY of corona came from disc as well. Lower T under corona but more importantly lower L enhancing outer disc (Svensson & Zdziarski 1994)

L(R)

R-3

R

slide22

Disk + Compton! Bandpass!!

  • All high L states have disc plus tail
  • Disc – low E, constant on short timescales
  • Compton – high E, varies on short timescales
  • Steep power law state is HARD at low E
slide23

Disk + Compton! Bandpass!!

  • XTEJ1550-564
  • ASCA-RXTE-OSSE
  • Steep power law state is HARD at low E
  • low kTbb~0.6keV, high kTe~20keV compared to ULX
slide24

GRS1915+105 (Nh 4-6e22!)

kTe~7keV kTe~3keV

Done et al 2004

slide25

ULX state ?

Gladstone Roberts & Done 2008

slide26

ULX state ?

Gladstone Roberts & Done 2008

slide27

Modifies optical continuum

  • X-rays illuminate outer disc where intrinsic flux is low so reprocessed can dominate (van Paradijs 1996)
  • SWIFT/XMM X-opt simultaneously
  • XTE J1817-330 - trace scattered fraction through outburst SWIFT+RXTE
  • Lopt ~ 0.002 Ldisc in high/soft state.
  • Big changes at transition to low/hard state….

Gierlinski Done & Page 2007

slide28

Luminosity >LEdd ?

  • Standard disc assumes that energy liberated locally through mass accretion is radiated locally
  • Not necessarily true – can be carried radially along with the flow is accretion timescale < radiated timescale
  • Optically thick advection – slim discs (Abramowicz et al 1988) only different L>LEdd
  • Heats next ring in – but can advect that also. Then lose does the black hole!
  • L=LEdd log(1+mdot/mdotEdd)

Log n f(n)

Log n

slide29

Luminosity >LEdd ?

  • Standard disc assumes that energy liberated locally through mass accretion is radiated locally
  • Not necessarily true – can be carried radially along with the flow is accretion timescale < radiated timescale
  • Optically thick advection – slim discs (Abramowicz et al 1988) only different L>LEdd
  • Heats next ring in – but can advect that also. Then lose does the black hole!
  • L=LEdd log(1+mdot/mdotEdd)

Log n f(n)

Log n

slide30

Luminosity >LEdd ?

  • Standard disc assumes that mdoty constant with R
  • Not necessarily true – can lose mass in a wind is L>LEdd (Shakura & Sunyaev 1973)
  • L=LEdd log(1+mdot/mdotEdd) i.e. same as before but for different reason

Log n f(n)

Log n

slide31

Luminosity >LEdd ?

  • Standard disc assumes that mdotyconstant with R
  • Not necessarily true – can lose mass in a wind is L>LEdd(Shakura & Sunyaev 1973)
  • L=LEdd log(1+mdot/mdotEdd)i.e. same as before but for different reason – local flux at disc surface has to be <LEdd
  • Two possible responses – so disc probably does both as seen in numerical simulations

Log n f(n)

Log n

slide32

Modifies optical continuum

  • Expect f_opt,int/f_x to increase
  • X-rays decrease via advection and/or mass loss
  • Optical determined by irradiation – depends on geometry
  • If see irradiation then CAN’T be strongly beamed
slide33

Modifies optical continuum

  • Expect f_opt,int/f_x to increase
  • X-rays decrease via advection and/or mass loss
  • Optical determined by irradiation – depends on geometry
  • If see irradiation then CAN’T be strongly beamed
  • M81 X6

Sutton et al 2014

conclusions
Conclusions:
  • BHB spectral states: disk (low E) plus tail (high E)
  • Bandpass makes a difference RXTE (BHB) XMM (ULX)
  • High L~Ledd can show disc (constant radius)
  • Fraction illuminating outer disc is small
  • Disky ULX – fraction illuminating outer disc small
  • Or very high state – larger size scale, lower kTe– connects to ULX?
  • But then got more extreme ULX states – higher mdot?
  • fopt determined by irradiation – so irradiating disc so not highly collimated….
  • NOT like expect for mdot~1000
