  1. Working with CBA Component Based Automation Creating Components Engineering Tool (STEP7) Using Components SIMATIC iMap

  2. Creating components with SIMATIC STEP7 Highlights of the new version 3.0(Extracts)

  3. Steps to create a component • Define devices and functions • Create hardware configuration • Addressing of singleton component • PROFINET Components: • Adjusting CPU’s scan cycle load from communication • Limit PROFINET communication load for local PROFINET IO-Devices • Set the name for local PROFINET IO-Devices • Create PROFINET Interface • Programming of the function • PN copy blocks (PROFINET System-Library) only required when the PN Interfaces will be updated by user program • Generate the component

  4. Support of components with several PROFIBUS DP Master and PROFINET IO-System

  5. Adjusting scan cycle load from communication

  6. Adjusting PROFINET RT communication load for local PROFINET IO-Devices

  7. Addressing local PROFINET IO-Devices by the device name

  8. Creating a PROFINET Interfaces

  9. Graphical preview of the SW-function Properties of the connector Intuitive Interface Editor within STEP7

  10. Multifunction component

  11. Properties of component

  12. Defining component type and the PROFIBUS DP master systems with PROXY functionality

  13. Using of componentswithin SIMATIC iMap Highlights of the new Version 3.0(Extracts)

  14. Basic procedure for configuring the plant • Structure the plant • Insert components in SIMATIC iMap library / project • Couple and address devices in the net view (IP-address and/or PROFIBUS-address) • Interconnect technological functions in the plant view • Modifying properties of devices and functions (optional) • Check the project • Generate the project • Commissioning of devices • Download of project data to the devices • If required rework of devices and technological function in vendor specific Engineering-Tool (optional) • Test the plant • Document and archive the project

  15. New working range: Chart view Plant and Network overview Working range: Plant view, Network view Project view Library window New: one info window for status und diagnosis New look & feel of SIMATIC iMap

  16. 2 1 Reduction of rework cycle and consistent data by project library

  17. Multifunction componentn-functions within one device

  18. Higher performance in communication due to PROFINET Real-Time (RT)

  19. Hidden connectors Highlighted connections Improved plant view by downsizing to process relevant data

  20. Reduced connection by using data type ‚STRUCT‘ Online status of structured data in variable table

  21. Support of components with several PROFIBUS DP master systems – CPU 319-3 PN/DP Component withseveral PROFIBUSDP systems

  22. Unique addressing of local PROFINET IO-Devices Device name

  23. Parts of the Component Generation state Online-state Component with n functions Simple administration of the project in project view

  24. Delta Download for modified program

  25. Improved download of several CPU’s withoutPop-Up windows

  26. Shorter commissioning time with improved system and device diagnosis Graphical informationin the diagnostic window

  27. Unambiguous OPC Tag-File Generationfor each project

  28. Improved project documentation in HTML format and printout

  29. SIMATIC iMap V3.0New functions • Several functions within one device (based on CPU 319-3 PN/DP) • Comfortable navigation and plan overview through new „Chart view“ • Improvements in diagnostic and better support by help on errors • Support of PROFINET components with integrated PROFINET IO-Devices • Support of CPU 319-3 PN/DP • Support of several PROFIBUS DP master systems in one device (based on CPU 319-3 DP/PN) • Support of WinCC flexible panels within the component

  30. SIMATIC iMap V3.0Further new functions • Hide and show of connectors to get a better overview in the plant view • Support of delta download for program blocks to keep the process relevant data • Comfortable download of several CPUs without Pop-Up windows • Improved project documentation in HTML format and printout inclusive cross-reference • Further language support: Italian, French, Spanish • Support of additional operating systems

  31. CBA Components Products for CBA

  32. CPU 319-3 PN/DP CPU 4xx + CP 443-1 Adv. CPU 317-2 PN/DP CPU 315-2 PN/DP Machine-machine communication IE/PBLink S7 300 + CP 343-1 Adv. IM 151CPU Decentralized intelligenceon PB with PN/DP Proxy Component Based Automation:The different levels of modularity From decentralized intelligence up to machine-machine communication
