1. Streams
2. The hydrologic cycle
3. Sources of Earth’s water
4. Running water Streamflow
Factors that determine velocity
Gradient, or slope
Channel characteristics including shape, size, and roughness
Discharge – the volume of water moving past a given point in a certain amount of time
5. Longitudinal profile of a stream
6.
Base level and Graded Streams
Base level is the lowest point to which a stream can erode
Two types of base level
Ultimate (sea level)
Local or temporary
Graded Streams restore original state
Changing conditions causes adjustment
Sudden extra sediment steeper gradient, faster flow erosion, sediment removed and equilibrium reestablished.
Equilibrium is temporary
8. Stream - Sediment Terminology Transport of sediment by streams
Transported material is called load
Types of load
Dissolved load – ions in solution from weathering
Suspended load – fine particles
Bed load Moves during high velocity events
Sandy Portion – Saltation (bouncing)
Cobbles – Traction (rolling)
Capacity –maximum load stream transports
Competence – Largest particles it can move
Proportional to velocity squared
10. Competence
maximum particle size a stream transports
Proportional to velocity squared –K.E.
12. Stream valleys
Most common landforms on Earth’s surface
General features of stream valleys
1. Narrow valleys – Very Steep Gradient
V-shaped
Downcutting toward base level
Can include rapids and waterfalls
13.
Wide Stream Valleys
Low bed load, high suspended load
2. Wide valleys often include
Floodplains
Erosional floodplains
Depositional floodplains
Meanders
Cut bank and point bar
Cutoffs and oxbow lakes
Levees
14. Erosion and deposition along a meandering stream
16. Point Bar Sequence
17. Formation of natural levees by flooding
21. Incised meanders
Meanders in steep, narrow valleys
Caused by a drop in base level or uplift of region
23. Stream terraces
Terraces
Remnants of former floodplain
River adjusts to drop in base level by downcutting
27. Braided Streams Very high bed load, intermittent flow
Often adjacent to mountains w/ seasonal flow
Mid-channel bars split the stream
Many channels
29. Deltas Occur where stream hits slow water
Suspended load is dropped
Deposits build out into lake or sheltered sea, extending the length of the river
Consists of three types of beds
Topset beds - horizontal, surface delta
Foreset beds - delta slope
Bottomset beds – horizontal, bottom sea
32. Groundwater
33. Importance of groundwater Groundwater is water found between grains in sediment, and in narrow fractures in bedrock
Groundwater is the largest reservoir of fresh water available to humans
34. Sources of Earth’s water
35. The water table Water table is the upper limit of saturation
Variations in the water table
Depth is highly variable
Varies seasonally and from year to year
Shape is usually similar to surface topography
37. Factors influencing movement of groundwater Permeability, aquitards, and aquifers
Porosity – Volume of Pore Space
Permeability – the ability of a material to transmit a fluid through pore space
Aquitard – an impermeable layer that hinders water movement (such as clay)
Aquifer – permeable rock strata or sediment that transmits groundwater freely (such as sands and gravels)
38. Springs may result from a perched water table
39. Features associated with groundwater Hot springs
Water is 6-9oC warmer than the mean annual air temperature of the locality
The water for most hot springs is heated by cooling of igneous rock
40. Features associated with groundwater Geysers
Intermittent hot springs
Water erupts with great force
Occur where extensive underground chambers exist within hot igneous rock
Groundwater heats, expands, changes to steam, and erupts
46. Features associated with groundwater Wells
To ensure a continuous supply of water, a well must penetrate below the water table
Pumping of wells can cause
Drawdown (lowering) of the water table
Cone of depression in the water table
47. Formation of a cone of depression in the water table
48. Saltwater contamination due to excessive well pumping
50. Geologic work of groundwater Acidic groundwater dissolves limestone
Groundwater is often mildly acidic
Rain contains weak carbonic acid
Forms when rainwater dissolves carbon dioxide from air
Humic acid from decaying plants increses acidity
Carbonic acid reacts with calcite in limestone to form calcium bicarbonate, a soluble material
Cements particles – lithification
Hard water – a problem for pipes
51. Geologic work of groundwater Caverns
Features found within caverns
Composed of dripstone (travertine)
Calcite deposited as dripping water evaporates
Includes stalactites (hanging from the ceiling) and stalagmites (form on the floor of a cavern)
52. Geologic work of groundwater Karst topography
Landscapes that have been shaped by the dissolving power of groundwater on limestone
Some common features include
Irregular terrain
Sinkhole or sinks (formed by groundwater slowly dissolving the bedrock often accompanied by collapse)
Disappearing (aka sinking) streams
53. Karst Topography
Sinkhole or sinks (formed by groundwater slowly dissolving the bedrock often accompanied by collapse)
Disappearing (aka sinking) streams
55. Florida sinkholesFlorida sinkholes
56. End of Chapter 14
