  1. Section A Information Systems CHAPTER 9 Information Systems Analysis and Design PARSONS/OJA Page 442

  2. Chapter 9 Information Systems Analysis and Design Chapter PREVIEW • Information systems • Types of information systems • System development life cycle (SDLC) Page 443

  3. Section A Chapter 9 Information Systems What is an information system? • An information systemcollects, stores, and processes data to provide useful, accurate, and timely information • Information is used to make decisions Page 444

  4. Section A Chapter 9 Information Systems Who uses information systems? • Top management makes decisions with long-range impact. Referred to as strategic planning • Summarized information for entire company • Mid-level managers set incremental goals that can be achieved in a year or less—a process referred to as tactical planning • Information relevant to manager’s responsibilities • Low-level managers are responsible for scheduling employees, ordering supplies, and other activities that make day-to-day operations run smoothly—a process referred to as operational planning • Detailed information Page 445

  5. Section A Chapter 9 Information Systems How do information systems help the people in an organization? • An information system can help the people in an organization perform their jobs more quickly and effectively by automating routine tasks • Online banking • One of the major functions of an information system is to help people make decisions in response to problems • Price for flight from Dallas to Chicago on Southwest Page 446

  6. Section A Chapter 9 Information Systems Do organizations require different kinds of information systems? • Because organizations have different missions, face different threats, and encounter different opportunities, they require different kinds of information systems Page 448

  7. Section A Chapter 9 Information Systems Types of information systems • Office automation systems • Transaction processing systems • Management information system • Decision support system • Expert systems • Neural networks • Data base mining Page 448

  8. Section A Chapter 9 Information Systems Office Automation Systems: • An office automation system “automates,” or computerizes, routine office tasks • Reorder of inventory Page 448

  9. Section A Chapter 9 Information Systems Transaction Processing Systems: What’s a transaction? • A transaction is an event that requires a manual or computer-based activity • Order a cheeseburger at McDonalds • Most modern transaction processing systems use online processing. Such systems are often referred to as OLTPS (online transaction processing systems) • Adding/dropping classes at EIU Page 449

  10. Section A Chapter 9 Information Systems What are common examples of transaction processing systems? • A point-of-sale (POS) system records items purchased at each cash register, and calculates the total amount due for each sale • An order-entry/invoice system provides a way to input, view, modify, and delete customer orders • A general accounting system records the financial status of a business by keeping track of income, expenses, and assets • An e-commerce system collects orders and processes credit card payments Page 450

  11. Section A Chapter 9 Information Systems Management Information Systems: What is a management information system? • A management information system (MIS) refers to a type of information system that uses the data collected by a transaction processing system, but manipulates that data to create reports that managers can use to make routine business decisions in response to structured problems Page 450

  12. Section A Chapter 9 Information Systems What is a management information system? • One of the major goals of an MIS is to increase the efficiency of managerial activity • A summary report combines or groups data and often shows totals • Top management • An exception report contains information that is outside of normal or acceptable ranges • Middle management: regions where GM SUV sales below monthly forecast • Scheduled reports follow a fixed format and are produced according to a preset timetable • An ad hoc report is a customized report, generated to supply specific information not available in scheduled reports • Impact of SARS on airlines at Toronto’s airport Page 451

  13. Section A Chapter 9 Information Systems How does an MIS differ from a TPS? • Whereas a TPS simply records data, an MIS can consolidate data by grouping and summarizing it • TPS provides raw material • MIS is finished product Page 451

  14. Section A Chapter 9 Information Systems What are the limitations of a management information system? • A traditional MIS is based on the data collected by a transaction processing system • Employee morale • The reports generated by an MIS are limited by the processing capabilities of the database software. • The MIS cannot typically be used to create models or projections Page 451

  15. Section A Chapter 9 Information Systems Decision Support Systems: What’s a decision support system? • A decision support system (DSS) helps people make decisions by directly manipulating data, analyzing data from external sources, generating statistical projections, and creating data models of various scenarios Page 452

  16. Section A Chapter 9 Information Systems What’s a decision support system? • A DSS does not make decisions, however. That task remains the responsibility of the human decision maker • A decision model is a numerical representation of a realistic situation • A decision query is a question or set of instructions describing data that must be gathered to make a decision • Pujols has hit .537 against left handed pitchers • A DSS typically includes modeling tools so managers can create a numerical representation of a situation and explore “what-if” alternatives Page 452

  17. Section A Chapter 9 Information Systems What are the limitations of a DSS? • A DSS helps people manipulate the data necessary to make a decision, but does not actually make a decision • A DSS is appropriate in situations where it is used by trained professionals Page 453

  18. Section A Chapter 9 Information Systems Expert Systems: What is an expert system? • An expert system, sometimes referred to as a “knowledge-based system,” is a computer system designed to analyze data and produce a recommendation, diagnosis, or decision based on a set of facts and rules • The facts and rules for an expert system are typically derived by interviewing one or more experts, and then incorporated into a knowledge base • What percent of my portfolio should be invested in stocks? Page 453

  19. Section A Chapter 9 Information Systems Expert Systems: What is an expert system? • Use data base of knowledge to draw conclusions • Data base is If, Then knowledge • Rules of thumb provided by expert individuals • Can handle routine situations with great accuracy; leaves complex situations to humans • Can explain why it reached conclusion: loan denied because… • Each expert system is designed to make decisions in a particular area or “domain” • Credit card fraud, HP printer support Page 453

  20. Section A Chapter 9 Information Systems Neural networks • An expert system begins with a set of facts and rules. But if the rules are not known, a computer can “learn” how to make decisions based on hundreds or thousands of lightning-fast trial and error attempts • A neural networkuses computer circuitry to simulate the way a brain might process information, learn, and remember • Looks for patterns that work • May use genetic algorithms where only the best solutions “survive” Page 455

  21. Section A Chapter 9 Information Systems Neural networks are used when… • There are not “hard and fast” solutions such as pattern recognition and forecasting • Neural nets are well suited to problems that people are good at solving, but for which computers are not. • What are the characteristics of a terrorist? Page 455

  22. Section A Chapter 9 Information Systems Data base mining • automated extraction of predictive information from large databases • What customer will respond to a catalog of bird feed and houses? • Deep Blue used data mining to calculate all possible moves and selected best move • Confirming or discovering patterns in huge data bases Page 455

  23. Section A Chapter 9 Information Systems Data base mining • Pattern validation: • Confirm existence of expected patterns. • Visits to Health Service in November versus September • Top down data mining • May not ask about the right patterns. • Pattern discovery • 75% of the purchasers of low-fat ice cream buy bottled water Page 455

  24. Section B Chapter 9 Systems Analysis What is a system development life cycle? Page 458

  25. Section B Chapter 9 Systems Analysis Planning Phase: How does an information system project begin? • An information system project begins with a planning phase • The goal of these activities is to create a Project Development Plan • This planning document includes: • A short description of the project, including its scope • A justification for the project • A list of project team participants • A schedule for the project, including an outline of its phases Page 456

  26. Section B Chapter 9 Systems Analysis Justify Project: Why are new information systems developed? • The justification for a new information system usually emerges from a serious problem with the current system, or from an opportunity to improve an organization’s products or services using technology • Perhaps your network can’t handle traffic trying to use the Internet at peak times Page 457

  27. Section B Chapter 9 Systems Analysis Analysis Phase: What happens in the analysis phase? • The goal of the analysis phase is to produce a list of requirements for a new or revised information system Page 460

  28. Section B Chapter 9 Systems Analysis Is it really important to understand the current system before planning a new system? • Typically, a new information system is designed to replace a system or process that is already in place • It is important to study the current system to understand its strengths and weaknesses before planning a new system Page 460

  29. Section B Chapter 9 Systems Analysis Determine System Requirements: How does the project team determine what the new system should do? • System requirements are the criteria for successfully solving the problem or problems identified in an information system • They also serve as an evaluation checklist at the end of the development project, so they are sometimes called success factors Page 461

  30. Section B Chapter 9 Systems Analysis What marks the end of the analysis phase of the SDLC? • The analysis phase concludes when the project team produces a written report that documents its findings • The System Requirements Report typically contains diagrams that illustrate what the new information system should do • Should we do the same thing when we buy a personal computer? Page 462

  31. Section C Chapter 9 System Design Design Phase: What happens in the design phase? • In the design phase of the SDLC, the project team must figure out HOW the new system will fulfill the requirements specified in the System Requirements Report Page 464

  32. Section C Chapter 9 System Design Identify Potential Solutions: How does the project team come up with solutions? • There might be more than one way to solve the problems and meet the requirements identified in the analysis phase of the SDLC • The project team should identify several potential hardware and software solutions by “brainstorming” and researching case studies on Web sites and in computer magazines Page 464

  33. Section C Chapter 9 System Design What kinds of hardware alternatives are available? • A myriad of hardware options are available for information systems • Mainframes, servers, and personal computers are the most commonly used components, but in some information systems, handhelds, or even supercomputers, play a role Page 464

  34. Section C Chapter 9 System Design What kinds of software alternatives are available? • The project team might consider software alternatives, such as whether to construct the system “from scratch,” use an application development tool, or commercial software • Creating an information system “from scratch” using a programming language can take many months or years • An application development tool is essentially a type of software construction kit containing building blocks that can be assembled into a software product Page 466

  35. Section C Chapter 9 System Design What kinds of software alternatives are available? • Commercial software for an information system is usually a series of pre-programmed software modules, supplied by a software developer, consulting company, or value-added reseller (VAR) • A turnkey system is essentially an “information system in a box” which consists of hardware and commercial software designed to offer a complete information system solution • A turnkey system must be extensively evaluated to determine whether it can satisfy system requirements Page 466

  36. Section C Chapter 9 System Design Evaluate Solutions and Select the Best: How does the team choose the best solution? • To determine the best solution the project team devises a list of criteria for comparing each of the potential solutions • Each criterion is assigned a weight to indicate its importance. The project team then evaluates the criteria for each solution and assigns raw scores • Sound complicated? It isn’t, especially if the project team uses a decision table Page 467

  37. Section C Chapter 9 System Design Select Hardware and Software: How does the project team find the right hardware and software for the new information system? • Once the project team selects a solution, the next task is to select the hardware and software needed to implement the solution • The method for selecting the hardware, software, and vendor depends on the project team’s understanding of what is required for the solution Page 467

  38. Section C Chapter 9 System Design Develop Application Specifications: What happens after the project team selects a solution? • Exactly what happens next in the system design phase depends on the type of solution selected • If the project team selected a solution that requires custom programming, the team’s systems analysts will create a set of application specifications Page 469

  39. Section C Chapter 9 System Design What happens to the completed specifications? • Application specifications are similar to the pages of an architectural blueprint that show the detailed plan for electrical wiring or plumbing • In a large information systems project, the specifications are given to a programming team or application developer who creates the software • In a small information systems project, you as the user might develop your own specifications Page 470

  40. Section D Chapter 9 Implementation and Maintenance Implementation Phase: What happens during the implementation phase? • During the implementation phase of the SDLC, the project team supervises the tasks necessary to construct the new information system Page 471

  41. Section D Chapter 9 Implementation and Maintenance Purchase and Install Hardware and Software: Do most new information systems require new hardware? • Most new information systems require new hardware, which can either replace old equipment, or be connected to existing equipment Page 471

  42. Section D Chapter 9 Implementation and Maintenance How about new software? • Many information systems require new software, such as a commercial application, a programming language, an application development tool, or an expert system shell Page 471

  43. Section D Chapter 9 Implementation and Maintenance Test Applications: How can the team ensure that a new information system works? • A rigorous testing process is the only way to make sure that a new information system works Page 472

  44. Section D Chapter 9 Implementation and Maintenance What is application testing? • Application testing is the process of trying out various sequences of input values and checking the results to verify that the application works correctly • As each application module is completed, it undergoes unit testing to ensure that it operates reliably and correctly • When all modules have been completed and tested, integration testing is performed to ensure that the modules operate together correctly Page 472

  45. Section D Chapter 9 Implementation and Maintenance Train Users: How do employees learn how to use the new information system? • In preparation for using a new information system, users need extensive training, which might include hardware operation, data entry, and backup procedures • Training sessions can be conducted by members of the team or professional trainers • Resistance to change!!! Page 473

  46. Section D Chapter 9 Implementation and Maintenance Convert to New System: How does a business switch from the old system to the new system? • System conversion refers to the process of deactivating an old information system and activating the new one • A direct (crash) conversion means that the old system is completely deactivated and the new system is immediately activated • A parallel conversion avoids some of the risk because the old system remains in service while some or all of the new system is activated • In a phased conversion, the new system is activated one module at a time Page 474

  47. Section D Chapter 9 Implementation and Maintenance How does a business switch from the old system to the new system? • A pilot conversion works well in organizations with several branches that have independent information processing systems • The new information system is activated at one branch • If the system works correctly at one branch, it is activated at the next branch Page 474

  48. Section D Chapter 9 Implementation and Maintenance Maintenance Phase: What happens during the maintenance phase? • The maintenance phase of the SDLC involves day-to-day operation of the system, making modifications to improve performance, and correcting problems • The maintenance phase of the SDLC is the most expensive because it lasts until the system is retired Page 475

  49. Section D Chapter 9 Implementation and Maintenance Why do maintenance activities include user support? • Even after-in-depth training, employees sometimes forget procedures, or have difficulty when they encounter a new set of circumstances • Many organizations establish a help desk to handle end-user problems Page 476

  50. Section D Chapter 9 Implementation and Maintenance Does an information system change during the maintenance phase? • The term “maintenance phase” is a bit misleading • Changes during the maintenance phase typically include the following: • Upgrades to operating system and commercial software • User interface revisions • Application software revisions • Hardware replacements • Security upgrades Page 477
