flash memory built in self diagnosis with test mode control

Flash Memory Built-In Self-Diagnosis with Test Mode Control

Jen-Chieh Yeh, Yan-Ting Lai,Yuan-Yuan Shih, and Cheng-Wen Wu

Laboratory for Reliable Computing (LaRC)

Department of Electrical EngineeringNational Tsing Hua University

Hsinchu, Taiwan 30013

outline
Outline
  • Introduction
  • Flash Memory Diagnosis Methodology
  • BISD with Enhanced Test Mode Control
  • Experimental Results
  • Conclusions
introduction
Introduction
  • Flash memory is enjoying a rapid market growth
  • System integration and new applications drive the demand for flash technologies [ITRS 2003]
  • Embedded flash memory is gaining popularity in SOC applications
  • BIST and BISD are considered a good solution for flash memory testing and diagnosis
flash memory fault models
Flash Memory Fault Models
  • Flash memories are commonly tested for disturbance problems
  • Flash disturb fault models are defined in our DELTA02 and VTS02 papers
  • WPD, WED, BPD, BED, and OP faults are considered here for the BiNOR-type flash memory
  • SAF, TF, SOF, CFst and AF are also considered
binor type flash memory
BiNOR-Type Flash Memory
  • Bi-directional tunneling program/erase NOR-type flash memory
  • Low power consumption and excellent reliability

Source: IEEE Trans. Electron Devices, 2001

flash memory diagnosis methodology
Flash Memory Diagnosis Methodology

SAF, TF, SOF, CFst, AF,

Fault Models

WPD, WED, BPD, BED, OP

Fault

Fault Dictionary

(SA1)

Simulator

Error Catch

Diagnosis

March-FT

and Analysis*

Algorithm

Parser

(WPD)

(to get

Tester Log

BISD

signatures)

(BPD)

Fault Map

Source: ICCAD00

Error Bit Map

part of the march ft fault dictionary
Part of the March-FT Fault Dictionary
  • March-FT:{ (f); (r1,p0,r0); (r0); (f); (r1,p0,r0); (r0); }< 0 0 0 1 1 0 0 0 1 1 >
bisd with enhanced test mode control
BISD with Enhanced Test Mode Control
  • Built-in March-FT algorithm
  • Programmable diagnosis algorithms
  • Flexible output format for test and/or diagnosis
  • Supports dynamic burn-in (BI) test
  • Engineering test mode can be accessed by BISD
    • Overall test time is reduced
  • Provides various types of access commands, e.g., Reset Wait
high voltage hi v tests
High Voltage (HI-V) Tests
  • HI-V tests usually employed to reduce the test time in the engineering test mode
  • TExecution(HI-V Erase) < TExecution(Erase)

{A9, RSTB, OEB}

HI-V

Detector

Normal

flags

Signal

Memory

{A[17:10], A[8:0]}

Controller

Test Collar

DQ

{WEB, CEB}

Memory

BISD

Array

bisd architecture
BISD Architecture

2

RBB

BSI

MUX

CMD Reg.

FSMofTPG

WPB

FOPC Look-Up Table

5

CLK

CMDDecision

FSMofCTR

8

I/O1

5

BRS

ADDR Generator

BMS

MarchOp.Counter

I/O Selector

BNS

8

BIM

I/O2

DB Generator& Comparator

BAC

BFI

CEB

WEB

E-info. SelectorE-info. Register

E-info.Collector

Control Signal Generator

7

5

43

BSO

REB

CLE

ALE

BISD Controller(CTR)

Test Pattern Generator(TPG)

parallel test methods
Parallel Test Methods

Original Program/Erase Unit

Page buffer & SA

Page buffer &SA

Y-Decoder

Block 0

Block 1024

Block 1

Block 1025

Block 2

Block 1026

Plane 0

Plane 1

FlashMemoryController

Block 1023

Block 2047

Page buffer & SA

Page buffer &SA

Charge pump and other analog circuitry

X-Decoder

Proposed Program/Erase Unit

experimental results
Experimental Results
  • BISD circuit implemented on FPGA
  • BISD test results compared with those of ATE
results for 256mb flash memory
Results for 256Mb Flash Memory
  • Three chips are tested in this case
  • ATE test result: one passed and two failed
  • FPGA (BISD prototype) test results: two passed and one failed
    • The difference between ATE and FPGA is clock rate
    • Real BISD can perform at-speed test
  • Diagnosis result for the failed chip: one block cannot be erased (SA0)
    • Same for ATE & FPGA
conclusions
Conclusions
  • We have proposed a flash memory diagnosis methodology and BISD design
    • Supports test, diagnosis, and BI modes
    • With enhanced test mode control
  • Area overhead is low
  • An FPGA-based low-cost flash memory diagnosis system is implemented
    • Real BISD required for at-speed test
